COOLING CAPACITY - Upflow, Downflow and Horizontal Furnaces and Coils (Coil Only Ratings)

UNIT MODEL
MODEL
YFK24B21S CF/CM/CU30B
YFK24B21S CF/CM/CU30B
YFK24B21S CF/CM/CU42C
YFK24B21S CF/CM/CU42C
YFK24B21S CF/CM/CU48C
YFK24B21S CF/CM/CU48C
YFK24B21S CF/CM/CU60C
YFK24B21S CF/CM/CU60C
YFK24B21S CF/CM36A
YFK24B21S CF/CM36A
YFK24B21S CF/CM36C
YFK24B21S CF/CM36C
YFK24B21S CF/CM48D
YFK24B21S CF/CM48D
YFK24B21S CF/CM60D
YFK24B21S CF/CM60D
YFK24B21S XAF/XAUB36D
YFK24B21S XAF/XAUB36D
YFK24B21S XAF/XAUC60G
YFK24B21S XAF/XAUC60G
YFK24B21S XAF/XAUD60G
YFK24B21S XAF/XAUD60G
YFK24B21S XAFA30D
YFK24B21S XAFA30D
YFK24B21S XAFC36D
YFK24B21S XAFC36D
YFK24B21S XAFD48F
YFK24B21S XAFD48F
YFK24B21S XAHB36D
YFK24B21S XAHB36D
YFK24B21S XAHC36D
YFK24B21S XAHC36D
YFK24B21S XAHC48F
YFK24B21S XAHC48F
YFK24B21S XAHC60G
YFK24B21S XAHC60G
YFK24B21S XAHD48F
YFK24B21S XAHD48F
YFK24B21S XAHD60G
YFK24B21S XAHD60G
YFK36B21S CF/CM/CU36B
YFK36B21S CF/CM/CU36B
YFK36B21S CF/CM/CU36C
YFK36B21S CF/CM/CU36C
YFK36B21S CF/CM/CU42C
YFK36B21S CF/CM/CU42C
YFK36B21S CF/CM/CU48C
YFK36B21S CF/CM/CU48C
YFK36B21S CF/CM/CU60C
YFK36B21S CF/CM/CU60C
YFK36B21S CF/CM48D
YFK36B21S CF/CM48D
Johnson Controls Ducted Systems
COIL
CFM RANGE
(MIN.-MAX.)
WIDTH
17.5 550 - 650
17.5 650 - 950
21.0 550 - 650
21.0 650 - 950
21.0 550 - 650
21.0 650 - 950
21.0 550 - 650
21.0 650 - 950
14.5 550 - 650
14.5 650 - 950
21.0 550 - 650
21.0 650 - 950
24.5 550 - 650
24.5 650 - 950
24.5 550 - 650
24.5 650 - 950
17.5 550 - 650
17.5 650 - 950
21.0 550 - 650
21.0 650 - 950
24.5 550 - 650
24.5 650 - 950
14.5 550 - 650
14.5 650 - 950
21.0 550 - 650
21.0 650 - 950
24.5 550 - 650
24.5 650 - 950
17.5 550 - 650
17.5 650 - 950
21.0 550 - 650
21.0 650 - 950
21.0 550 - 650
21.0 650 - 950
21.0 550 - 650
21.0 650 - 950
24.5 550 - 650
24.5 650 - 950
21.0 550 - 650
21.0 650 - 950
17.5 800 - 1000
17.5 1000 - 1400
21.0 800 - 1000
21.0 1000 - 1400
21.0 800 - 1000
21.0 1000 - 1400
21.0 800 - 1000
21.0 1000 - 1400
21.0 800 - 1000
21.0 1000 - 1400
24.5 800 - 1000
24.5 1000 - 1400
NET MBH
STAGE
RATED
CFM
TOTAL
1 600 19.2
2 800 23.0
1 600 19.4
2 800 23.4
1 600 19.4
2 800 23.4
1 600 19.5
2 800 23.6
1 600 19.2
2 800 23.4
1 600 19.2
2 800 23.4
1 600 19.4
2 800 23.4
1 600 19.3
2 800 23.4
1 600 19.7
2 800 23.4
1 600 19.9
2 800 23.6
1 600 19.9
2 800 23.6
1 600 19.7
2 800 23.4
1 600 19.7
2 800 23.4
1 600 19.7
2 800 23.4
1 600 19.7
2 800 23.4
1 600 19.7
2 800 23.4
1 600 19.7
2 800 23.4
1 600 19.9
2 800 23.6
1 600 19.7
2 800 23.4
1 600 19.9
2 800 23.6
1 900 27.6
2 1200 34.4
1 900 28.2
2 1200 34.4
1 900 28.6
2 1200 34.8
1 900 28.8
2 1200 34.8
1 900 28.8
2 1200 35.4
1 900 28.0
2 1200 34.8
5545023-YTG-G-1121
COOLING
1
SEER EER
SENS.
14.5 14.50 20.00
17.9 14.50 12.25
14.5 14.50 20.37
18.4 14.50 12.25
13.3 15.00 20.37
16.7 15.00 12.50
14.5 15.00 20.46
18.4 15.00 12.50
13.1 14.75 20.90
16.7 — 12.50
13.1 14.75 20.90
16.7 — 12.50
13.3 15.00 21.25
17.0 — 12.50
13.2 14.75 21.05
16.8 — 12.50
13.9 14.75 21.70
17.5 — 12.50
14.0 15.00 22.05
17.3 — 12.50
14.0 15.00 22.05
17.3 — 12.50
13.9 14.75 21.70
17.5 — 12.50
13.9 14.75 21.70
17.5 — 12.50
13.7 15.00 21.65
17.1 — 12.50
13.9 14.75 21.70
17.5 — 12.50
13.9 14.75 21.70
17.5 — 12.50
13.7 15.00 21.65
17.1 — 12.50
14.0 15.00 22.05
17.3 — 12.50
13.7 15.00 21.65
17.1 — 12.50
14.0 15.00 22.05
17.3 — 12.50
19.5 14.50 20.25
25.0 — 12.75
22.2 15.00 18.41
27.6 15.00 12.50
21.6 15.00 18.87
27.8 15.00 12.25
22.0 15.00 19.00
28.0 15.00 12.25
21.8 15.00 19.00
27.4 15.00 12.25
19.9 14.75 20.65
25.4 — 12.75
