Toolway Tooltech Xpert 191051 Quick Start Manual

OFFSET PEX CRIMP TOOL
If the ring does not fit into the slot at all,
then the crimp is a "No-Go".
Adjust the crimping force on the tool
and re-crimp the ring.
1.Remove C-clip with screwdriver.
Montreal Office: 1868 Blvd. Des Sources, Suite 115, Pointe-Claire, QC, Canada H9R 5R2 | Phone : (514) 630-5130 | Fax: (514) 695-1761
HOW TO USE THE GO/NO-GO GAUGE:
If the ring slides into the slot and stops in
the "Go" range, then the crimp is good.
HOW TO ADJUST THE TOOL:
2.Push & rotate pin increase by single
increment only.
Head Office: 1-280 Hunter's Valley Road, Woodbridge, On, Canada L4H 3V9 | Phone: (905) 326-5450 | Fax: (905) 326-5451
Atlantic Canada Office: 2 Royles Avenue, Dartmouth, NS, Canada B3B 2E5 | Phone : (902) 468-2950 | Fax: (902) 468-2929
MODEL: 191051
If the ring slides all the way into the slot,
then the crimp ring is over crimped and is
a "No-Go". Remove the ring and adjust the
tool by flowing instruction below.
3.Replace C-clip with pliers or screwdriver
ENGLISH
EG
