USER GUIDE ETHERNET MODULE (REF. RS2NET)
Technical manual V1.0
NetBus is a module produced by Sugar Valley in order to allow the interconnection between a Sugar Valley device
and the VistaPool system.
Likewise, the NetBus module allows the work with the PoolShow system of Sugar Valley to see the pool
parameters.
IMPORTANT: The NETBUS module and the PoolShow system must to be in the same network local to work
properly.
This module allows an internet wired connection, replacing the WIFI solution
IMPORTANT: The manual
operating ways of the devices, like the information used to generate
recommended to keep this document only for the internal use of Sugar Valley.
NETBUS module

Starting the system:

When the NetBus box is opened, you will find the folloging parts:
- NETBUS module
- MODBUS RTU wire connection
- Ethernet wire
The device can power from an 12V external adapter, or from the device. To install, complete the following steps:
contains instructions
Local internet Network
Pool controller
1
for the acces to a
a
ADSL modem
Internet
Vistappol web server
low level of differents
firmware upgrade file. It's
