Summary of Contents for Metal Arsenal ECCOTARP ET-ROLLER 5
- Page 1 ET-ROLLER 5 Electric roller for fire hoses up to 5" INSTRUCTIONS FOR USE Metal Arsenal s.r.o. T +420 737 802 153 E info@eccotarp.com Poděbradova 1920 T +420 777 472 640 289 22 Lysá nad Labem Owner of Eccotarp www.eccotarp.com Czech Republic...
- Page 2 This document „Instructions for use“ (hereinafter manual) is used to get acquainted with the operation and characteristics of the ET-Roller 5 – Electric roller for fire hoses up to 5" (hereinafter the roller or the winder), and describes the manner of its use and possible risks connected with its use.
-
Page 3: Technical Data
Technical data Dimensions in use (w × d × h) 480 × 360 × 1080 mm The package includes: Dimensions of folded roller (w × d × h) 480 × 270 × 900 mm Height of roller with handle at the maximum 1× ET-Roller 5 –... - Page 4 Safety instructions for charging The winder is completely discharged when a slow 11. If the winder is not charged within 5 hours, interrupt rhythmical sound signal is heard and the WORK the charging process. Begin charging again button goes off. in 12 hours.
-
Page 5: Charging Station Specifications
Charging station specifications Charging station 36 V Mains voltage 88-264 VAC Charging time Winder battery charging indicator LED is off – battery is fully charged LED blinks in longer intervals – battery SWITCH ON PUSH RED BUTTON TO WORK is half discharged LED blinks in short intervals –... - Page 6 Prepare the hose in the appropriate position according to how you want to wind it for storage – see the instructions below (“option 1” or “option 2”). Option 1: The hose can be folded in half and pulled by the folded end towards the winder (see figure X). When folded, both parts of the stretched hose must be put on each other and aligned and the metal couplings must be positioned in such a way that the coupling of the upper half lies over the end of the lower half...
- Page 7 a controlled manner by pressing the WORK button intermittently until the couplings come safely close to the guiding coil. After that the hose couplings must be manually passed under the guiding coil (tilting the winder to a side in the case of the largest hoses) and with extreme care, the rest of the hose can be wound by pressing the WORK button shortly.
- Page 8 couplings get close to the lower guiding coil, it is recommended that the hose should be wound in a controlled manner by pressing the WORK button intermittently until the couplings come safely close to the guiding coil. After that the hose couplings must be manually passed under the guiding coil (tilting the winder to a side in the case of the largest hoses) and with extreme care, the rest of the hose can be wound by pressing the WORK button shortly.
- Page 9 SAFETY FUNCTIONS OF THE WINDER Certain safety features influence some of the winder’s reactions during the work: Graph 1 Stopping the winding – If the motor Winding speed becomes overloaded unexpectedly (e.g. as a result of the hose being obstructed or stepped on), the winding process is interrupted immediately, the WORK button starts blinking and a fast sound...
-
Page 10: Reverse Function
Smart winding Your winder has a smart motor control which allows you to adjust the fire hose winding speed. The reason is your convenience and safety as well as battery protection. How does it work? After WORK is pressed, the motor begins winding at zero speed. Then it switches to the highest revs very quickly and while the hose is gradually being wound, it starts lowering the revs so that with the increasing diameter of the wound hose, the winding speed for the free end of the hose remains safe. - Page 11 Squeezing remaining water out of a fire hose The winder must be turned off – the OFF position on the control panel. Pass one end of the hose over the lower guiding coil so that you can step on this hose end. If the stabilizing fold-out chassis is tilted out, tilt it down so that the winder can stand on it without being supported.
-
Page 12: Recommended Optional Accessories
Instructions for winder charging and storing Store the winder in a dry place. If the winder is not to be used for a long time, it should be stored at room temperature (19–23 °C). The winder system is designed in such a way that the charger can be connected to it permanently and the battery is safely recharged without any risk of damage. -
Page 13: Important Contact Information
A charger, that is past service, must be taken to an electric waste collection point or returned to the manufacturer. EU DECLARATION OF CONFORMITY No. 01032020/M Metal Arsenal s.r.o., Poděbradova 1920, 289 22 Lysá nad Labem, Czech Republic, hereby declares, at its sole liability, that the following product ET-ROLLER 5 Electric roller for fire hoses up to 5"... - Page 14 Notes...
- Page 15 Pictograph meanings Observe the Instructions for use for ET-Roller 5. During the winding process, the handle must be held with both hands and the stabilizing fold-out chassis must be secured by a leg. !CAUTION! During winding, there is a risk of serious injury as a result of clothes or limbs being caught in the carrier.
- Page 16 The winder may only be operated by 1 person. 1 person only Before the hose is taken away from the carrier, the device must be turned off. Protect the device from direct sunlight and do not expose it to temperatures higher than 40 °C for extended periods of time.
