Summary of Contents for Moodo AIR
- Page 1 Moodo user A I R guide...
- Page 2 Moodo AIR lets you take the finest fragrances, mix and match them, innovate and invent your own signature scent. In addition, with the AIR capsule it can be your personal smart air purifier.
-
Page 3: Tech Specs
Tech Specs ELECTRICAL SPECIFICATIONS Moodo AIR comes with a power adaptor & (optional) rechargeable battery Charger input: 100-240Vac; 50/60 Hz; 0.5A Charger output: 12Vdc; 1.5A Battery (optional): Li-ion rechargeable 7.2V / 2.4Ah OPERATION CONDITIONS Moodo app runs on both Android and iOS Moodo AIR device should be operated and stored at room temperature (the device can be operated in 7 - 40°C, with a relative humidity range of 20-90%... -
Page 4: Get To Know
Get to know Capsule 1 Slot Capsule 2 Slot Capsule 4 Slot Capsule 3 Slot Capsule 1 Control Capsule 2 Control Capsule 4 Control Capsule 3 Control Volume Indicator Main Volume Recharging Battery Indicator Power Button 12V Power Jack Also supplied in the box: 100-240V power adapter suitable for use with electric outlet... - Page 5 Device Manual Control Moodo AIR works with both fragrance capsules and air purifier capsules, however you need to choose the mode of operation as they can not be operated at the same time. Follow the below steps to manually activate your device: Insert chosen fragrance and AIR capsules into the capsule slots, any combination of capsules is fine.
- Page 6 Long press on the capsule control or ‘+/-’ buttons will increase the speed to maximum or switch it off. Connecting the device to a WiFi network: Install the Moodo application on a smartphone and follow the instructions Switching into pairing mode (access point): Press and hold the ‘capsule 1 control’...
-
Page 7: Battery Level Indication
5 seconds. Note: an empty capsule slot can not be turned on, you must insert certified original Moodo capsule to get it to work. In the occurrence of an unsupported push button command 2 fast LED blinking will be shown on the device. E.g. when trying to control an... - Page 8 Power button LED light Indications The device is in Access point mode Constant blinking The device is connected to Wi-Fi Button is constantly ON and no capsule recognized The device is connected to Wi-Fi Button is ON and every and is in diffuser mode 10 seconds blinks once The device is connected to Wi-Fi Button is ON and every...
- Page 9 Scent capsule lifetime is 60 hours in full speed (e.g. 2 months of daily operation of 2 hrs @ 50%) AIR capsule lifetime is 250 hours (e.g. 1 month of daily operation @ 8 hours) How to store your capsules? Capsules should be kept in a temperature below 25°C / 77°F at all time.
- Page 10 Moodo Setup Process Download the app: Moodo – The Smart Home Fragrance Mixer and Air Purifier After signing up select “setup wizard” in the app dashboard For troubleshooting please visit connect.moodo.co Still have an issue? Contact us: support@moodo.co...
- Page 11 App Dashboard Shuffle between presets Enable Interval Mode selector Tap to select which diffuser/purifier Moodo device to control Capsule monitoring and intensity indicator Power/Stand-by button Active capsules indicator Main scent volume Scent family name Fragrance presets are created by leading perfumiers...
- Page 12 Visit Our Online Store moodo.co General Inquiries info@moodo.co Customer Care service@moodo.co Technical Support support@moodo.co Agan Aroma & Fine Chemicals Ltd. 3 Ha’Hashlag Street Northern Industrial Zone, Ashdod 7752009, Israel MODAIR-MANUAL01 2020/09 © 2018 Agan Aroma & Fine Chemicals Ltd. All rights reserved...
