U-Prox SL maxi Quick Start Manual

U-Prox SL maxi
VERSATILE READER
• mobile credentials
• NFC and 2.4 GHz radio
• adjustable 2.4 GHz distance (0.1 - 15 m)
• Mifare Plus SL1/SL3 and Mifare Classic
• supports multiple formats of 125 kHz RFID
• smartphone adjustable
• adjustable Wiegand interface
• convinient and safe
• simple and convenient installation
• IP65 degree of protection
The adjustable versatile SmartLine (SL) reader for mobile credentials and
proximity identifiers in conjunction with the U-Prox Mobile ID application
and U-Prox IDs allow any access control system to use smartphones as
access system credentials.
U-Prox ID
Digital personal mobile credential. It is processed and stored in the user's
smartphone using the U-Prox Mobile ID application. It can be transferred
over NFC and/or 2.4 GHz radio between the reader and the smartphone.
NFC
via for Android only
Read range 2-5 cm. Recommended for double-sided doors and turnstiles.
2.4 GHz radio
via for Apple and Android
Reader supports 3 operation modes for smartphones with U-Prox ID:
• "Door-Proximity" – 10-20 cm, reader activates by built-in IR sensor.
Recommended for double-sided doors and turnstiles
• "Door" - up to 60-70 cm
• "Barrier/Gate" - adjustable range of interaction from 1 to 15 m.
Mifare® и Mifare®Plus
Operates with ISO14443A identifiers, supports SL1 and SL3 modes for
Mifare®Plus. Read range — up to 5 cm.
Reads encrypted identifiers with static or diversified key and with an
arbitrary card number.
Simultaneous use of five encryption profiles.
RFID, 125 kHz
Supports RFID 125 kHz - EmMarine and other formats.
Easy connection
Seamless and easy connection to existing and new access systems, due to
the Wiegand 26, 32, 34, 37, 40, 42, 56, 58, 64 bit interfaces, Wiegand with
automatic selection, RS-232 and TouchMemory supports.
Integration
RS-232 protocol for integration into arbitrary systems.
Mobile Apps
Free mobile application U-Prox Mobile ID
mobile credential U-Prox ID between the reader and the smartphone.
With the free mobile application
completely adjusted — from the indication to the encryption modes.
The reader is supplied without the engineering password for programming
specified. To connect and (re) set the password — connect inputs D0
(green) and D1 (white) with each other and apply power to the reader.
U-Prox SmartLine
NEW GENERATION OF READERS
receives, stores and transmits
U-Prox Config, the reader can be
