Summary of Contents for Pyle PBKSRB40
-
Page 2: Box Contents
Please read all instructions before use for the best performance of this product. Save these instructions for future reference. Box Contents MUTE VOL+ VOL- COAX LINE MOVIE MUSIC DIALOG Bookshelf Speaker Remote Control Quick Start RCA to RCA Stereo RCA to RCA to RCA audio cable 3.5mm audio cable... - Page 3 Music -> Dialogue -> Movie 04. Volume control TREB 05. Treble control SPEAKER OUT 06. Bass control BASS Model: PBKSRB40 Power Consumption: 60W 07. Optical input port DC IN 19-21v 08. Coaxial input port Active Speaker 09. Line in input port 10.
-
Page 4: Connection Diagram
Connection Diagram BT Device BT signal up to 30 feet COAX VOLUME LINE IN TREB SPEAKER OUT BASS Model: PBKSRB40 Power Consumption: 60W SPEAKER IN DC IN 19-24v Active Speaker Passive Speaker Coaxial cable Digital Optical cable (not supplied) (supplied) (not supplied) Stereo RCA to 3.5mm audio cable... -
Page 5: Connecting With A Tv
Connecting with a TV Active Speaker Optical digital cable (supplied) RCA to 3.5mm cable (supplied) Coaxial cable (not supplied) Method 1. Connecting using an Optical cable. Select Optical mode and set the TV’s audio output to “PCM”. (More information on PCM page) Method 2. - Page 6 1. Press "Menu" on the TV’s remote control. 2. Press the arrow keys on the remote to scroll to "Audio Settings." 3. Press "OK" on the remote control. 4. Scroll to "Advanced Audio" and press "OK". Some televisions may not have an"Advanced Audio" menu and may list various audio settings instead.
-
Page 7: Troubleshooting
E ective BT transmission range is 10 meters, make sure operation is within the range. • Try another BT device for connection. The PBKSRB40 Bookshelf Speaker does not turn on Check if mains power is connected or if the wall outlet is switched on. Speci cations Power output:... - Page 8 Questions? Comments? We are here to help! Phone: (1) 718-535-1800 Email: support@pyleusa.com...
