Summary of Contents for Concox VL501
- Page 1 VL501 LTE Vehicle Terminal User Manual Version: V1.0 Read this manual carefully prior to use. No prior notice will be given for any changes made to the appearance color, or accessories of the product.
- Page 2 CONTENTS Introduction 1.1 Features 1.2 Operating Environment 1.3 Frequency Bands verview verview 2.1 Appearance 2.2 2.2 LED Indication Packing List Installation 4.1 SIM Card Attachment 4.2 Device Installation Configuring APN and Server Parameters Common SMS setting command Platform Operations...
- Page 3 Positioning accuracy <2.5m CEP (Open Sky) Location modes GPS/GLONASS/BDS/AGPS/QZSS Cold start≤30sec Sensitivity Hot start≤1sec Typical≤15mA @ 12V (deep sleep) Operating current Typical≤120mA @ 12V (active tracking) 1.3 Frequency Bands LTE-FDD CAT-1: B2/B4/B5/B12/B13 VL501(N) WCDMA: B2/B4/B5 VL501( J ) LTE-FDD CAT-M1/NB2: B1/B3/B8/B18/B19/B26...
- Page 4 02. Overview 2.1 Appearance Notch Type-C USB-A Cooling holes Negative Positive PWR LED Power LED SIM card holder 2.2 LED Indication Meaning Solid on The power is connected and the device can work properly. No power is connected or the device is faulty. Off...
- Page 5 find out where the cigar lighter port of your vehicle is. Note: Do not shake or rotate the VL501 at will, as it may falsely trigger reckless driving behavior and other alerts.
- Page 6 You can set the APN and the server via SMS commands if necessarily. APN set command It is recommended to contact your network operator to confirm the APN information. Then you can use your phone to deliver the following SMS command to the VL501: APN,apnname# For example: APN,internet#...
- Page 7 07. Platform Operations By logging in to the mobile app or locations services platform designated by your dealer and correctly your device, you can query and set related parameters. Logging In to Service Platform Log in to the location services platform designated by your dealer and configure accordingly. Downloading Mobile App Log in to the URL designated by your dealer to download the mobile app.
- Page 8 FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device,pursuant to part �� of the FCC Rules. These limits are de- signed to provide reasonable protection against harmful interference in a resi- dential installation.
