Summary of Contents for Quality Water For Less Fleck 2510
- Page 1 Fleck 2510 Metered Water SoF tener › I n s ta l l at I o n G u I d e v1.0...
- Page 2 › P r e fac e Thank you for your purchase of a new water softener with Fleck 2510 SXT Meter Control Valve from QualityWaterForLess.com! We have put together these instructions as reference and to be used as It is always recommended that a licensed plumber perform all instal- general installation guidelines.
- Page 3 Tank Size, Salt Setting, and Salt Grid Table Page 7 Pre-Installation and Filling the Tank Page 8 Installing the Fleck 2510 SXT Valve onto the Tank Page 9 Plumbing the Fleck 2510 SXT Valve into your Home Page 10 Making the Brine Tank Connection...
- Page 4 › G e n e r a l r e f e r e n c e Please take a moment to review this page in order to d r a I n familiarize yourself with these four ports on the valve and the programming values below.
- Page 5 › M e c H a n I c a l P r o G r a M s e t t I n G I n P u t Va l u e If you have a mechanical meter valve, here are your Gc - Gal caPacItY If you have an SXt valve, 00 Gallons...
- Page 6 1 › c a l c u l at I n G Yo u r H a r d n e s s l e V e l Water test: Before start-up, it is crucial that you know your water’s HardneSS and Iron levels in order to set up your unit properly.
- Page 7 c - unIt caPacItY: section In the first column, identify the containing your softener tank size and then within this H - compensated Hardness c - capacity section, find the pertaining to your level. Then look under the column c - unit capacity in the table on page 4 or 5.
- Page 8 › P r e - I n s ta l l at I o n Before assembly of your new system, be sure that the following conditions have been met for the place- ment of your system: • Level, firm surface, such as concrete, on which • Access to the water main coming into your to place the softener tank and salt tank (also home.
- Page 9 Valve as seen in Figure 9-E and then place the of the Fleck 2510 SXT Meter Valve as shown in valve onto the top of the tank, being sure that the...
- Page 10 3) Locate the plumbing adapter that was shipped 4) Using the included silicone lubricant packet, lu- with your system and disassemble the plumbing bricate the o-rings on the Fleck 2510 SXT Meter adaptor clips as shown in Figure 10-A Valve as shown in Figure 10-B...
- Page 11 2) Next, connect this prepared end of the tubing insert, and brine line screen to one end of the to the Fleck 2510 SXT Meter Valve as shown in included brine tubing as shown in Figure 11-A. Figure 11-B. Tighten the nut to the valve using Be sure that the tapered side of the black a wrench until snugly in place.
- Page 12 7) If you ever need to remove the tube, evenly press on 8) Finally, use ½” inner diameter (I.D.) tubing to connect both sides of the grey ring surrounding the tube and the drain barb fitting on the brine tank to a floor drain Be sure to recut pull out as shown in Figure 12-A.
- Page 13 6 › d r a I n c o n n e c t I o n 1) Locate the barbed fitting and use Teflon tape to 2) Move to the rear of the Fleck 2510 SXT control wrap the threading as shown in Figure 13-A.
- Page 14 7 › P r o G r a M M I n G t H e f l e c k 2 510 s x t Va lV e 1) Loosen the screw on the front of the valve and 2) To begin programming, first plug in your remove the valve front cover to expose the SXT 2510SXT Valve to a nearby wall outlet.
- Page 15 ct / Fd nt / ---1 7) The display should now show as shown 8) The display should now show as shown in Figure 15-A. This indicates Control Type Meter in Figure 15-B. This indicates the number of tanks Delayed Mode. Do not change this value and press is one.
- Page 16 do / 14 rt / 2:00 13) The display should now show as shown 14) The display should now show in Figure 16-A. This indicates the Day Override is shown in Figure 16-B. This indicates the system 14 days; the system will regenerate in 14 days if will regenerate at 2:00 AM following the day the the meter has not measured water consumption water consumption has passed the calculated...
- Page 17 FM / t0.7 19) The display may now show as shown 20) The system will now exit Master Programming mode and the display should now show the time in Figure 17-A. This indicates Flow Meter type of day followed by the number of gallons remain- 3/4”...
-
Page 18: Initial Start-Up
› c o n G r at u l at I o n s Your new softener with Fleck 2510 SXT Meter Valve is now properly installed and programmed! Please maintain your system by keeping the softener plugged-in and always keep your brine tank filled with salt to at least above the water level.
