Healthy Roaster

HR-121GCC32

Gas Type

For LNG

For LPG

Table of Contents

Important Safeguard.......................................

Parts and function..........................................

Installation method.........................................

I n s t a l l a t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Preparation before use..................................

How to use........................................................

●

Please make sure that you have the correct gas type (gas group) before installation.

● Please read the manual before using the appliance to become familiar with the charac-

teristics and usage method. Please follow the cautionary points indicated here and use

the appliance safely. Please refer to the attached DVD for usage method.

http://www.nondact89.com

ductless

How to cook Healthy Yakuniku.................

２

Maintenance.................................

５

Inspection,specification and after service...

６

If you think it is broken............................

１０

Application for repair request..............

１２

W a r r a n t y . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

１４

Healthy Roaster Co., Ltd.

User's Manual

Patent number ５００１４５７＆５３９６１９４

１６

１８

２０

２１

２２

Need help?

Do you have a question about the HR-121GCC32 and is the answer not in the manual?

Questions and answers

Summary of Contents for Healthy Roaster Co HR-121GCC32

Page 1     Healthy Roaster User’s Manual HR-121GCC32 Gas Type For LNG For LPG Table of Contents Important Safeguard........How to cook Healthy Yakuniku....２１６ Parts and function.......... Maintenance......... ５１８ Installation method......... Inspection,specification and after service... ６２０ I n s t a l l a t i o n ........
Page 2 Mandatory For city gas roaster, only city gas can be used and sticker that is on the roaster for propane gas roaster, only propane gas can be used. 製品名ヘルシーロースター ※If you use different kind of gas it may cause 品番 HR-121GCC32 incomplete combustion and carbon monoxide 都市ガス 13 A ガス使用ガス種 poisoning or burn yourself with explosive ignition or 5.85kW 5.85kW ガス消費量...
Page 3 Please follow these directions. Warning ■Do not take apart, alter, or repair. ■Do not place flammable items near the appliance Do not take apart or repair this product. ・ If there is any malfunction, contact our Do not place flammable items such as No fire Do not take apart support center. newspaper and paper bag, aerosol ※It may cause carbon monoxide cans, plastic bottles, and cooking oil. poisoning from incomplete combustion, ・ Do not use it near flammable items accident such as gas leakage, malfunc- such as curtains. tion, and fire. ...
Page 4 Please follow these directions. Caution ■Fill the tank with 3 to 4 liters of water. Fill the tank with 3 to 4 liter of water. If it evaporates and gets low, supplement it with water. ※If the tank water run out, the appliance gets hot due to the lack of heat radia- Mandatory tion effect so you may get burned. ■Do not let the water run out of the tank. If you are using it for long time, supplement it with water. 3~4ℓ ※If you keep using it without water, oil and residual burn may catch on fire. This may cause fire. ■Put about 1.5 liter of water in the net. Put the designated amount of water in the net in every use, and supplement the water after an hour of use. Mandatory ※If you use the appliance without any water, the net gets hot and burned, smoke containing oil and smell will be produced, and food will be burned on. ■Do not put anything other than water in the tank and net. Do not put anything other than water in the tank and net. 約1.5ℓ ※It may damage the appliance or cause fire. ■Do not use wet ceramic charcoal. ■Change the water in the tank if it is dirty. Wet ceramic charcoal may break when ...
Page 5 Parts and function Parts ● All stainless steel ③ Tabletop heat resistance lid ⑦Special net holder ④Stainless steel lid Net handles Feed water inlet (hold it with the special net holder) ⑤Stainless healthy net Steam outlet with moisturizing function (4 outlets on both side of the handle) ⑧Sliding charcoal case ⑥Special tong for opening the net (To open the lid went putting in water) Air zone Ignition lid with knobs ⑰Far-inferred radiation clean ceramic charcoal (16 in 1 case) Ignition knobs Far-inferred radiation ceramic gas burner Gas burner heat protective cover Safety mechanism for dying ﬁre (2 knobs on light and left) (Next tot eh gas burner) Hose end for the appliance ⑨Tank (water tray) When the appliance is purchased, necessary parts and consuming goods are all included. 1.Healthy Roaster 10.Heat resistance cover set ⑱...
