Summary of Contents for iBeeCool iBC-129P
- Page 1 Self-Contained Ice Machines & Ice Machines with Bins Service Manual Models: iBC-129P, iBC-219P, iBC-101B, iBC-289, iBC-350P, and iBC-500P PLEASE READ CAREFULLY BEFORE SET-UP, OPERATION, AND MAINTENANCE...
- Page 2 Table of Contents R290 Refrigerant Properties R290 Ice Machine 4 - 5 Maintenance Checklist 6 - 7 Maintenance S.O.P 8 - 11...
- Page 3 R290 REFRIGERANT PROPERTIES CAUTION: R290 refrigerant is highly flammable. KEEP AWAY FROM HEAT AND FLAME. IGNITION POINT IS 450° Celsius. CAUTION: R290 refrigerant has suffocating and anesthetizing effects. R290 is a hydrocarbon refrigerant similar to R600a for household refrigerators. The mass use of hydrocarbon refrigerants began as early as the 1930s, but they began to be widely used in household refrigerators and other products in the early 2000s.
- Page 4 This is equivalent to the charging volume of about 10 lighters. Special Parts All electrical elements of the iBeeCool’s R290 ice machines (i.e. iBC-129P, iBC-219P, iBC-101B, iBC-289, iBC-350P, and iBC-500P), including compressor, relay, switch and controller are explosion-resistant parts that passed tests and are permitted to be used in equipment using flammable coolant.
- Page 5 Water System Diagram Refrigeration System Note: R290 refrigeration system has no service valve for safety reasons; needle charging valve is required Note: When charging refrigerant for the system: 1. Discharge refrigerant from the system 2. Vacuum the refrigeration system 3. Charge the system...
- Page 6 MAINTENANCE CHECKLIST Environment ❏ For products using R290 refrigerant, room for use and maintenance needs to be greater than 15 square meters. ❏ “Danger: No Smoking, No Open Flame” signs are hung up. Flame or heat within 2 metres of the maintenance area is to be prevented. No smoking. ❏...
- Page 7 ❏ All mobile phones and electronics are turned off. Equipment ❏ Portable R290 tester ❏ Vacuum pump ❏ Dual-head charging meter (mechanical or digital) ❏ Charging tube ❏ Needle charging valve ❏ Refrigerant connection tube ❏ Electronic scale with a precision of 0.5g ❏...
- Page 8 MAINTENANCE S.O.P BEFORE OPERATION STEP PRECAUTION Use a handheld leak tester and wear a Wear the flammable gas tester flammable gas tester to check ice throughout the maintenance period. machines of any R290 refrigerant leaks. Make sure the maintenance area is Avoid sparks due to static electricity well-ventilated.
- Page 9 keep discharging for 3-5min. Remove the refrigerant discharging tube from the pressure gauge and use the connector of the vacuum pump to exhaust gas to the outside. Turn on the vacuum pump for at least 10 minutes. Remove the needle valve from the Generally, the dry filter should be process pipe and cut off the parts that replaced with the parts, especially for...
- Page 10 pressure gauge and turn off the vacuum pump. Maintain pressure for 20 minutes and make sure there is no leak. INJECTING REFRIGERANT STEP PRECAUTION Remove the vacuum pump from the charging meter. Connect the refrigerant cylinder to the charging meter with the connection pipe as short as possible.
- Page 11 pipe on two points; snap the process pipe on the clamped point farther away from the compressor and seal it by brazing. Take off the magnet and mount the defrosting valve coil on the original position. Turn on the ice machine for commissioning at least 20 minutes after charging.
