ATC ALIGNMENT
TOOL SET
Guardian of Machine Accuracy
Used for checking ATC positioning accuracy between
ATC arm, machine spindle and tool magazine.
▶ Prevent tool holder tapers from abnormal wear.
▶ Detect the potential problems of machines and
decrease the probability of machine breakdown.
▶ Prolong the use life of machine spindle.
BT / SBT
MAS 403
DualDRIVE+
CAT / SCAT
ANSI B5.50
DualDRIVE+
DAT / SDAT
DIN 69871-A
DualDRIVE+
HSK
DIN 69893
A, E, F Type
PSC
ISO 26623-1
Advertisement
Table of Contents
Summary of Contents for SYIC BT Series
- Page 1 ATC ALIGNMENT TOOL SET Guardian of Machine Accuracy Used for checking ATC positioning accuracy between ATC arm, machine spindle and tool magazine. ▶ Prevent tool holder tapers from abnormal wear. ▶ Detect the potential problems of machines and decrease the probability of machine breakdown. ▶...
- Page 2 INSTRUCTIONS FOR USE ( BT/CAT/DAT & SBT/SCAT/SDAT SERIES) Taper adapter Flange adapter Alignment Plug Clean machine spindle by spindle wiper. Assemble the taper adapter with pull stud and screw, insert taper adapter into spindle manually with screw and push machine controller button to clamp taper adapter, then loosen the screw.
- Page 3 INSTRUCTIONS FOR USE ( PSC & HSK SERIES) Taper adapter Flange adapter Positioning Pin Alignment Plug Clean machine spindle by spindle wiper. Insert the taper adapter into spindle manually and push machine controller button to clamp the taper adapter. Install the flange adapter into gripper of ATC arm and press machine controller button to move ATC closer to machine spindle.
