Summary of Contents for Pressalit Care R2170

  • Page 1 R2170 - R2172 Page 1/12 2021-02-19 Mounting instruction Montage-voorschrift Monteringsvejledning Monteringsanvisning Montageanleitung Monteringsveiledning Notice de montage Instrucciones de montaje Subject to alteration without further notice. Ret til ændringer forbeholdes.· Recht auf Änderungen sind vor- behalten. ·Nous nous réservons le droit d’apporter toutes modifications sans préavis. · Wijzigingen voorbe- houden.
  • Page 2: Mounting Instruction

    R2170 - R2172 Page 2/12 2021-02-19 Mounting Instruction Please read and carefully follow these instructions. Find the product number on the product label and ensure that these assembly instructions match your product. WARNING: Failure to comply with these instructions may result in accidents involving serious personal injury or the product being damaged.
  • Page 3 R2170 - R2172 Page 3/12 2021-02-19 Monteringsvejledning Sørg for at læse og følge disse anvisninger omhyggeligt. Se produktnummeret på produktmærkaten, og kontroller, at denne monteringsvejledning gælder for dit produkt. ADVARSEL! Hvis disse anvisninger ikke følges, kan det medføre ulykker og eventuel alvorlig personskade eller beskadigelse af produktet.
  • Page 4 R2170 - R2172 Page 4/12 2021-02-19 Montageanleitung Bitte lesen Sie diese Hinweise sorgfältig und folgen Sie ihnen. Suchen Sie die Produktnummer auf dem Produktetikett und versichern Sie sich, dass diese Montageanleitung für Ihr Produkt bestimmt ist. ACHTUNG: Ein Nichtbeachten dieser Hinweise kann zu Unfällen mit ernsthaften Personenschäden oder zu Produktschäden führen.
  • Page 5: Notice De Montage

    R2170 - R2172 Page 5/12 2021-02-19 Notice de montage Veuillez lire attentivement et respecter la présente notice de montage. Repérez la référence du produit sur l’étiquette et assurez-vous que la présente notice de montage correspond à votre produit. ATTENTION : le non-respect de cette notice peut entraîner des accidents induisant des blessures corporelles graves ou l’endommagement du produit.
  • Page 6 R2170 - R2172 Page 6/12 2021-02-19 Montage-voorschrift Lees deze montage-voorschrift grondig door en volg de aanwijzingen nauwkeurig. Controleer het productnummer op het productlabel en verzeker u ervan dat deze montage-voorschrift past bij uw product. WAARSCHUWING: Als de montage niet volgens deze handleiding wordt uitgevoerd, kan dit ernstig persoonlijk letsel of schade aan het product tot gevolg hebben.
  • Page 7 R2170 - R2172 Page 7/12 2021-02-19 Monteringsanvisning Läs och följ dessa instruktioner noga. Leta upp produktnumret på produktens etikett och kontrollera att dessa monteringsan- visningar gäller denna produkt. VARNING: Om inte anvisningarna följs kan detta resultera i olyckor såsom allvarliga personskador eller skador på...
  • Page 8 R2170 - R2172 Page 8/12 2021-02-19 Monteringsveiledning Les og følg disse instruksjonene nøye. Finn produktnummeret på produktetiketten, og kontroller at disse monterings- veiledningene stemmer overens med produktet. ADVARSEL: Hvis disse instruksjonene ikke overholdes, kan det føre til ulykker med alvorlig personskade eller skader på...
  • Page 9: Instrucciones De Montaje

    R2170 - R2172 Page 9/12 2021-02-19 Instrucciones de montaje Lea y preste atención a estas instrucciones. Busque la referencia del producto en la etiqueta y asegúrese de que estas instrucciones de montaje son las correctas. ADVERTENCIA: No respetar estas instrucciones puede dar lugar a accidentes, lesiones personales graves o daños al producto.
  • Page 10 R2170 - R2172 Page 10/12 2021-02-19 LA1307 LA1309 Pressalit Telephone: +45 87 88 87 88 Pressalitvej 1 Telefax: +45 87 88 87 89 DK 8680 Ry E-mail: pressalit@pressalit.com Danmark Web: www.pressalit.com...
