Summary of Contents for SINNOWA BS Series
- Page 1 BS3000S Multi-test Analyzer User’s Manual Sinnowa Medical Science & Technology Co., LtD...
-
Page 2: Table Of Contents
BS Series Multitest Analyzer Contents 1. GENERAL INTRODUCTION 1.1 C ..........................1 ONFIGURATION AND TRUCTURE 1.2 M ......................1 AIN FEATURES AND TECHNICAL PARAMETERS 2. INSTALLATION 2.1 I ............................ 2 NSTALLATION REQUIREMENT 2.1.1 SPACE REQUIREMENT ..........................2 2.1.2 ENVIRONMENTAL REQUIREMENT ......................2 3. -
Page 3: Configuration And Structure
BS Series Multitest Analyzer 1. General Description BS3000S is an optical multi-test analyzer with Biochemistry and Specific Protein test functions. The optical system possessing the function of Transmitted light colorimetric detection and scattering light detection enable the analyzer in multi-test functions. -
Page 4: Installation
In order to ensure the equipment works normally, it must be installed and debugged by the engineers who are authorized by Sinnowa or Sinnowa authorized organization. For any reasons to reinstall the analyzer, only the authorized engineer can do the works. -
Page 5: Biochemical Test Functions And Operation
BS Series Multitest Analyzer 3. Biochemical Test Functions and Operation 3.1 Working Principle The principle of analyzer is based on Lambert-Beer Law. 3.2 Operation Switch on the equipment, screen shows as below Click on the screen and enter the selection interface, then select to enter different menu function, which can perform edition, setting and testing, etc. -
Page 6: Parameters Setting
BS Series Multitest Analyzer report, etc. Wash: The shortcut key for cleaning, aspiration volume is 1.5ml per keystroke, used to clean flow cell. Feed: Used for printer to load papers, pass papers and cut papers Pump: Calibration for Peristaltic pump aspiration volume Gain: AD Auto Zero to confirm whether the instrument is in the regular test status. -
Page 7: Instrument Operation Key Process
BS Series Multitest Analyzer The default values of the instrument is that 3000ul aspiration sample volume corresponds to 20000 motor steps. When the aspiration volume is not correct, adjusting is necessary. Enter into the calibrate interface, input pump calibrate volume, then pour corresponding distilled water into the tube, insert pipette into water, press PUSH to aspirate. -
Page 8: Ad Auto Zero
BS Series Multitest Analyzer 3.4.3 AD Auto Zero Select AD Auto Zero from the main menu, the screen will show as below: Press Push to aspirate distilled water and click Continue And then click read When AD auto zero, put the aspiration pipe into distilled water, press push, then the instrument begin to zero. -
Page 9: Specific Proteins Test Function And Operation
BS Series Multitest Analyzer 4. Specific Proteins Test Function and Operation 4.1 Principle Specific proteins test is based on the light scattering principle. When immune complex which consists of specific proteins meet incident ray in detection System, the intensity of scattered light at 90 degrees is directly proportional to amount and size of immune complex within certain limits. -
Page 10: Weekly Maintenance
Please take measures to eliminate the malfunctions which occur in use or before use according to relevant troubleshooting. If the malfunctions still exist, please contact the after service of SINNOWA or our local franchiser as soon as possible. We are pleasure to serve you. 6.1.1 Malfunction phenomenon: There are mistakes with auto zero... -
Page 11: Wrong Result Or Bab Repetition
BS Series Multitest Analyzer Cuvettes are dirty (need to wash); There is air bubble in Cuvettes (need to wash); Pipette is connected wrongly, leaks or blocked; Peristalsis pump hitch; Filter is aging or damaged; Instrument bulb burned out. 6.1.2 Malfunction phenomenon: Wrong result or bad repetition Possible causations: There is air bubble in Cuvettes (need to wash);... -
Page 12: The Corrections And Replacements To Common Parts Of Analyzer
BS Series Multitest Analyzer Maintenance: Plasma (serum) and reagent incubate more than 3 minutes in winter it should around 5 minutes. Or reference to the manual, run the calibration procedure to calibration. 6.2 The corrections and replacements to common parts of analyzer In order to make the analyzer’s running reliable, it’s necessary to proofread or replace some... -
Page 13: The Replacement To Peristalsis Pump
BS Series Multitest Analyzer 7. Loosen the screws on the side of the lamp bracket 8. Turn on the power switch, enter into the instrument interface, enter into the interface of A/D signal detection, select any one wavelength, and test the signal value, at this time up and down to adjust the position of the lamp to fix it until the A/D value at the maximum signal value points. -
Page 14: The Replacement To Printing Paper
BS Series Multitest Analyzer ● Replacement of the pump pipe must be provided by SINNOWA, do not use other types of pump pipe to replace 6.2.4 Replacement to printing paper The steps as follows: 1. Open printer covering, take away the old printing paper 2.
