Summary of Contents for ScreenBeam ECB6250S02
- Page 1 User Guide Bonded MoCA Network Adapter Model # ECB6250...
-
Page 2: Table Of Contents
Table of Contents Table of Contents Getting Started Introduction Package Contents Features Connecting Adapters Connecting the First Adapter Connecting Addititional Adapters Specifications Notices Warranty Important Safety Instructions FCC Class B Equipment Technical Support User Guide | Bonded MoCA Network Adapter | Model # ECB6250... -
Page 3: Getting Started
Getting Started Introduction Congratulations for purchasing the ScreenBeam ECB6250 MoCA 2.5 Network Adapter. The Adapter is a simple, flexible solution for extending a home network. By leveraging the ubiquity of coaxial cabling within the modern home, the Adapter provides an Ethernet Internet port anywhere a coaxial connection is available. -
Page 4: Package Contents
Getting Started Package Contents • ECB6250 MoCA 2.5 Network Adapter • Coaxial cable • Power adapter • Quick Start Guide • Ethernet cable Requirements • Available coaxial port in installation areas • Available electrical wall socket in installation areas Features •... -
Page 5: Connecting Adapters
Connecting the Adapters Connecting the Adapter is a relatively simple process. First, connect one Adapter to the broadband modem or router and the coaxial network to establish the Internet signal. Then, additional Adapters can be installed throughout the home or office at any location Ethernet Internet access is needed, and an available coaxial port is available. - Page 6 Connecting the Adapters When complete, the setup should look similar to the figure below: Ethernet Cable Ethernet Coaxial Cable Power Coax In Power Coax ECB6250 Power Outlet Coaxial Outlet Ethernet Port of Modem/ Router Power Adapter If Coaxial Port is Being Used buy Another Device: 2-Way Splitter To Coaxial Port on Device From Coaxial Outlet...
- Page 7 Connecting the Adapters You will be asked to login. The user name is “admin" and the password is “actiontec”. Once you have enabled MoCA encryption, you can use the MPS push button to synchronize the encryption password on each MoCA 2.5 adapter connected via coaxial cable.
-
Page 8: Connecting Addititional Adapters
Connecting the Adapters If necessary, additional Adapters can be placed at locations around the home or office that need an Ethernet Internet connection, but currently only have a coaxial port. To connect additional Adapters: 1. Connect a coaxial cable to a nearby coaxial outlet. 2. - Page 9 Connecting the Adapters When complete, the setup should look similar to the figure below: Ethernet Cable Ethernet Coaxial Cable Power Coax In Power Coax ECB6250 Power Outlet Coaxial Outlet Ethernet Port of Modem/ Router Power Adapter If Coaxial Port is Being Used buy Another Device: 2-Way Splitter To Coaxial Port on Device From Coaxial Outlet...
- Page 10 Connecting the Adapters If the coaxial port is already being used by another device (a set-top box, for example), follow these steps: 1. Disconnect the coaxial cable from the connected device. Leave the other end connected to the coaxial wall outlet. 2.
-
Page 11: Specifications
Specifications Model Number ECB6250 (MoCA 2.5 Network Adapter) LAN MoCA (v. 2.5; up to 2.5 Gbps throughput) LAN Ethernet Port 10/100/1000 (1) Coax In Frequency Range - Extended D-band: LAN Connections 1125MHz ~1675MHz; LED Indicators Power, Coax Power External, 5V DC, 2A, 1.3 mm diameter connector plug Made by APD, model #WB-10E05FU FCC, UL 60950-1, CUL, IC Regulatory... -
Page 12: Notices
Under such local law, certain disclaimers and limitations of this Warranty Statement may not apply to the customer. Go to https://www.screenbeam.com/warranty-consumer for more information. Important Safety Instructions Basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and personal injury, including the following: •... -
Page 13: Fcc Class B Equipment
Notices • Use only the power cord and batteries indicated in this manual if applicable. Note: you may need to reword for batteries or adapters. • Do not dispose of batteries in fire, as they may explode – check with local codes for possible special disposal instructions if applicable. - Page 14 Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by ScreenBeam Inc., may void the user’s authority to operate the equipment. Declaration of Conformity for Products Marked with the Industry Canada (IC)–Canada only...
-
Page 15: Technical Support
Contact Information For questions regarding your product or the FCC/Industry Canada declaration, contact: ScreenBeam, Inc. 220 Devcon Drive, San Jose CA 95112 Technical Support Go to retailsupport.screenbeam.com for product support, updates, and more information including: • Firmware updates • Troubleshooting •...
