Z-8 EHT RFID Electronic Door Lock
with EM-Marine & HID ProxCard II & Atmel (T5557) reader (125 kHz)
and standalone controller
User Manual
1. OVERVIEW
Z-8 EHT lock consist of a wireless reader, a locking system and a controller powered by four 1.5V
AA batteries). From outside, the door opens by approaching with a card, and from inside, it's
enough to just turn the door handle.
Z-8 EHT locks have two operating modes.
- OFFICE MODE: Only cards in the lock's controller database can open the lock. With special
software, it is possible to limit card access by time of day and day of week
- HOTEL MODE: Considers the security and operation requirements of hotels, guest houses,
dorms, student campuses etc. Allows creating "Guest Cards", "Staff Cards", "Special Cards", which
are assigned specific access rights and offer protection against card cloning or loss.The Hotel
Mode operates only with special software.
2. SPECIFICATIONS.
- Work Frequency: ....................................................................................................125 kHz.
- Keys standards:............................................... EM-Marine, HID ProxCard II, Atmel (T5557).
- Maximum number of keys/cards: ................................................................................1364.
- Maximum Event Log capacity: ....................................................................................1000.
- Inbuilt NVRAM: .......................................................................................................Present.
- Reading Distance: ..................................................................................................2...4 cm.
- Standby mode current: ...............................................................................................30 µA.
- Power: ............................................................................................Four 1.5 V AA batteries.
- Audio-visual status indication: ........................................................buzzer signal, two LEDs.
- Door Unlock Duration settings:............................................................................... 0...220 s.
- Working ambient temperature: ...............................................+5...+40 °C (except batteries).
- Case material: ..............................................................................................Stainless steel.
- Case colours: ....................................................................................................Silver, Gold.
