OPERATOR'S
MANUAL
WOOD ROUTER TABLE
MODEL: WR-32
Baileigh Industrial Holdings LLC,
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: 920.684.4990
Fax: 920.684.3944
sales@baileigh.com
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL
HOLDINGS LLC, IS PROHIBITED. Baileigh Industrial Holdings LLC, does not assume and hereby disclaims any
liability for any damage or loss caused by an omission or error in this Operator's Manual, resulting from accident,
negligence, or other occurrence.
Rev. 05/2020
© 2020 Baileigh Industrial Holdings LLC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WR-32 and is the answer not in the manual?

Questions and answers

Related Manuals for Baileigh WR-32

Summary of Contents for Baileigh WR-32

  • Page 1 REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL HOLDINGS LLC, IS PROHIBITED. Baileigh Industrial Holdings LLC, does not assume and hereby disclaims any liability for any damage or loss caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurrence.

  • Page 2: Table Of Contents

    Table of Contents MENU TREE ........................1 CAUTIONS ........................2 1. Local Files ....................... 2 2. USB Files ......................... 2 3. Operations ....................... 3 4. Oper Param ......................5 5. Mfr Param ........................ 9 6. Param Upkeep ....................... 14 7. System Upkeep ..................... 14 8.

  • Page 3: Menu Tree

    MENU TREE The normal operation screen will display is a combination of rows and columns. X, Y, and Z are each in a row with their coordinate locations relative to the last set workpiece coordinate. The right or 3 column is a display of the active operating conditions and settings. When the machine is not moving it will display “Idle”.

  • Page 4: Cautions

    • STOP! These settings are not normally changed. DO NOT change these settings unless asked to by an authorized Baileigh Industrial service technician. NOTICE: While some of these settings are intended to be adjusted by the operator to tune the operation to the material and cut being performed, other settings are not to be changed by the operator.

  • Page 5: Operations

    3. Operations STOP! The parameters shown in the OPERATIONS menu below should only be changed by an experienced operator. Failure to do so may result in incorrect machine motions and possible machine damage. Take notes and if possible practice on scrap material to get the settings which will produce the best results.
  • Page 6 G58 WCS G59 WCS Select by [OK] key File <File Name> Rows Columns RowSpace 50.00 7 Array Process ColSpace 50.00 Delay ----Load Now-- 1:X 0.00 Y 0.00 Z 0.00 2:X 0.00 Y 0.00 Z 0.00 3:X 0.00 Y 0.00 Z 0.00 4:X 0.00 Y 0.00 Z 0.00 5:X 0.00 Y 0.00 Z 0.00 8 Origin List...

  • Page 7: Oper Param

    4. Oper Param STOP! The parameters shown in the OPER PARAM menu below should only be changed by an experienced operator. Failure to do so may result in incorrect machine motions and possible machine damage. Take notes and if possible practice on scrap material to get the settings which will produce the best results.
  • Page 8 Unit: Spec.: Interval of cycle 3 Cycle Interval process Value: 0 Unit: ms Spec.: Enable cycle SPDL off in the SOff In Interval process interval ● Value: No ► Unit: Spec.: G73_G83 retract 7 G73_G83Retrac distance 0.000mm Value: 0.000 Unit: mm Spec.: Ignore F code 8 Ignore F Code...
  • Page 9 ► Value: Yes ● Unit: Spec.: Process shape Process shape 4 Shape Process separately separately ● Value: No ► Unit: Spec.: Enable bottom Enable bottom 5 Bottom Process machining machining ● Value: No ► Unit: Spec.: Adopt metric size Metric Size Adopt metric size ●...
  • Page 10 Value: 0.025 Unit: mm Spec.: 4 Process Depth Process depth -1.000mm Value: -1.000 Unit: mm Spec.: Tool magazine 1 ATC Capacity capacity Value: 1 Unit: Spec.: 2 CurrentToolNo. Set current tool No. Value: 1 Unit: Tool Offset 1 X Axis: 0.000 3 Tool Offset 1 Tool1...

  • Page 11: Mfr Param

    • STOP! These settings are not normally changed. DO NOT change these settings unless asked to by an authorized Baileigh Industrial service technician. NOTICE: While some of these settings are intended to be adjusted by the operator to tune the operation to the material and cut being performed, other settings are not to be changed by the operator.
  • Page 12 Value: Unit: Spec.: Length of short 9. SpdLmt Length Seg.SpdLmt 0.500mm Value: 0.500 Unit:mm Spec.: 0:Not 1:Z single 10. Z Down Option 2:XYZ all Value: Unit: Spec.: 11. ZPlungeCutSpd Plunge Spd along Z 300.000mm/min Value: 300.000 Unit: mm/min Spec.: Reference circle 12.
  • Page 13 Y Axis: 930.000 Z Axis: 0.000 StrkLowerLmt (mm) X Axis: 0.000 2. StrkLowerLmt Y Axis: 0.000 Z Axis: -100.000 Speed (mm/min) X Axis: 2800.000 1. REFP Speed Y Axis: 2800.000 Z Axis: 1800.000 Homing direction X Axis: Negative 2. REFP Dir Y Axis: Negative Z Axis:...
  • Page 14 equivalent Value: 0.00600 Unit:deg/p Spec.: 3. mm As Unit Use mm as unit Value: Unit: Spec.: * Rotary workpiece 4. Rev.WorkRadius radius 10.000mm Value: 10.000 Unit:mm Spec.: Takeoff speed of 5. Rotary Takeoff rotary Y 0.291rad/s Value: 0.291 Unit:rad/s Spec.: 6.
  • Page 15 Spec.: 13. Arc Tolerance Arc Radius Tolerance 2.000mm Value: 2.000 Unit:mm Spec.: 14. Forward Seg Prospect. Segments Value: Unit: Spec.: Cancel REF Sign after 15. Sign of BKREF E-stop Value: Unit: Spec.: 16. Safety Height * Safety height 10.000mm Value: 10.000 Unit:mm Spec.:...

  • Page 16: Param Upkeep

    6. Param Upkeep STOP! The parameters shown in the PARAM UPKEEP menu below should only be used by an experienced operator. Failure to do so may result in incorrect machine motions and possible machine damage. 1 Backup Params OK, or ESC 2 Restore Backup OK, or ESC 3 Factory Params...

  • Page 17: Diagnosis

    10 Delete Info OK, or ESC Old PWD: New PWD: 11 Modify Code Confirm: --------------Modify--- 8. Diagnosis STOP! The parameters shown in the DIAGNOSIS menu below should only be used by an experienced operator. Failure to do so may result in incorrect machine motions and possible machine damage.
  • Page 18 0 1 2 3 4 5 6 7 º º º º º º º • 4 Inport Diag 8 9 A B C D E F º º • • º º º º 0 1 2 3 4 5 6 7 º...
  • Page 19 NOTES...
  • Page 20 BAILEIGH INDUSTRIAL HOLDINGS LLC 1625 D , WI 54220 UFEK RIVE ANITOWOC : 920. 684. 4990 F : 920. 684. 3944 HONE www.baileigh.com BAILEIGH INDUSTRIAL HOLDINGS LTD. U WIFT OINT WIFT ALLEY NDUSTRIAL STATE UGBY , CV21 1QH U IDLANDS...