Page 6 Installation method Table top, heat resisting cover, and roaster are very heavy. To avoid accident and injury, work on it with more than 2 people and wear protective gloves with anti-slip function. Also, Place blanket, cushion, and other material when you put the table on the ﬂoor to protect the ﬂoor so it will not Caution get scratched. １.Building the table ① Place the table top facing down on the floor. ② Put on 4 legs on the table Protect the floor with sheet or blanket. Insert the bolt of the pole legs on the discs installed on the table top. Install them by screwing them in. wobble. ※ Make sure to install it firmly so it will not ２.Assembling and installing heat resisting cover ３ Inside Convex side with nut processing It is easier to assemble if you use Tighten the bold from the bottom. is on the inside. a box. ４５６ Put the heat resistance cover on the Build it carefully so it is not warped. It is done if you finish tighten 16 bolts. back of the table top. ■ Caution for when installing the heat resistance cover. Top panel Make sure that the heat resistance cover is in the right direction and place it on the table top while making sure that it matches the ◎ mark indicated on the back of the table top. Tighten 2 screws on the front and back and 3 screws on the sides (do not put bolts on all wholes) as it shows below. ※Do not put on the panel yet.
Page 7 ３.Place the table ■ Stand the finished table. With 2 people, pick up the table, turn it around slowly, and place it on the floor. ※If you tilt the table or put weight on the leg only with 1 person, it may cause accident or injury. Carefully work on it with more than 2 people. ■ Place the table on the appropriate place. It is easier to use if you place the table so the ignition knob is facing ail (service side). ４.Prepare the roaster Burner cover Appliance hose end １１ Appliance hose end that is connected Burner protective cover located ２ to the gas cord. on both sides of the appliance. ①Take off the burner cover. Take of 2 bolts (the part that shows in image 1) located on the side of the burner cover. ②Turn the appliance hose end to the inside. Turn the appliance hose end to the inside so it would not get on the way when you drop the appli- ance in the table. ※It may damage the table top or the appliance. ５.Install the roaster ３ 30度 ③Drop the appliance. Take of all accessories such as net, tank and stainless steel lid. Firmly hold with both hands as it shows in the image 3. Drop the appliance slowly while tilting it about 30 degrees. ７.How to install the burner cover. ④ Put the burner cover with the bolt. ４５ Put the burner cover that was removed back to the original place.
Page 8 Installation method continues. ８.Place the table 6. There are 2 areas with metal fitting to set the charcoal case and they are located on the bottom portion of the ceramic burner. 7. Hold the charcoal case horizontally while the back is facing upward, and insert the charcoal case in to the groove in the metal fitting. 8. Hold it up gently. ※ Do not force it to go, twist it, or pull it. ９.Set up the net. Steam outlet Handle 7. Hold the net up as it shows above. As it shows in the image 7, stand the net up while placing it close to the side with ignition knob and handle and steam outlet facing up. 8. Push down the net and set it up. ※Set up the net so the handle and steam outlet is located on the other side of the ignition knob. 10.Set the tank Bump on the bottom of the tank Tank insert 9. Set the tank. Lift the tank a little so the bottom bumps do not get caught. Slide it in the tank insert gently. Get it close to the panel A indicate in figure 9, and place the tank so it is in the middle of the appliance. ※It may damage the appliance, leak water on the floor, and oil may catch on fire if it is not place in the right location. Caution on far-inferred clean ceramic charcoal ・Charcoal case is a sliding type and there are 16 charcoal s inside. You can use the charcoal repeatedly but there are some that breaks easily. If it is broken, slide the case and switch it to the spare. ・Do not use the charcoal if it is wet because it may break while heating ...
Page 9 11.Set the panel for tank insert Take out the tank and set the panel. Take out the tank and set the panel on both sides. Panel is set for the ignition knob side. As it shows in the picture, set the hook inside and stand it up. (Magnet attached) Set all three places. 12.Set the stainless steel lid Set the stainless steel lid Set the outer frame and lid in the center. When you use the appliance, remove the lid in the center only. ※Do not touch the stainless steel while and after in use. Do not touch it with bare hand. 13.Set the safety heat resistant lid ① ② ③ ④ Set the 4 safety heat resistance lid as it shows above and installation is complete. Check the installed place Set the appliance according to the ﬁre prevention law and description related to the electric setting. (Upward direction) over 50 ㎝ Upward direction / over 50 ㎝ (Backward) over 0 ㎝ Appliance valve Backward / over 0 ㎝ side Lateral over ０㎝ (Upward direction) over 50 ㎝ (Lateral) over 0 ㎝ Healthy Roaster 9...
