AUTO BAG SEALER
MANUAL
Preface
Thank you for purchasing our automatic bag sealing machine.
This manual explains its basic structure, usage method and operation precautions, in
order to facilitate the safe and correct use of the machine and improve the service life of
the machine. Please read this manual in detail before using the machine, please ensure
1 / 14
Advertisement
Summary of Contents for HENOPAC AUTO BAG SEALER
- Page 1 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 AUTO BAG SEALER MANUAL Preface Thank you for purchasing our automatic bag sealing machine. This manual explains its basic structure, usage method and operation precautions, in order to facilitate the safe and correct use of the machine and improve the service life of the machine.
- Page 2 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 that the manual is delivered to the end In the hands of people, if the contents of this manual are changed due to technical updates, without notice. Safety Precautions 1. Please read this manual carefully before operating this machine.
- Page 3 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 CONTENT 1.The machine feature................3 2.Description of mechanical structure and adjustment..........5 3.Machine operation process................. 7 3.1.HMI operation and instruction................9 3.2.Electrical schematic diagram................. 14 4.Safety precautions.....................16 5.Trouble shooting....................14 3 / 14...
- Page 4 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 1.Characteristics This machine is a product of a series of packaging machines with automatic bag lifting and automatic sealing functions. It is economical and efficient in stand-alone operation. It is an ideal packaging equipment.
- Page 5 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 2: Mechanical structure and adjustment instructions Carton cover blocking mechanism Width limit stop Note: The width limit stop restricts the carton in the middle of the conveyor belt, and the carton cover mechanism prevents the front and rear covers from supporting the carton during the process of opening.
- Page 6 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 The heat sealing mechanism is adjusted as follows： Heat-sealed compacting cylinder Bag compression cylinder Heat-seal pressing adjustment mechanism Description: Adjust the bag tightness by adjusting the bag compression cylinder, and adjust the tightness of the heat-sealed bag by adjusting the heat...
- Page 7 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 3: Machine operating instructions 3.1 The touch screen display is as follows: 7 / 14...
- Page 8 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 8 / 14...
- Page 9 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 1) Make sure that the machine is powered on. 2) Turn on the power switch and wait for the to start 3) Enter the operation screen directly after booting. "Automatic" interface can operate the machine to start, reset, view the output and other information;...
- Page 10 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 Electrical schematic diagram 10 / 14...
- Page 11 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 Heating temperature control principle wiring diagram 11 / 14...
- Page 12 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 1. 4.Safety Precautions Please pay attention to the safety labels on the machine, and pay attention to safety when using to avoid injury. 3. 1. Electrical box, junction box is affixed with "Electrical 4. "Warning signs", except operators and electrical maintenance 5.
- Page 13 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 The user should read this manual carefully before using the machine, and should pay special attention to safety during use. Before preparing to turn on the machine, carefully check whether someone or someone's body parts are in contact with the moving parts of the machine.
- Page 14 Web: www.henopac.com Email: sales1@henopac.com What’s app:+8618680322634 c) Servo motor servo over limit position. e) The air switch is switched to the ON position; f) Check if the PLC has output. Touch screen output screen 3. The conveyor line does not turn: a) Check whether the motor and transmission shaft are connected properly;...
