Table Of Contents
Fan Filter Units
List Of Models.........................................................i
Installation Operation
Read And Save These Instructions........................1
and
Receiving And Unpacking......................................1
Maintenance Instructions
Pre-installation Instructions....................................1
Installation Instructions..........................................1
Operating Instructions............................................2
Troubleshooting
Guide........................................2
SAM Maintenance Instructions..............................3
SAM MS 3S NCR Style
When To Change A HEPA Or ULPA Filter................3
How To Change A HEPA Or ULPA Filter............4-5
Gel Seal Filter Replacement...........................6-7
Wiring Diagram......................................................8
Warranty..............................................................8
SAM MS 3S GS Style
READ AND SAVE THESE INSTRUCTIONS
Headquarters: 4939 Starr St. SE
Designers and Manufacturers of
Legend Modular Hardwall Cleanrooms-Flexible Solutions
Grand Rapids, MI 49546 USA
Softwall Cleanrooms- Cleanroom T Grid Systems-Cleanroom
Ph: 616-452-8700 • Fx: 616- 452-2372
Workstations-SAM Fan Filter Units and Industrial Air Cleaning
sales@cleanroomsint.com • www.cleanroomsint.com
Equipment
November, 2012
Advertisement
Table of Contents
Summary of Contents for CleanRooms International SAM MS 3S Series
-
Page 1: Table Of Contents
Designing Flexible Solutions MS 3S ® Table Of Contents Fan Filter Units List Of Models............i Installation Operation Read And Save These Instructions......1 Receiving And Unpacking........1 Maintenance Instructions Pre-installation Instructions........1 Installation Instructions..........1 Operating Instructions..........2 Troubleshooting Guide........2 SAM Maintenance Instructions......3 SAM MS 3S NCR Style When To Change A HEPA Or ULPA Filter....3 How To Change A HEPA Or ULPA Filter....4—5 Gel Seal Filter Replacement......6—7... -
Page 2: List Of Models
LC = Low Cost, LI = Lights, GS = Gel Seal , HO = High Output, 3S = Three Speed Model No. Size Volts Watts Motor FLA Housing Code & Description Listed 1/5 HP SAM MS 3S Series 12339 SAM 22MS 3S NCR 2’ x 2’ 115V Metal 12340 SAM 22MS 3S NCR 2’ x 2’ 277V Metal... -
Page 3: Read And Save These Instructions
READ AND SAVE THESE INSTRUCTIONS PRE-INSTALLATION INSTRUCTIONS WARNING- TO REDUCE THE RISK OF FIRE, WARNING- TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO PERSONS, OB- ELECTRICAL SHOCK, OR INJURY TO PERSONS, SERVE THE FOLLOWING: OBSERVE THE FOLLOWING: Use this unit only in the manner intended by the manufacturer. -
Page 4: Operating Instructions
Mechanical Installation of Units in 2” T-Grid Systems: CAUTION: If the unit is provided with a square perforated metal barrier over the opening to the prefi lter frame, it must Install 2” T-Grid system in accordance with site plan and be re-installed prior to application of power and start-up of the manufacturers instructions. -
Page 5: Sam Maintenance Instructions
SAM Maintenance Preventive Maintenance It is the intention of Clean Rooms International, Inc. to deliver a safe and reliable product that will give years of trouble-free service. To ensure optimum, safe performance and maximum product life a preventative maintenance program must be established. SAM Unit 1. -
Page 6: How To Change A Hepa Or Ulpa Filter
NCR Style units with HEPA or ULPA Filter SAM 24 NCR Style (are not replaceable from roomside) Shown here all other sizes use same method How to Change the HEPA or ULPA Filter Plenum Hood CAUTION: Do not touch either side of the HEPA or ULPA Plenum Flange fi... - Page 7 SAM 24 GS Style Shown here all other sizes Housing use same method Filter Filter Clamps Swing Down Grille 3. (Fig. 9) With a 5/32” allen wrench, remove the (4) fi lter clamp bolts and (4) fi lter clamps (D) from housing. Filter Clamp Bolts Fig.
-
Page 8: Gel Seal Filter Replacement
Gel Filter Replacement 4. Formation of wet areas on or in the gel. Dripping of the gel. Polyurethane and Silicone Gel are often used in systems where HEPA fi lters Filters may be re-installed into gel showing mild chemical attack. Reinstalled are installed into grids or housing and where ease of installation and removal fi... - Page 9 If the fi lter is found to be leaking at the gel seal during the test, the fi lter should be removed and the gel should be replaced prior to Inset “A” re-installation and testing. Gel exhibiting severe physical damage must be completely removed and replaced prior to reinstallation of the fi...
-
Page 10: Wiring Diagram
WIRING DIAGRAM FOR SAM 22 & 24 MICROSOUND MODELS with 3- SPEED CONTROL and 1/5 HP MOTOR USE 75 ◦ C MIN COPPER High Med Denotes: Field Connection CONDUCTORS ONLY Denotes: Factory Connection Standard Wring, 120 & 277v 120v Motor Common (White) White 120v, Single Phase, 60 Hz...