Page 10 Installation ■Preparation and Checking ・ Before the preparation, make sure that the type of gas connected is the same type as the one indicated on the appliance. ・ As the gas cord gets longer, the gas ﬂow pressure is lower and heating power gets lower. Cord under 3m is recommended. ・ Have the gas cock construction prior to the installation. ■Installed are and ﬁreprooﬁng the surrounding ・ Install the appliance correctly to prevent carbon monoxide poisoning, ﬁre, and burns. ・ Fireproof the area according to the local ﬁre prevention law. Warning Select the area that satisfies the following conditions. ※If you do construction in the area near the appliance (such as wall cabinet and room divider) make sure that the place satisfies the condition after the installa- tion. ●No exposure to wind ●No water nearby ●Well ventilated ●No falling objects ●Horizontal and stable ●No flammable object nearby ●The room temperature can be controlled ●No resin product over the appliance such as a light Where to install gas cock In-wall plug in type ■ Gas cock needs to be installed on the oppo- site side of the ignition knob indicated in ① in the figure. Install the type that suite your store design and usage environment such as in-wall plug in type or exposed plug in type. ■ Do not install gas cock directly under the ①...
Page 11 Connecting rubber hose Connecting the appliance side 【 What to prepare 】 Rubber hose for gas ・ 9.5mm (for both LNG and LPG) rubber hose for gas ・ 2 rubber hose stopper 合格 1.Cut the rubber hose to the appropriate length so it does not touch the appliance. 2.Put the robber hose through the saddle band on the back side Appliance side hose end Rubber hose stopper of the table top, and organize it so it is not on loose. Connecting the gas cock side 3.Put the rubber hose all the way to the red line for the gas cock and appliance side and tighten it with rubber hose stopper. 4.Open the gas cock and make sure that no gas smell comes from the connection. ※Do not use the appliance if the rubber hose for gas (soft Rubber hose stopper cord) is touching a hot portion, bent, or twisted. Make the ...
Page 12 Preparation before using the roaster ■Preparation and checking ・ Be sure to follow the direction and use it correctly and safely. ・ Put designated amount of water in the net and tank before starting the ﬁre for every use. ・ After an hour of use, turn oﬀ the ﬁre, add water in the net, and check the water level on the tank. １.Put water in the tank ■ Put water in the tank more than 2/3 of the way full (about 3 to 4 liter) Water in the tank prevents the appliance to get too hot by heat radiation effect from evaporation. It also catches the oil and juice from the food. Be sure to have water while you are cooking. ①Take out the tank by taking off the panel for tank insert on the heat resistant cover. ※You can take out the tank either from right or left. ※The panel is magnetized so put it on above the tank insert. ②Put the water more than 2/3 of the way full (about 3 to 4 liter). ③Hold the tank horizontally, lift the tank a little and insert it inside so the bumps on the bottom do not hit. Set the tank in the center under the appliance. (Refer to set the tank on P8). ２.Put water in the net Feed water inlet About 1.5ℓ If it gets full, stand it up Installing ﬂexible hose Put a drop of pressure while opening the lid to on the faucet makes it easier reducer about a size drain some water. of a grain of rice. ■Put designated amount of water in the net (about 1.5l) By keeping an appropriate amount of water in the water cooling healthy net with moisturizing function, you can cook delicious food without smoke or burns. ①...
Page 13 ３.Set the net ■ Be aware of the direction of the net when setting the net. As it shows in the figure, be aware of the direction of the net when setting when setting the net. Lay the net down with the handle to the far end so the handle with steam outlet is on the other side of the ignition knob and put it on the center of the appliance. ※Set the net so the feed water inlet is facing above. ※If you grab it by the tank portion or pipe portion, you may drop it while setting or cause injury by pinching your hand. Make sure to use the handle to set the net. ※If you put the net with the handle on the knob side, it causes malfunction due to steam and water on the appliance valve. Make sure to set it in the right direction. ４.Set the lid ■ Set the safety lid As it shows in the figure, set the lid correctly. ① Set the stainless steel lid. ※Set the lid so the feed water inlet and the slit of the frame would match. ② Set the table top heat resistance lid. ※Set the lid correctly so the lid for feed water inlet is in the right direction. ５.Start the ﬁre ※Start the fire after all the preparation is done and set the timer (P15). Healthy roaster uses a fire starter with piezoelectric, which does not use electricity. There are 2 burners on the right and left and they each have ignition knob. When you start the fire, make sure to check for safety and...
Page 14 How to use Supplying water When the timer ring after 50 minutes of use, turn the ﬁre oﬀ and supply water in the tank, and check the water level in the tank.The appliance is very hot while being used so use the tong for opening the lid and be careful not to get burned when supplying water. １.How to supply water in the net STEP.1 Tong for opening the lid ３ Funnel Watering can (1ℓ) ① Put water in the attached watering can ② Turn both of the knobs and turn ③ Use the tong to open the lid and lift and have the funnel and tong for the lid for feed water inlet (insert it off the fire. opening lid ready. in the gap). STEP.2 ④ Open the lid using the tong, and open ⑤ Switch the tong for opening the lid to ⑥ When you grab it firmly, pull the lid the ...
