MF5 Loudspeaker
Service Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MF5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ultimatum MF5

  • Page 1 MF5 Loudspeaker Service Manual...
  • Page 2 System description The Ultimatum MF5 is a multi-chamber, multi-facet loudspeaker system incorporating seven drive units per enclosure. The crossover network is essentially 2 way, plus additional super-tweeters, these being mounted at the top of the enclosure, facing upwards. The visible drive units are mounted on sub-baffles SBU and SBT. These are attached to the main enclosure via a polyethylene membrane.
  • Page 3 Crossover Network. L1: 0.8mH C1: 3.8mfd (3.3 + 0.5) C2: 0.5mfd L2: 0.4mH R1: 6.8 Ω R2: 6.8 Ω...
  • Page 4 Replacing drive units Caution: Use only NEAT ACOUSTICS replacement parts. To replace LF2 drive unit: 1) Place the enclosure with the drive units facing upward. Remove the foam trim ring from the drive unit, being careful not to stretch it out of shape. 2) Remove the old silicone adhesive by carefully peeling it away from the bass unit surround.
  • Page 5 M5 allen screws. 6) Fasten the rear panel to the enclosure with the M5 allen screws. Parts List - Ultimatum MF5 Description Part number...
  • Page 6 Neat Acoustics Ltd., tel: 01833 631021 fax: 01833 630022 www.neat.co.uk...
