- Page 1 HiManager USER MANUAL V1.00...
-
Page 2: Safety And Warnings
1. SAFETY AND WARNINGS 1.1 Safety Instructions HiManager, produced by Suzhou Hypontech Co,. Ltd., is designed, tested and manufactured strictly aligned with relative safety regulation. As an electric device, installation and maintenance shall follow instructions stated in this document. Incorrect operation may cause physical or financial damage to the operator or third parties. -
Page 3: General Introduction
2. General Introduction 2.1 Product Introduction HiManager is a PV system monitoring device. Together with ethernet, HiManager can collect data from inverters, smart meters and other dataloggers, therefore, to actively control power output, data configuration and firmware update remotely via HiPortal. - Page 4 Interface Power Adapter Input for DRED Port for connecting ethernet cable RS485 COM1: for connecting Inverter RS485 COM2: for connecting Smart Meter or Inverter Port for USB connection Reset Button 2.3LEDIndicator The LEDs indicate of the product: "PWR" > Power Status ...
- Page 5 LED Indicator Status Explanation Glowing red light Device operation normal Flashing red light Unstable power supply No power supply Glowing green light System operation normal Flashing green light System booting or resetting System not operating Glowing yellow light Cloud server connected Flashing yellow light Internet connected, no connection to cloud...
-
Page 6: Installation
- 2* Expansion Bolts 3.2 Installing the product 3.2.1 Positioning Protection level of HiManager is IP20, it MUST be mounted indoor. Weight and dimension of HiManager must be considered to choose installation method and position. Well air ventilation, no direct sun light. - Page 7 Put HiManager on a horizontal surface. Please make sure to place HiManager on a horizontal surface to avoid slipping down. Keep distance between HiManager and other cables to avoid signal interference. Mounting on wall: Mark 2 drill holes on the wall and align them horizontally.
-
Page 8: Connecting The Product
4. CONNECTING THE PRODUCT 4.1 Connection Area Power Adapter Input for DRED Port for connecting ethernet cable RS485 COM1: for connecting Inverter RS485 COM2: for connecting Smart Meter or Inverter Port for USB connection Reset Button 4.2 Connect to Inverter 4.2.1 To single Inverter The connection port COM1 and COM2 are used for RS485 cable connections. - Page 9 Multiple inverters can be connected in string. Inverters are inter-connected via COM1, and the last inverter in string connects to COM1 on HiManager. Please be advised to connect A to A and B to B. Maximum connection is up to 16 inverters.
- Page 10 Procedure of Installing DRED on HiManager 1. Prepare the RJ45 plug for DRED connection. 2. Insert the plug into the DRED socket on HiManager until the plug snaps into place. 4.5 Connect to Ethernet 1. Insert the RJ45 plug of the network cable into the Ethernet port until the plug snaps into place.
- Page 11 CO M 1 CO M 2 P O W E R D R E D E T H E R N E T U S B R E S E T 路由器必须支持 DHCP 服务且已经激活 DHCP 服务...
- Page 12 5. Configuration Please find further instructions from document HiPortal User Manual EN. This document can be found in www.hypontech.com/xiazai/.
-
Page 13: Technical Parameter
6. Technical Parameter MODEL HiManager ELECTRICAL PARAMETERS Input Voltage / V DC 7.5 - 12 Input Current / mA Max. Power Consumption / W Power Supply Type AC Adaptor Connection Interface Ethernet 10/100 Mbit/s RS485 COMMUNICATION RS485 Communication Range / m...
