- Page 1 User Manual 7ISW152 Spectrometer Optics Focus Instruments Co., Ltd. 0 / 10...
-
Page 2: Table Of Contents
Contents Features ..........................2 Description.......................... 2 Specifications ........................3 Specifications of Optional Gratings ..................3 CCD Specifications ......................4 Optical Design ........................5 Slits Adjustment ........................6 Usage ..........................6 Others ..........................7 10. Utility Software ........................8 11. Accessories ......................... 9 1 / 10... -
Page 3: Features
1. Features Czerny-Turner optical design for high resolution & maximum throughput while minimizing stray light & aberrations Dual ruled gratings used for high efficiency ultraviolet to visible wavelength scanning Single output port version with CCD detector Micrometer adjustable slits ... -
Page 4: Specifications
3. Specifications Model 7ISW152 Focal Length 150mm F/4.5 Stray Light 5x10 Minimum Step 0.0045nm Number of Gratings Supported Grating Name Grating S30x30x6 Grating Size 30mmx30mm Standard Grating OG1200-300(1200g/mm, λp=300nm) OG600-1000(600g/mm, λp=1000nm) Wavelength Selection Method Motorized Output Ports 1 (with CCD detector) -
Page 5: Ccd Specifications
OG1800-250 185-500 0.17 0.08 0.27 0-730 OG1800-500 330-730 OG1200-250 185-500 OG1200-300 0.25 200-600 0-1100 OG1200-500 330-1000 OG600-300 200-600 OG600-400 260-800 OG600-500 300-1000 10.8 0-2200 OG600-750 500-1500 OG600-1000 660-2000 OG600-1250 830-2200 OG300-500 330-1000 OG300-1250 830-2500 21.6 0-4400 OG300-1800 1200-3600 OG300-3000 2000-4400 OG150-4000 43.2 2600-8000... -
Page 6: Optical Design
Eliminating secondary dispersion is designed to restrain stray light. The F/4.5 spectrometer is optimized to provide excellent stray light rejection while minimizing aberrations. 7ISW152 spectrometer optical design 5 / 10... -
Page 7: Slits Adjustment
7. Slits Adjustment This series of spectrometers uses micrometer adjustable slits with sharp stainless-steel blades. The narrowest practically achievable width is 10 μm. The slit is 5 mm high and its width can be adjusted from 10 μm to 3 mm. The slit uses micrometer head with 10μm graduations to drive the width of slits. -
Page 8: Others
or power socket. After you turn on the power, you will hear worm gear is rotating. That means the instrument is making self-checking and resetting. After finishing self-checking, the instrument will stop automatically and wait for communication with computer. Now you can run the 7ISWS application software and select the actual RS232 port to make communication. -
Page 9: Utility Software
Nitrogen connector To avoid the absorption of air, you can fill the spectrometer with nitrogen in ultraviolet and near infrared band to improve the efficiency. There is a specific nitrogen connector with the spectrometer. When you need to use it, remove the cover and install the nitrogen connector, then connect the nitrogen pipe. -
Page 10: Accessories
Utility Software Screens 11. Accessories 1 x 220V line cord or 110V line cord 1 x RS232 cable 1 x USB cable 1 x USB cable for CCD 2 x 3A fuse 1 x Nitrogen connector 9 / 10...
