YEEUU S1 Smart Lock Quick Start Manual

S1 Smart Lock
Please follow us on YouTube channel: YEEUU

Lock Show

1
2
3
4
1 Door Card Identification Area
2
Fingerprint Identification Area
3 Key Open Area
4 Password Area
5 Battery Compartment Area
6 Anti Lock Knob

Basic Parameters

Door Opening Method: fingerprint, card, password, APP, mechanical key
Storage Capacity: 100PCS of door cards + fingerprints + passwords
Working Voltage: 3 No.7 AAA alkaline dry batteries
Battery Life: Up to 1 year (unlock 10 times a day)
Working Temperature: -20°C ~ 70°C
Working Humidity: 40%RH ~ 80%RH
Fitting category A: single latch
Door Thickness: 30mm-80mm
Door Prep: 54mm diameter face hole &25mm diameter latch hole

Daily Maintenance

· Installation environment: requires at least a canopy, do not keep the lock
completely exposed in open air.
· Please do not scratch the fingerprint identification area with a sharp
object.
· Please exchange both three batteries at the same time, do not use
mixed new batteries with old ones.
· The mechanical key is a measure for emergency door opening, please
keep at least 1 mechanical key in a safe place other than home(e.g. office,
parents' house).
· Please adjust the door or door frame in time if it deforms, otherwise the
latch will not enter the door frame hole position smoothly.

Instructions

Note: Please install 3 x No.7 AAA alkaline dry batteries before use.
Download APP:
Log in AppStore/GooglePlay to search "YEEUU" and download the APP.
Add device:
Register and log in "YEEUU" account; click "Add Device" or click symbol
"+" at the upper right corner on "Home page"; select "Auto Scan" to start
searching; after the device is searched, click "next" to connect the lock to
be added.
Add/use fingerprint to open the door(Applicable fingerprint version):
Log in "YEEUU" APP; select the device and enter "Settings" page; click
"Fingerprint Management" to enter the page; click "Add Fingerprint" at
the upper right corner and put the finger on the fingerprint identification
area for admission.
Add/use door card to open the door:
Log in "YEEUU" APP; select the device and enter "Settings" page; click
"Door Card Management" to enter the page; click "Add Door Card" at the
upper right corner and then put the door card on the card identification
area for admission.
Add Password:
Log in "YEEUU" APP; Select the device and enter the "Settings" page;
click "Password Management" to enter the page; click "Add Password" to
set the password; Please note that the initial device password is
"123456".
Use APP to open the door:
Log in "YEEUU" APP; select the page for the device to be entered, click
the icon at the page center after your APP is connected with the lock; turn
the handle to open the door when the green light flashes.
View records:
Log in "YEEUU" APP; select the page for the device to be entered; after
your APP is connected with the lock, click
"Opening Record/Alarm" to enter the page to view opening/alarm re-
cords.
Unbind the door lock：
Unbind the door lock: [Remove Device] button shows up when a non-ad-
ministrator user performs the above mentioned operations, click it and
follow the prompt to unbind.
Low Voltage Alarm:
Yellow light flashes 2 times.
Operation Failed:
Red light flashes 2 times, buzzing 2 times.
Error Lock:
Red light flashes 5 times.
Frequently Asked Question
Opening door by mobile phone fails.
Check whether the batteries are loaded and working properly; Check the
networking status of mobile phone and perform operation again; Remove
the batteries and re-load.
Opening door by card fails.
Check whether the batteries are loaded and working properly; Confirm
whether the card has been added; Remove the batteries and re-load.
Opening door by fingerprint fails.
Check whether the batteries are loaded and working properly; Confirm
whether the fingerprint has been added; Remove the batteries and
re-load; Ensure that the finger is dry.
Yellow light flashes when opening the door.
Low power, please replace 3 No.7 AAA alkaline dry batteries in time.
Red light flashes 5 times when opening the door.
Error in lock, please try to unlock the door by fingerprint/door card/pass-
word 1 minute later, or use the APP to unlock it.
No response when opening the door.
Please check if the batteries are loose; If the batteries are dead, please
replace the batteries.
Login/registration cannot be performed normally.
Please check whether the network is running properly.
Quick Start Guide
or visit our website: YEEUU.com
or email to support@yeeuu.com
to get more info of operation manual.
Front Lever
6
5
Back Lever
