PHYSICAL AND ELECTRICAL DATA

Model
Unit supply voltage
1
Normal voltage range (V)
Minimum circuit ampacity (A)
Maximum overcurrent device (A)
Minimum overcurrent device (A)
Compressor
Crankcase heater
Factory external discharge muffler
Hard start kit required with TXV
Hard start kit part number (S1-2SA067*****)
Fan diameter (in.)
Fan motor
Coil
Liquid refrigeration piping outdoor (field installed)
Vapor refrigeration piping outdoor (field Installed)
7
Unit charge (lb - oz)
Charge (oz/ft)
Operating weight (lb)
1. Rated in accordance with AHRI Standard 110-2012, utilization range A.
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
4. Rotary compressor models are limited to an equivalent length of refrigeration piping of 100 ft with no exceptions.
5. Refer to the Hard Start Kit Accessory Installation Manual for the hard start kit part number for each model. The hard start kit is a field installed accessory.
6. For applications with non-standard vapor line sizes, refer to the APPLICATIONS AND ACCESSORIES section in the Technical Guide.
7. The unit charge is correct for the outdoor unit, smallest matched indoor unit, and 15 ft of refrigerant tubing. For tubing lengths other than 15 ft, add or subtract the
amount of refrigerant, using the difference in actual refrigeration piping length (not the equivalent length) multiplied by the per foot value.
‡ The adapter fitting must be field installed for the required 1 1/8 in. refrigeration piping.
Johnson Controls Ducted Systems
2
3
4
Type
Rated load (A)
Locked rotor (A)
5
Rated HP
Rated load (A)
Nominal RPM
Nominal CFM
Face area (sq ft)
Rows deep
Fins per inch
6
YFK24B21S YFK36B21S
208-230 V, 1 60 Hz
15.3 21.4
25 35
20 25
2-stage scroll 2-stage scroll
10.0 14.8
62.9 84.2
No No
No No
No No
10106 10106
26 26
1/3 1/3
2.80 2.80
574 689
2650 3350
26.40 31.20
1 2
25 22
3/8 3/8
3/4 3/4
8 - 8 13 - 6
0.62 0.62
195 265

DIMENSIONS

Unit
model
YFK24B21S 39 1/2
YFK36B21S
YFK48B21S
YFK60B21S
‡ The adapter fitting must be field installed for the required 1 1/8 in. refrigeration pip-
ing.
Notes:
• All dimensions are in inches and are subject to change without notice.
• The overall height is from the bottom of the base pan to the top of the fan
guard.
• The overall length and width include screw heads.
5545023-YTG-G-1121
YFK48B21S
187 to 252
28.2
45
30
2-stage scroll
20.4
122.1
No
No
No
10106
26
1/3
2.80
800
3925
31.20
2
22
3/8
7/8
15 - 1
0.67
295
Dimensions Refrigerant connection
(in.) service valve size (in.)
A B C Liquid
38 34 1/4
46 38 34 1/4
3/8
46 38 34 1/4
46 38 34 1/4
YFK60B21S
31.4
50
35
2-stage scroll
22.9
147.2
No
No
No
10106
26
1/3
2.80
777
3900
31.20
2
22
3/8
1 1/8 ‡
16 - 11
0.75
295
Vapor
3/4
7/8
7/8 ‡
3
