Messano Dog Bed Assembly Instructions

Messano Dog Bed Assembly Instructions
Thank you for purchasing a Messano Dog Bed. Following the below instructions will ensure that the
bed is assembled correctly.

Parts List:

2 x Longer Aluminium Tubes
2 x Shorter Aluminium Tubes
4 x Aluminium Tube legs
4 x Vinyl Tubing Caps (pre-fitted to legs)
4 x Galvanised Iron Brackets
1 x PVC Polyester Cover
1 x Hexagon Key

Step 1:-

Check & confirm that all the above parts are present.

Step 2:-

Lay the PVC cover on a flat surface, ensuring that the stitched pockets are facing
upward.
Slide the aluminium tubes into the appropriate pockets, long tubes into the long pockets, short
tubes into the shorter pockets.

Step 3:-

Concentrating on one corner, push the two tubes into the bracket as far as they will go, so that
the leg is perpendicular to the floor.