  • Page 11 R2170 - R2172 Page 11/12 2021-02-19 Mounting instruction Montage-voorschrift Monteringsvejledning Monteringsanvisning Montageanleitung Monteringsveiledning Notice de montage Instrucciones de montaje Subject to alteration without further notice · Ret til ændringer forbeholdes · Recht auf Änderungen sind vorbehalten Nous nous réservons le droit d’apporter toutes modifications pour l’amélioration de nous produits sans préavis · Wijzigingen voorbehouden Rätten till ändringar förbehålles ·...
  • Page 12 R2170 - R2172 Page 12/12 2021-02-19 R2170 5 5 0 2 1 . 6 1 5 2 R2172 2 1 . 6 5 5 0 1 5 2 Pressalit Telephone: +45 87 88 87 88 Pressalitvej 1 Telefax: +45 87 88 87 89...
  • Page 13 Nous nous réservons le droit d’apporter toutes modifications pour l’amélioration de nous produits sans préavis · Wijzigingen voorbehouden Rätten till ändringar förbehålles · Vi forbeholder oss rett til endringer · Salvo variaciones Pressalit Care Telephone: +45 87 88 87 88...
  • Page 14 IEC 60601-1 and IEC 60364-7, as well as any locally applicable standards. WARNING: Ensure that the voltage of the local mains supply to be connected is compliant with that stated on the label on the product. Pressalit Care Telephone: +45 87 88 87 88...
  • Page 15 Sørg for at installere produktet et sted med nem adgang til produktet og tilstrækkelig plads til at justere det. Pressalit Care Telephone: +45 87 88 87 88...
  • Page 16 Dieses Produkt wurde für die Nutzung in feuchter Umgebung wie z. B. in Badezimmern oder Waschräumen entwickelt. Es darf nur in einer Umgebung verwendet werden, die dem Schutzgrad IP entspricht. Achten Sie darauf, dass der Aufstellort und dessen Umgebung die folgenden Betriebsparameter des Produkts erfüllt: Pressalit Care Telephone: +45 87 88 87 88...
  • Page 17 Sollte das Produkt nicht funktionieren, prüfen Sie, ob die Kabel korrekt angeschlossen sind und der Stromkreislauf intakt ist. Sie finden eine detaillierte Anleitung zur Fehlerbehebung in der Gebrauchs- und Pflegeanleitung. Wenden Sie sich an Ihren Pressalit-Vertreter, falls Sie Hilfe bei der Installation des Produkts benötigen. Pressalit Care Telephone: +45 87 88 87 88...
  • Page 18 IP adaptée à l'emplacement de la prise en fonction de l'humidité. Le produit peut également être directement câblé sur l'alimentation secteur. ATTENTION : assurez-vous que le circuit du côté alimentation secteur est isolé de l'alimentation lors du raccordement du produit au secteur. Pressalit Care Telephone: +45 87 88 87 88 Pressalitvej 1...
  • Page 19 Milieufactor Gebruiksbereik Temperatuur 5°C tot 40°C Relatieve vochtigheid 20% tot 90% @ 30°C (condensvrij) Atmosferische druk 700 tot 1060 hPa Pressalit Care Telephone: +45 87 88 87 88 Pressalitvej 1 Telefax: +45 87 88 87 89 DK 8680 Ry E-mail: pressalit@pressalit.com...
  • Page 20 De gebruiks- en onderhoudshandleiding van het product bevat een meer gedetailleerde gids voor het oplossen van problemen. Neem contact op met uw Pressalit-dealer als u hulp nodig hebt bij het installeren van het product. Pressalit Care Telephone: +45 87 88 87 88...
  • Page 21 VARNING: Produkten måste anslutas till elnätet och jordas av auktoriserad elektriker enligt IEC 60601-1 och IEC 60364-7, liksom enligt eventuella lokala regler. VARNING: Kontrollera att det lokala elnätets spänning överensstämmer med den spänning som anges på produktens etikett. Pressalit Care Telephone: +45 87 88 87 88 Pressalitvej 1...
  • Page 22 å unngå ledningsbåret emisjon. Når du velger installeringssted, må du sørge for at det er tilstrekkelig plass for flytting av – og tilgang til – produktet. Pressalit Care Telephone: +45 87 88 87 88...
