Collar AquaLighter 3 Marine 30 Instructions

Fig.1
1. LED illumination lamp AquaLighter 3 Marine
2. Power supply
3. Mounting
AquaLighter 3 Marine User Manual Guide
Dear Sir and Madam,
We thank you for choosing our product. We assure you that you will be
satisfied with the work of this illumination lamp. Please, study this User
Manual Guide before use in order to avoid problems connected to its usage.
Intended Use and Specifications of the Product
AquaLighter 3 Marine LED illumination lamp is designed to function over the
water surface and is used for illumination of the marine aquariums. The
movable feet allow you to use the illumination lamp for aquariums of different
length. The source of illumination of the lamp is bright LEDs of the latest
generation produced by OSRAM (Germany). Unlike fluorescent tube aquarium
lamps, the illumination by AquaLighter 3 Marine creates a dimensional
perception of the aquarium, simulating midday time daylight at the reef.
AquaLighter 3 Marine brings your aquarium to life!
Especially elaborated illumination spectrum of the LEDs lets you successfully
maintain most of the sea plant and animal species. The illumination lamp has
a 3-channel system of illumination sources management and can be
controlled by the external AquaLighter Device controller. The external
controller is connected to the illumination lamp through a FireWire plug
connector on the butt end part of the illumination lamp.
ATTENTION!
It is strictly forbidden to connect other devices to the controller through
external FireWire plug connectors! Such action will bring these devices and
the controller out of order.
Technical characteristic
Types:
30
Parameters:
Voltage + frequency AC110~230V (50-60Hz) / DC15V/DC24V/DC36V, 2A
Light temperature, K 12000-15000
Power, Watt 22
Luminous flux, Lum 1480
Length, mm 280х75х33 580х75х33
Ingress protection rating - IP40

AquaLighter 3 Marine Illumination Management Channels:

1st Channel - cold-white LEDs (light temperature up to 7500К).
2nd Channel – warm-white LEDs (light temperature up to 3000К) and hyper red
LED with a peak emission at wavelengths of 649-666 nm is used. Such
wavelength coincides with the absorption peak of chlorophyll A, the most
affordable source of energy for the plant growth.
3rd Channel - cold-white LEDs (light temperature up to 7500К).
The illumination lamp can be used for aquariums with a wall thickness of up to
12 mm.

Safety Usage Rules

The device you have purchased is manufactured in compliance with the norms
applicable on the territory of Ukraine and the European Union. For long lasting
and safe usage, please do study the safety rules listed below:
1. This device is designed to be used only within indoor areas and only for its
intended use.
2. The voltage rating of the power supply system has to be exactly the same as
the voltage rating indicated on the device.
3. It is forbidden to submerge the device in water! Even a short time
submersion of the device in water can cause damage and can lead to loss of
warranty obligations. If the device was accidentally submerged in water, it is
strictly forbidden to connect it to the power supply! If such situations arise,
please contact the manufacturer for the repair and further safe usage of the
device.
4. It is forbidden to use the device if the device or its electrical cord is damaged.
It is recommended to check the condition of electrical cord each time before
switching it on.
5. Before you switch on the illumination lamp, please make sure it is fixed
safely on the walls of the aquarium.

Preparation for Work

Take the protective film off the illumination lamp. Fasten the feet on the body of
the illumination lamp as shown in Fig. 1.

Assembly and Startup

Place the illumination lamp on the aquarium, moving the feet along the body of
the device until you reach the necessary length. Having fixed the illumination
lamp safely on the walls of the aquarium, plug in the plug of the power supply
cord into the power supply socket situated on the illumination lamp. The device
is ready to use. Connect the power supply block to the power supply system.

Maintenance

The device does not require any special maintenance. If necessary, clean the
body of the illumination lamp from residues resting on it with the help of soft
tissue or a sponge.
* LED lamp AquaLighter 3 90 сm also has special fixing sets with which you can
hang the lamp above the aquarium.

Warranty

The manufacturer gives a warranty of 24 months from the purchase date.
The warranty covers damages that appeared due to the fault of the
manufacturer, i.e., material defects, etc. The warranty does not cover damages
that appeared due to the improper or unintended use of the illumination lamp.
60 90
Attention! Any trials to change the structure of the device, or dismantling of
the device that, fall out of the scope of regular intended use or maintenance
lead to loss of warranty obligations.
In case improper functioning of the device is detected, please contact technical
39 57
support. The condition for accepting the guarantee is conformity of the date of
sale to the date of the warranty period specified in the warranty card. The
2960 4440
present warranty conditions do not exclude, limit, or cease the rights of the
880х75х33
buyer granted by the applicable legislation of the country where the sale was
made.
YOUR
LED LAMP
FOR AQUARIUM
Aquarium comes alive!
30 cm
60 cm
90 cm
www.aqualighter.com
