Summary of Contents for Telemark 376
- Page 1 MODEL 376/379 ELECTRON BEAM SOURCE CRUCIBLE INDEXER INSTRUCTION MANUAL Part Number 376-0001-2 Copyright © TELEMARK, 1995-03 - All rights reserved June, 2003 www.telemrk.com Brand and product names are trademarks or registered trademarks of thier respective companies.
- Page 2 Telemark. Components which are purchased by Telemark from other manufacturers will be guaranteed for any lesser time that such manufacturer warrants its product to Telemark. This warranty is valid only for normal use where regular maintenance is performed as instructed. This warranty shall not...
-
Page 3: Table Of Contents
Telemark 376/379 Crucible Indexer TABLE OF CONTENTS WARRANTY USER RESPONSIBILITY SAFETY WARNING LIST OF ILLUSTRATIONS UNPACKING DESCRIPTION INSTALLATION Required Components....3-1 Setting Up ......3-1 Changing Number of Pockets . - Page 4 Telemark 376/379 Crucible Indexer SERVICING Motor Drive Assembly ....5-1 LIST OF ILLUSTRATIONS Fig. Title Page Indexer Reference Dimensions ....2-2 Suggested Installation .
- Page 5 Telemark 376/379 Crucible Indexer UNPACKING Your Model 376/379 electron beam source crucible indexer is packed into a specially designed double strength box surrounded with rigid foam padding. Since packaging the indexer for safe shipment is otherwise difficult, please save the box in the event that the indexer may ever need to be returned for servicing.
- Page 6 Telemark 376/379 Crucible Indexer UNPACKING...
- Page 7 (6.35mm). The controller features crucible pocket selection lights to tell the operator which crucible is in the “evaporate” position. The model 376/379 electron beam source crucible indexer’s most notable features are the following: Selects, accurately positions, and indicates crucible to be evaporated.
- Page 8 Telemark 376/379 Crucible Indexer Figure 2-A Crucible Indexer Reference Dimensions DESCRIPTION...
-
Page 9: Installation
Telemark 376/379 Crucible Indexer INSTALLATION Required Components See fig. 3-A The following is the minimum list of components required for setting up the indexer for safe operation. 4 or 6 pocket electron beam source. Source rotation must be in working order. - Page 10 1" feedthru. With Telemark thru baseplate Sources (231, 238, 267, 268, 277 or 281) the motor can be installed on the motor bracket.
-
Page 11: Changing Number Of Pockets
Control PCB See figure 3-C The model 376 has C1 installed and not S1. The model 379 has S1 installed and not C1. S1 is used to select the end of the banana pocket, an in figure 4-1. The number 2 position is defalt as shipped from the factory. -
Page 12: Sweep Select Control
See firures 3-C and 3-D This option board is used in conjunction with sweepers incorporating pattern preselect, such as the Telemark XY Sweep with the optional Sweep Select Module. Switches S3 - S6 allow four sweep patterns (relay closesures on the Sweep Select Control PCB, K5 - K8) to be married to any of the four or six pockets controlled by the indexer. -
Page 13: List Of Accessories Or Supplies
With six pockets and four patterns; Pockets (5) and (6) must share a pattern with the other four pockets. see figure 3-E. List of Accessories or Supplies Recommended parts: Rotary Feedthrough. Right Angle Rotary Feedthrough, Telemark number 275-0006-1 for side drive sources or 1/4" Rotary Feedthrough, number 275-0002-1 for bottom drive sources. Figure 3-D... - Page 14 Telemark 376/379 Crucible Indexer INSTALLATION...
-
Page 15: Operation
The indexer is ruggedly designed and built, and should last a long time between adjustments. Model 379 Modes The Model 379 Indexer has three modes of operation: Normal - In this mode it operates like a model 376. OPERATION... - Page 16 Telemark 376/379 Crucible Indexer Figure 4-A Banana Pocket Banana - (see figure 4-A) In this mode the pocket will move back and forth under the beam with one end of the pocket being the #1 position and the opposite end being settable in positions two to six.
- Page 17 Telemark 376/379 Crucible Indexer SERVICING Motor Drive Assembly Part# -8 Part# -9 Description Qty. Figure 5-A Assembly 271-6030-8 271-6030-8 Soc. Head Cap Screw, #6-32 X 1/4" 9ea. 271-6130-8 271-6130-8 Soc. Head Cap Screw, #8-32 X 1-3/4" 4ea. 271-6171-8 271-6171-8 Soc. Head Cap Screw, #10-32 X3/4"...
- Page 18 Telemark 376/379 Crucible Indexer Figure 5-A Assembly SERVICING...
