MC30-R2 MO-0462-ING Doc. N° 1. General Utilization and Commissioning Directions Always make reference to the specific description of the product and to the Manufacturer's instruction. Carefully observe the following warnings. 1.1 - Storage and Transportation Must comply with the environmental conditions stated in the product's specification or by the applicable IEC standards.
MC30-R2 MO-0462-ING Doc. N° 1.10 - Maintenance Make reference to the instruction manual of the Manufacturer; maintenance must be carried-out by specially trained people and in strict conformity with the safety regulations. 1.11 - Waste Disposal of Electrical & Electronic Equipment (Applicable throughout the European Union and other European countries with separate collection program).
MC30-R2 MO-0462-ING Doc. N° 2. General The MC is a very innovative and versatile line of Protective Relays which takes advantage of the long and successful experience coming from the M-Line. The main features of the MC-Line relays are: Compact draw-out execution for Flush Mounting or for assembly in 19” 3U chassis for 19” Rack systems.
MC30-R2 MO-0462-ING Doc. N° 2.2 - Operation and Algorithms 2.2.1 - Reference Input Values Display Description Setting Range Step Unit Rated Primary current of phase C.T. 9999 Rated Secondary current of phase C.T. Reference primary current of the relay 9999...
Page 7
MC30-R2 MO-0462-ING Doc. N° 2.2.2.4 - Algorithm of the time current curves The Time Current Curves are generally calculated with the following equation : • • t(I) α ...
MC30-R2 MO-0462-ING Doc. N° 3.2 - I> (1F51) - First overcurrent protection level FuncEnab → Enable [Disable / Enable] Options → [D / A / B / C / MI / VI / I / EI / / SI ] →...
MC30-R2 MO-0462-ING Doc. N° 3.5 - Io> (1F51N) - First Earth Fault protection level FuncEnab → Enable [Disable / Enable] Options → [D / A / B / C / I / VI / EI / MI / SI ] →...
MC30-R2 MO-0462-ING Doc. N° 4. Logic Blocking of Functions 4.1 - Blocking Outputs The instantaneous element of each of the protection functions (1F50, 2F50, 3F50, 1F50N, 2F50N, 3F50N) can be programmed to control one of the Output Relays. This relay picks-up as soon as the input quantity exceeds the set trip level of the Protection Function and it automatically resets when the input quantity drops below the function reset level (95% of the trip level) or,...
MC30-R2 MO-0462-ING Doc. N° 6. Digital Inputs Three optoisolated, selfpowered Digital Inputs D1, D2, D3 are provided. A Digital Input is activated when its terminals are shorted by a cold contact. (terminals 22 - 19) : It is usable as Function Blocking Input...
MC30-R2 MO-0462-ING Doc. N° 8. Relay Management The relay can be totally managed locally, either by the RS232 communication port or by the 4 key buttons and the LCD display, or remotely via the communication bus RS485 connected to the rear terminal blocks. The 2 line x 8 characters LCD display shows the available information.
MC30-R2 MO-0462-ING Doc. N° 9. Signalizations Four signal leds are available on the Front Face Panel: Illuminated when C/B open status is detected. ❑ OPEN (Digital Input D3 Open) Illuminated when C/B close status is detected. ❑ (Digital Input D3 closed) CLOSED Flashing when Breaker Failure is detected.
Note: any change of this setting becomes valid at the next power on. Each relay is identified by its programmable address code (NodeAd) and can be called from the P.C. A dedicated communication software (MSCom) for windows is available on www.microelettrica.com. Maximum length of the serial bus can be up to 200m.
MC30-R2 MO-0462-ING Doc. N° 11.2 - Communication Port on Front Face Panel This port is used for communication through the Front Face Panel between a local Lap-top PC. The physical link is RS232 by the standard female 9-pin D-sub connector available on the Front Face Panel.
MC30-R2 MO-0462-ING Doc. N° 12. MENU AND VARIABLES 12.1 - Real Time Measurements Scrolling display of the Real Time Measurements is the Default operation. Scrolling can be stopped at any of the measurements and restarted by pressing the Reset button...
MC30-R2 MO-0462-ING Doc. N° 12.4 – Trip/Ev. (Event Recording) The MC records any tripping and stores the information relevant to the last five tripping of protection functions (FIFO). Each event recording includes the following information. “Real Time Meas” “LastTrip” event, to scroll available events, to “Rec #”...
MC30-R2 MO-0462-ING Doc. N° 12.5 - R/W Set (Programming / Reading the Relay Settings) “Main Menu” select “Function” select among following sub menus: 12.5.1 - CommAdd (Communication Address) “CommAdd” “Add: #” “Password ????” (if not yet entered; see § Password) to select the Address (1-250) to validate.
MC30-R2 MO-0462-ING Doc. N° 12.5.4 - Function (Functions) “Function”, function, to scroll available Functions, to Read/Write setting of the selected function, to select the different definable fields - FuncEnab - TripLev - Options - Timers to access the selected field and read the actual setting of the relevant variable to modify the actual setting;...
Page 31
MC30-R2 MO-0462-ING Doc. N° Display Description Setting Range Step Default Function Type Variable Unit Value FuncEnab → Enable Enable of the protection function Enable/Disable (3F51N) Options → Disable Operation controlled by Blocking Digital Input Enable/Disable Enable Function operation triggers the oscillographic wave...
MC30-R2 MO-0462-ING Doc. N° 12.6 - RelayCfg (Relay Configuration) To associate one of the Output Relays to one or more functions : enter the menu “R/W Set”, select “Relay Cfg”, select the “Relay #” to be programmed, select “Link”; at this stage the list of the available functions is displayed.
MC30-R2 MO-0462-ING Doc. N° 12.7 - Commands “ Commands “ Control, to select other available control, to operate selected control. Display Description Clear Erase memory of Trip Counters, Event Records. Test Starts a relay diagnostic test Reset Reset after trip...
OK button when the password is requested. 15. Maintenance No maintenance is required. In case of malfunctioning please contact Microelettrica Scientifica Service or the local Authorised Dealer mentioning the relay's Serial No reported in the label on relays enclosure.
MC30-R2 MO-0462-ING Doc. N° 19. Direction for Pcb's Draw-Out and Plug-In 19.1 - Draw-Out Rotate clockwise the screws in the horizontal position of the screws-driver mark. Draw-out the PCB by pulling on the handle 19.2 - Plug-In Rotate clockwise the screws in the horizontal position of the screws-driver mark.