Page 15 ＭＥＭＯ Healthy Roaster 15...
Page 16 Maintenance Warning ■ Cleaning the table ■ Cleaning the inside Wipe it down with soft cloth. Remove heavy dirt Take out the net after using, scrub it with with neutral detergent, and wipe it with dry cloth. stainless steel brush to remove the oil, and dry it with dry cloth. ※ Tabletop and lid is hot after use. Be sure to Do not touch Do not touch ※ Make sure to cool down the appliance. cool it down enough before cleaning. when it is hot when it is hot ■ Cleaning the outside ■ Cleaning the appliance Make sure to wear gloves when you Do not pour water directly over the appliance. Also, do not spray ...
Page 17 Cleaning the net / Maintenance ●The inside of the net do not need to be washed. ●When you clean the net make sure to keep the lid for the feed water inlet closed for both sides. ●If you soak the net in water, make sure to prevent things to get in from the steam outlet on the handle portion. Caution Steam outlet Water tank Connected parts ① For the pipe portion, remove the dirt ② For the whole net, clean the oil ③ After cleansing, wipe down the on both sides with stainless steel well using detergent and water tank with dry cloth. sponge. sponge that does not scratch ※ Do not scrub the connected parts the net. hard. ℓ （Refer to P12）（Refer to P12）（Refer to P12） ④ Supply the designated amount ⑤...
Page 18 Inspection, product speciﬁcation and after service Inspection list Is there anything ﬂammable Make sure that there is no ﬂammable object, obstacles, around the roaster? or falling object around the roaster. Check to see if the location of the charcoal case, direction of the net, Are all parts installed correctly? direction of the table top lid and stainless steel lid are installed correctly. Insert the hose all the way to the red line and tighten it with the rubber hose Is the rubber hose connected stopper. It will crack and insert gets loose when it gets old. Change it early. correctly? Is it too old? If you leave the oil on there, it may catch on ﬁre. Please clean if after use. Is it dirty? Open the gas cock and make sure that there is no gas smell coming from Does it smell like gas? the rubber hose connection. Product speciﬁcation Product type BBQ Healthy Raster / ＨＲ- １２１ＧＣＣ３２ Product number Gas consumption amount 5.85kW 5.85kW LNG 13A Nozzle diameter φ1.32 φ1.02 W560mm D363mm H350mm Size of the appliance Appliance material Stainless steel + SPC1 enamel coating...
Page 19 If you think it is broken Check the following items if you think the appliance is broken. If the following items do not apply or malfunction is still present, stop using it immediately and contact our support center. Condition Cause How to fix it. Open the gas cock all the way. Gas cock is closed. It does not light Fix the bend in the rubber hose. Rubber hose is bent or squished. It does not light easily. Fire goes out while in Ensure the rubber hose connection. Connection for the rubber hose is not suﬃcient. use Light the grill over and over. Air left in the rubber hose. Push the knob well and turn. Lighting method is inappropriate. Remove the dirt and clean the pilot light. Pilot light is dirty and closed. Check the gas cock and light the grill over and over. It has not been used for a long time. Contact your gas company. LP gas is running out. Flame is red and weak Insuﬃcient ventilation. Ventilate the room The ﬂame is strange Wind from outside, fan, or air conditioner is Burner is exposed to wind (the way it burns and blowing the burner. color) The calcium in the moisture turns the ﬂame red. Using humidiﬁer It is not malfunction. Charcoal case is touching the burner Install the charcoal case correctly. Clean it with brush after it cools down enough.
Page 20 Pages / ※ Please make a photocopy and use this sheet FAX repair request sheet To the customer service FAX counter (Date) Month/ Day/ Year Store name/ Company name Department ： Position ： Name/Person in charge Postal code （ − ） Address Phone number Cell phone number ＦＡＸnumber e-mail □It does not light. □Fire goes out while in use. □Flame is strange. Malfunction □Others （） Failed state and condition (as much as you know). □Home phone □Cell phone □FAX Desired contact ...
Page 21 ＭＥＭＯ Repair record Repair detail Year / Month / Date M E M O Healthy Roaster 23...
Page 22 Product Warranty for Healthy Roaster This product is manufactured in thorough product management and strict inspection process. This warranty is to promise our customer free repair indicated in this warranty if there is any BBQ Healthy Roaster / HR-121GCC32 Product Type 1 year Warrantied period Purchased date Name Postal code （ - ） Address Customer Store name Phone number Store name Seal of the store Address ★Dealer Phone number (For dealers) Please write it down and put a seal. ※The warranty period is 1 year from the purchase and the main component is under warranty. ※If there is any malfunction during the warranty period, send a repair request to our support center along with this warranty and product. ※For repairs, we may use recycled parts that meets our quality standard. Warranty Rules 1. If there is malfunction when the product is used ...