  • Page 23 Este producto ha sido diseñado para el uso interior en estancias húmedas, como baños o lavabos. Su uso sólo es posible en entornos correspondientes al grado de aislamiento IP. Asegúrese de que las condiciones del lugar de instalación no superen los límites de funcionamiento del producto: Pressalit Care Telephone: +45 87 88 87 88...
  • Page 24 Las instrucciones de uso y mantenimiento del producto incluyen una guía de resolución de problemas más detallada. Si necesita ayuda para instalar el producto, póngase en contacto con su distribuidor de Pressalit. Pressalit Care Telephone: +45 87 88 87 88...
  • Page 25 (NL) Bevestigingsmateriaal voor de wand niet inbegriepen. (SV) Skruvar för väggmontering ingår ej (NO) Skruer for veggmontering er ikke inkludert (ES) Los tornillos montajes para la pared no están incluidos. Pressalit Care Telephone: +45 87 88 87 88 Pressalitvej 1 Telefax: +45 87 88 87 89...
  • Page 26 à l'aide d'une buse de 12,5 mm au maximum, boquilla de hasta 12,5 mm sin sufrir efectos dans n'importe quel sens n'aura aucun effet perjudiciales. préjudiciable. Pressalit Care Telephone: +45 87 88 87 88 Pressalitvej 1 Telefax: +45 87 88 87 89...
  • Page 27 LA8931 D. M6 x 10 A. M4 x 12 B. M6 x 10 E. M6 x 16 C. M8 x 25 Pressalit Care Telephone: +45 87 88 87 88 Pressalitvej 1 Telefax: +45 87 88 87 89 DK 8680 Ry E-mail: pressalit@pressalit.com...
  • Page 28 ⁄ ⁄ ⁄ 11 ⁄ 11 ⁄ 1 ⁄ 11 ⁄ 7 ⁄ Ø32 Ø1 17 ⁄ Pressalit Care Telephone: +45 87 88 87 88 Pressalitvej 1 Telefax: +45 87 88 87 89 DK 8680 Ry E-mail: pressalit@pressalit.com Danmark Web:...
  • Page 29 R4870 - R4875 2019-10-31 · Page 17/21 6 0 2 3 5 0 2 7 5 4 5 2 1 7 ⁄ Ø12 R2170 Mounting instruction Montage-voorschrift Monteringsvejledning Monteringsanvisning Montageanleitung Monteringsveiledning Notice de montage Instrucciones de montaje Subject to alteration without further notice · Ret til ændringer forbeholdes · Recht auf Änderungen sind vorbehalten Nous nous réservons le droit d’apporter toutes modifications pour l’amélioration de nous produits sans préavis ·...
  • Page 30 LA8930 LA8930 Ø 3 2 N.B. LA8932 LA8932 ⁄ ) , 5 ( 1 Ø 3 5 N.B. Pressalit Care Telephone: +45 87 88 87 88 Pressalitvej 1 Telefax: +45 87 88 87 89 DK 8680 Ry E-mail: pressalit@pressalit.com Danmark Web: www.pressalitcare.com...
  • Page 31 LA8931 A. M4 x 12 B. M6 x 10 C. M8 x 25 D. M6 x 10 E. M6 x 16 Pressalit Care Telephone: +45 87 88 87 88 Pressalitvej 1 Telefax: +45 87 88 87 89 DK 8680 Ry E-mail: pressalit@pressalit.com...
  • Page 32 D. M6 x 10 E. M6 x 16 max 150 kg 21 ⁄ (330 lbs) 36 ⁄ 28 ⁄ 7 ⁄ Pressalit Care Telephone: +45 87 88 87 88 Pressalitvej 1 Telefax: +45 87 88 87 89 DK 8680 Ry E-mail: pressalit@pressalit.com...
  • Page 33 R4870 - R4875 2019-10-31 · Page 21/21 R4870 - 75 Pressalit Care Telephone: +45 87 88 87 88 Pressalitvej 1 Telefax: +45 87 88 87 89 DK 8680 Ry E-mail: pressalit@pressalit.com Danmark Web: www.pressalitcare.com...
