QubeStove Portable Outdoor Pizza Oven
and Fire Pit Stove in One
Your safety is very important, please read this manual thoroughly
before you install, operate or maintain this oven/stove. Keep this
manual for future reference. If you have questions about assembly,
operation, service or repair of this stove, please reach out to us directly.
HOT SURFACE WHEN BURNING! KEEP CHILDREN AND PETS AWAY.
WEAR PROTECTIVE GLOVES WHEN ASSEMBLING AND OPERATION.
Owner's Manual
IMPORTANT:
WARNING:
FOR OUTDOOR USE ONLY!
SAVE THIS MANUAL FOR FUTURE REFERENCE
QSTOVES INC.
SAMMAMISH WA 98074, USA
Advertisement
Summary of Contents for Qstoves QubeStove
- Page 1 QubeStove Portable Outdoor Pizza Oven and Fire Pit Stove in One Owner’s Manual IMPORTANT: Your safety is very important, please read this manual thoroughly before you install, operate or maintain this oven/stove. Keep this manual for future reference. If you have questions about assembly, operation, service or repair of this stove, please reach out to us directly.
-
Page 2: Important Warnings
Be sure you understand all operation instructions before attempting to operate or service this stove/oven. QSTOVES WILL NOT BE RESPONSIBLE FOR INJURY, DEATH OR PROPERTY DAMAGE IF INSTRUCTIONS IN THIS MANUAL ARE NOT FOLLOWED. - Page 3 QubeStove Portable Outdoor Pizza Oven and Fire Pit Stove in One Owner’s Manual 1. Packing List: Here’s everything of the QubeStove from the box, including: 1 QubeStove fire pit/stove; 1 hook&pick tool; 1 detachable fire pit handle; 1 pizza oven (main body);...
- Page 4 2.2.1 put the rolling bearing ring onto the plate shaft; 2.2.2 put the flat bearing ring (spacer) on the plate shaft; 2.2.3 there are 2 pits in the pizza stone; set the 2 positioning screws on the rotating plate into 2 pits;...
- Page 5 2.3 place the pizza stone into the oven: hold the rotating plate shaft in between 2 fingers, place the pizza stone with the rotating plate into the pizza oven. Make sure the shaft of rotating plate is positioned into the hole in the central of the oven bottom.
- Page 6 2.4 set the pizza oven onto the fire pit: 2.4.1 pull the legs outward, rotate the leg base about 40° degrees. 2.4.2 there’s a big round hole in the backside of the oven; place this hole onto the round connecter of the fire pit: 2.4.3: lift the pizza oven by using the handle on the top, set the oven onto the fire pit, connecting the round hole in the oven...
- Page 7 2.5 put the chimney onto the pizza oven: 2.5.1 There are 3 tabs at one end of the chimney; and 3 slots are cut on the top of the oven; 2.5.2 Insert the 3 tabs inside the 3 slots, then turn the chimney clockwise, the chimney will be locked firmly onto the oven top.
- Page 8 The CubeStove fire pit can be turned 90° degrees, so that the hopper lid can be on left side or right side, make it convenient to fill the wood pellets when operation.
- Page 9 3. Light On the QubeStove 3.1 Use the QubeStove Fire Pit Only without Oven: 3.1.1 place the QubeStove Fire Pit on a flat and solid surface, Keep safe distances away from the other flammable vapors, liquids or solid combustibles. 3.1.2...
- Page 10 3.1.7 Let the wood pellets burn out if you want to turn off the fire. 3.2 Light the QubeStove when the pizza oven is set 3.2.1 Open the wood pellets hopper lid at the back of the QubeStove by using the hook&pick tool, pour a scoop of wood...
- Page 11 Close the hopper lid, put on the oven lid. That will make an air draft from the air inlet at the bottom of QubeStove to the oven chimney. After about 10 minutes, the flame will rush out on the top.
- Page 12 4. Cooling and Disposing of Ash Wood Pellets burn very efficiently. You can only get very little ash even after hours of burning. But pay more attention of cooling and disposing of the ash for your safety. 4.1 When you have finished heating or cooking, allow the oven/stove to burn through all remaining wood pellets.
- Page 13 9. Warranty Terms-One Year Limited Warranty, and we’ll extend that to a 3-year warranty on Qubestove products when you register your products. Subject to the conditions set out below, this product is warranted to the original purchaser to...
- Page 14 subjected to abuse improperly treated, neglected, rusted by exposure to the elements, misused and/or if any repairs. 9.4 Return must be properly packaged and freight prepaid. 9.5 Each of the manufacturer, distributor and retailer will not be liable for any incidental or consequential loss or damage arising from the installation or operation for the product and/or the failure of any part for any reason.
- Page 15 Tips: Wood Pellets: - Safer and More Sustainable Wood Pellets are made from compressed recycled sawdust, and is considered as renewable, carbon neutral, eco-friendly biomass fuel, an alternative to fossil fuels that save our precious forests and reduces air pollution. Mainly there are 2 kinds of wood pellets: soft wood pellets and hard wood pellets.
- Page 16 Follow us and keep up to date with all things via: Qstoves / Qubestove Patented: QSTOVES INC. QSTOVES, Q-STOVES, Q-FLAME, QUBESTOVE are registered trademarks of Qstoves Inc. Copyright 2020 All Rights Reserved For patent, trademark and copyrighted information please email vp@qstoves.com...
