GemVax & KAEL 5aver User Manual

Fire evacuation Mask
User's Guide
(Note)
Please remove the sealed sticker
on the mask for emergency situations only.
Portable emergency lighting
* No button for
a wall mounted set.
Light On/Off
(Brightness 100Lux)
Buzzer On/Off
A lantern is included in the set
(Portable / Wall Mounted)
Material configuration
of each part
Cover cap: PC
Canister: Acrylonitrile Butadiene
Styrene resin
Nose-Grip: Stainless steel / silicon
Mouthpiece: Urethane
Air shut-off cap: Urethane
Lantern: Acrylonitrile Butadiene
Styrene resin
How to use the mask
1. Preparation
Remove the sealed sticker by
snapping off the cover cap from
the main body. Then remove the
orange air shut-off cap.
2. Using the mask
Please detach the nose grip and
place it on your nose. The ring
should face towards you.
Bite the mouthpiece and breathe
into it.
3. Evacuation
Evacuate in a low stance, by cro-
uching and walking.
(Note) This product cannot be reused after opening.
5aver is an innovative Fire Evacuation Mask which
can be activated within 5 seconds and is equ-
ipped with a triple filter. It is used by biting the
mouthpiece and breathing. It filters many toxic
chemical substances including carbon monox-
ide(CO), a major cause of death in the event of fire.
5aver, using its proprietary absorbent triple filter
mask, it is designed to act as a personal life safety
device during evacuation.
Mask for emergency evacuation
The canister uses triple filer processing (pre filtering/ CO2 removal / after filtering).
A portable emergency lantern is included in the set (portable/Wall Mounted).
The Portable emergency lantern includes a lithium-ion battery (CR2).
To use the fire evacuation mask, please remove the sealed sticker
and take off the cover cap.
Please remove the plastic from the bottom of the lantern before use.
How to use the portable set
1. Preparation
① Separate the mask and lantern.
Remove the sealed sticker by sna-
pping off the cover cap from the main
body. Then remove the orange air shut
-off cap. ② Please pull the plastic from
the bottom of the lantern to activate
the battery.
2. Using the mask
Please detach the nose grip and place
it on your nose. The ring should face
towards you. Bite the mouthpiece and
breathe into it. Press the light button
and buzzer to work.
3. Evacuation
Carry the lantern and evacuate in a low
stance, by crouching and walking.
Cover-Cap
Nose-Grip
Mouthpiece
Canister
Air shut-off Cap
How to use a wall mounted set
1. Preparation
① Detach 5aver from the cradle. ② Se-
parate the mask and the lantern. Re-
move the sealed sticker by snapping off
the cover cap from the main body. Then
remove the orange air shut-off cap. ③
Please pull the plastic from the bottom
of the lantern to activate the battery.
2. Using the mask
Please detach the nose grip and place it
on your nose. The ring should face
towards you. Bite the mouthpiece and
breathe into it. *For a wall mounted
product, when removed from the cradle,
the light and alarm auto-activate.
3. Evacuation
Carry the lantern and evacuate in a low
stance, by crouching and walking.
How to use the mask during a fire evacuation
Detach 5aver from the cradle.
When it is removed from the cradle,
the light and alarm auto-activate.
* For a wall mounted set only.
Separate the mask and the lantern.
* Portable and wall mounted
Remove the plastic from the bottom
of the lantern to activate.
Remove the sealed sticker by
snapping off the cover cap
from the main body. Then remove
the orange air shut-off cap.
Please detach the nose grip
Youth and above
and place it on your nose.
The ring should face towards you.
Bite the mouthpiece
and breathe into it.
*See precautions no.4.
Children and infants
Carry the lantern and evacuate
by crouching and walking.
Children and the elderly
may need help.
sets only.
in a low stance,
