Summary of Contents for RHOMBUS 105
- Page 1 Rhombus105 Extended Range Reader Instruction Manual Contents Section1 Introduction Section2 Features Section3 Specification Section4 Interface Section5 Trouble Shooting...
- Page 2 1. Introduction The Rhombus105 is a low cost and high performance proximity reader for reading ID code from uem4100 compatible read-only tags. The Rhombus105 reader features an extended reading range up to 1000mm. It is ideally suited to be applied in automatic parking system, personal identification, access control and production control systems etc.
- Page 3 Rhombus105’s functional area; 6) Try to change the installment of the Rhombus105 to another place to check if the trouble still exists; Note: Rhombus’ products must work with linear regulated power supply, and other kinds of power supply are prohibited.
