Summary of Contents for MAKINA S7 PRO-PID
- Page 1 User manual MAKINA S7 PROPID Makina Espresso Machines Veemarkt 36D 1019 DD Amsterdam The Netherlands Contact us E. info@makinaespressomachines.com W. www.makinaespressomachines.com T. 0031614577467 Company details KVK 62515152 BTW NL253855639B01 IBAN NL63ABNA0247389293...
- Page 2 If you have further questions or if you require more information, please contact us or your MAKINA authorized dealer before starting up the espresso coffee machine. Please keep the instruction manual for future reference.
- Page 3 Index Index Used symbols 1. Introduction 2. Product delivery 3. General advice 3.1 General safety notes 3.2 Proper use 4. Machine description 4.1 Machine parts 4.2 Technical data 4.3 Specifications 5. Installation 5.1 Preparing for installation 5.2 Electrical connection 5.3 Water supply connection 5.3.1 Machine in use with water tank 5.3.2 Machine in use with direct water connection 5.3.2.1 Advice for using the machine with direct water connection...
-
Page 4: Used Symbols
The manufacturer is free to modify this manual without updating previous editions ● except for exceptional cases. 2. Product delivery The following is supplied as standard with the Makina S7 PROPID 1 portafilter with 1 spout ● 1 portafilter with 2 spouts ●... -
Page 5: General Advice
3. General advice 3.1 General safety notes Make sure that the local mains voltage corresponds with the information on the ● type sticker on the inside of the espresso machine's drip tray. The installation of the machine is to be carried out by authorized and qualified ●... -
Page 6: Proper Use
3.2 Proper use The MAKINA S7 PROPID is designed to be used for the preparation of coffee, hot water and steam only. The machine is intended for domestic and semi professional use. Use of the machine other than for the abovementioned purpose will void the warranty. The manufacturer cannot be held responsible for damage caused by the machine and is not liable for redress. -
Page 7: Machine Description
4. Machine description 4.1 Machine parts MAKINA S7 PROPID Image 1 Cup warming tray. The water tank under the the tray) Steam valve lever Pump pressure gauge Boiler pressure gauge Steam wand Control lamp red On/off switch Control lamp on/off green Hot water valve lever 10. -
Page 8: Technical Data
4.2 Technical data Voltage: EU 230 V Frequency: EU 50 Hz Power: 1,500 W 1800 W Water tank capacity: 2.1 liter Boiler capacity: 3.0 liter Weight: 28 kg Measurements: 425 mm height / 510 mm deep / 290 mm wide 4.3 Specifications 1. -
Page 9: Preparing For Installation
20. Stainless steel adjustable feet 21. Ergonomic design wood portafilters. 22. Original E61 brew group. Complete wood kit. 24. Quick heat. In 9 min ready to serve. 25. Soft & easy closing removable drip tray. 26. Optional water drain in the drip tray. 27. -
Page 10: Electrical Connection
Check and verify that the outlet power supply voltage is the same shown on the ● rating-plate of the appliance. The customer has to protect the power outlet used to supply the appliance by ● means of a safety switch system, complying with the standards and laws in force. ... -
Page 11: Water Supply Connection
5.3 Water supply connection 5.3.1 Machine in use with water tank When using the machine with a water tank, please turn the valve under the machine facing the rear of the machine (image 2. Place the switch under the machine into position 0 (image 3. Image 2 Valve in position for operating the machine with water tank (facing the rear of the machine) - Page 12 2 bar. Important Always use an original hose. Original hoses can be purchased from us or at your MAKINA specialized dealer. Make sure that the machine is on a water-resistant surface in case of water spillage or leakage.
-
Page 13: First Use
Important Do not leave the machine switched on or unattended when not in use. ● Make sure to close the shut off valve of the water connection and to switch off ● the electric main switch or to disconnect the power plug when the machine is not in use. - Page 14 6.1.2 Alarms If the red signal lamp lights up, this means that the water tank is empty if the machine is in use with a water tank connection. All machine functions will be automatically blocked by an internal electronic device to prevent damage of the heating element. To reset normal working conditions, take the following actions: Turn off the main switch.
-
Page 15: Use Of The Machine
7. Use of the machine Important Please note that the portafilter, drip tray and water tank are not suitable for the dishwasher. 7.1 Standard use of the installed machine with water tank The switched off machine is put into operation as follows: Make sure that there is enough water in the water tank. - Page 16 Important Before preparing the first coffee, please rinse the machine by extracting about 35 water tank fillings from the brew group and the hot water wand. When the machine is switched off, more hot water can be dispensed. Important If you use large quantities of hot water through a water valve, please wait for the filled water to reach the desired temperature.
-
Page 17: Preparing Coffee
The Makina espresso machine S7 PROPID is able to provide large amounts of steam. Thanks to the generic 3 liter copper boiler and the powerful 1800 W heating element. The Makina S7 PROPID is a semi professional espresso coffee machine. It can prepare frothed milk within seconds. However, frothing milk needs some practice. -
Page 18: Frothing Milk
7.8 Frothing milk Push down the steam valve lever for a couple of seconds to release the condensation water in the steam wand. Push the steam valve lever to its original position. 2. Position the nozzle (at the end of the steam pipe) of the steam wand into the milk pitcher. You can decide the amount of milk up on your need (one cup or two cups). - Page 19 Warning: before performing tests and maintenance and replacing parts. DISCONNECT THE MACHINE FROM THE MAINS. 8.2 Weekly Backlash the machine every day (without espresso machine detergent), the group and shower plate must be cleaned every day, ONCE a week use a detergent in the blind filter: Put a half teaspoon of special espresso machine detergent in the blind filter and then insert it into the brew group.
-
Page 20: Troubleshooting
9.0 Troubleshooting Trouble Cause Solution The appliance doesn’t switch ON 1. Mains switch is OFF 1. Set mains switch ON 2. Machine switch is OFF 2. Set machine switch in pos. ON 3. Wrong connection to mains 3. Contact service for check Missing coffee delivery from 1.
