MOMOHO BTS0011 User Manual

MINI Bluetooth Speaker
User Manual
1 3
2
1.Speaker 2.Micro USB socket
5.Hole for cord 6.Hole for MIC
4.Turn off the speaker by pressing " " button for 4 seconds
and the speaker will sound "DI DO". When disconnected,
this speaker will turn off after 5 miniutes.
Note:1.When you can't take a photo,under the Android
system,please open "Settings"-"Camera",then set
"Volume key" to"Settings";under the IOS system,
you just need to refresh the Bluetooth connection.
2.When you can't play tthe music,please refresh the
Bluetooth connection.
3.Under the music playing model,short press "
button can increase the volume.
Charging the battery:
1.Insert the charging cable into the Micro USB input port,
connect the USB plug into 5V/300mAh USB power terminal.
The LED indicator will turn red.
2.After charging completed, the red LED indicator will turn off.
Note:When music sound become smaller and you hear the
warning tone "DI DI",Please charge this speaker in time.
5
4 6 Bluetooth pairing for music/phone call/camera remote shutter
1.Turn on the speaker by pressing "
The speaker will have a voice prompt and blue indicator will
flash.
2.Turn on your device and activate the Bluetooth function.
3.Search for Bluetooth pairing name "BTS0011" and click to
pair,the speaker will pair automatically and the speaker will
have a voice prompt,the blue indicator will light on.
Then,just need to press "
open your music player or answer the call when the call is
coming or take a photo when open the camera of your
devices.
Specification:
Model
Power Rating
Transmitting Frequency
THD
S/N
Speaker Parameter
Battery
"
Bluetooth Version
Recharge Voltage
Product Size
Dong guan Haolisheng Electronic Technology Co.,Ltd
" button for 3 seconds,
" button to play music when
BTS0011
PO=1W
150-16KHZ
<1%
>90DB
4Ω2W Dimaeter 30mm
3.7V/140mAh
Bluetooth V4.2
DC 5V 0.3A
35.6X25mm
