USER MANUAL AND ASSEMBLY

CUSTERS® Amigo Mobile

Maximum load:

Maximum platform height:

9505790001NL May 2020

CUSTERS HYDRAULICA B.V.

Smakterweg 33

5804 AE VENRAY NL

P.O. Box 22

5800 AA VENRAY NL

info@custers.nl

Scaffold Tower

In accordance with EN1004

Telephone

Fax

Website

200 kg/m

4.25 metres

: +31 (0) 478 55 30 00

: +31 (0) 478 55 30 10

: www.custers.nl

Table of Contents

Need help?

Do you have a question about the Amigo Mobile Scaffold Tower and is the answer not in the manual?

Questions and answers

Summary of Contents for CUSTERS Amigo Mobile Scaffold Tower

Page 1 Custers Hydraulica B.V. Venray NL USER MANUAL AND ASSEMBLY CUSTERS® Amigo Mobile Scaffold Tower In accordance with EN1004 Maximum load: 200 kg/m Maximum platform height: 4.25 metres 9505790001NL May 2020 CUSTERS HYDRAULICA B.V. Smakterweg 33 5804 AE VENRAY NL Telephone : +31 (0) 478 55 30 00 P.O.
Page 2: Table Of Contents
No part of this publication may be copied and/or multiplied and/or made public by means of photocopy/ print/ microfilm/ CD/ DVD/ Internet or any other means without the prior express written permission of the publisher Custers Hydraulica B.V. 7-jan- www.custers.nl...
Page 3: Introduction
Custers Hydraulica B.V. Venray NL 1. Introduction The Custers® Amigo mobile scaffold tower is part of a wide range of aluminium scaffolding variants. The Custers® Amigo mobile scaffold tower complies with the EN1004 standard provided it is assembled according to the instructions of this manual.
Page 4: Warranty And Liability
Custers Hydraulica B.V. Venray NL 2. Warranty and liability Custers provides a warranty for material and manufacturing defects for up to 12 months after delivery. The warranty means that we will repair the defects at our own expense, or - at our sole discretion - take back all or part of the delivered goods and replace them with a new delivery.
Page 5: Safety Instructions
Custers Hydraulica B.V. Venray NL 5. Safety instructions 5.1. Check before assembly Check whether the people in charge of assembling the tower are sufficiently qualified and check whether the place where the scaffolding is to be erected, is safe and suitable.
Page 6: Lifting The Parts
Custers Hydraulica B.V. Venray NL 5.4. Lifting the parts Lifting parts for higher sections must be done by passing the parts from platform to platform. The Amigo floor boards have extendable arms. All parts can be hung on these arms.
Page 7 Custers Hydraulica B.V. Venray NL Figure 2 Dimensions in mm. 7-jan- www.custers.nl...
Page 8: Handrail Frames
Custers Hydraulica B.V. Venray NL Figure 3 If the mobile scaffold tower is placed against a wall, do not remove the support leg/arch, but turn it parallel to the wall. If the mobile scaffold tower is placed in a corner, remove the inner support leg and turn the outer two parallel to the wall.
Page 9: Assembly Instructions
6. Assembly instructions Figure 5 1. In transport position, the Amigo mobile scaffold tower can be used as a trolley. 2. Remove all materials from the trolley and put them aside. Leave the floor and one of the two small handrail frames.
Page 10 Custers Hydraulica B.V. Venray NL Figure 7 5. Couple two four-stage-frames and secure them with the supplied locking pins. 6. Then place these on the two four-stage frames. Figure 8 7. Place a floor board on the last rung of the second four-stage frame.
Page 11 Custers Hydraulica B.V. Venray NL Figure 9 9. Place the second handrail frame as indicated in the picture. Do this by pressing the frame with its claws from the inside to the outside on the uprights. Figure 10 10. Again couple two four-stage-frames to each other and secure them with the locking clips.
Page 12 Custers Hydraulica B.V. Venray NL Figure 11 14. Place the two coupled frames and secure them with locking clips. 15. Hang the folding toeboard on the arm. 16. Remove the lower floor and hang it on the same arm as the one of the toeboard.
Page 13 Custers Hydraulica B.V. Venray NL Figure 12 18. Climb on the first floor and place a handrail frame between the fifth and seventh rung from the platform floor. 19. Place the floor on the eighth rung and fold out the arms.
Page 14: Use Of The Mobile Scaffold Tower
Custers Hydraulica B.V. Venray NL 7. Use of the mobile scaffold tower Prior to each use, you should verify that: The base (e.g. the expansion legs, braking castors) of the mobile scaffold tower is correct; The overall construction is correct;...
Page 15: Moving The Mobile Scaffold Tower
Custers Hydraulica B.V. Venray NL 8. Moving the mobile scaffold tower: Check the surroundings for obstacles located around the route to be taken by the mobile scaffold tower. Provide a clean surface, check the route for potholes/ unevenness / cables/ irregularities/ traffic/ passers-by.
Page 16: Disassembly Of The Mobile Scaffold Tower
Custers Hydraulica B.V. Venray NL 9. Disassembling the mobile scaffold tower Disassembling the mobile scaffold tower takes place in reverse order. Start at the top with removing the toeboards. Disassemble the mobile scaffold tower from top to bottom. Do not throw the parts to the floor! 7 January 2021 www.custers.nl...
Page 17: Maintenance Of The Mobile Scaffold Tower
Custers Hydraulica B.V. Venray NL 10. Maintenance of the mobile scaffold tower All parts, especially the moving parts and the welds, must be checked regularly, but at least once a year, for wear and damage. Missing and broken parts must be replaced.
Page 18: Guidelines For Use, Transport And Storage
Custers Hydraulica B.V. Venray NL 11. Guidelines for use, transport and storage Scaffolding parts must be handled and transported with care to prevent damage. Storage must be arranged in such a way that only undamaged parts in the correct amounts become available for erecting the tower.
Page 19: Parts
Custers Hydraulica B.V. Venray NL 12. Parts 12.1. List of parts Figure 13 1. Swivel castor 2. Four-stage-frame 3. Amigo adjustable stabiliser. 4. Amigo strut frame 1.20m (base). 5. Locking clip 6. Amigo platform 1.20m with hatch. 7. Amigo folding toeboard.
Page 20: Summary Table
Summary table The table below shows which parts are necessary for erecting a scaffolding up to a certain height. Make sure that these parts are indeed present. Composition table Custers Amigo mobile scaffold tower Working height [m] 3 4 5...
