Ozone Gas Detector Pro

Catalog #

Description/Content

AMS.E4002GD

Ozilla® Ozone Gas Detector Pro,

rechargeable, 0.00-50.00 PPM

Wall charger and USB cord

Calibration adaptor

Shipping and

Shipped at room temperature. Store in a dry place away

from water and heat sources. Guaranteed for 1 year.

Storage:

At all times, care and attention should be exercised in handling and using the Ozilla Ozone Gas

Detector Pro by following the instructions in the manual, using common sense lab practices,

wearing protective lab clothing, eyewear, and breathing masks whenever needed. NEVER use a

damaged or defective instrument to certify that a room or area is free of ozone gas

Exposure to sustained and high levels or ozone gas can be highly irritating to the upper and lower

respiratory tract. The characteristic odor is readily detectable at low concentrations (0.02 ppm to 0.05

ppm). Ozone produces local irritation of the eyes and mucous membranes and may cause pulmonary

edema at high exposure. Systematically, ozone has been reported to mimic the effects of ionizing

radiation, and may cause damage to chromosomal structures. A partial tolerance appears to develop

with repeated exposures. Although most effects are acute, the possibility of chronic lung impairment

should be considered based upon animal experimentation.

Evacuate area with ozone levels that accumulate to sustained 0.3 ppm or higher. Open

doors and windows to allow area to ventilate, and until ozone gas smell is no longer

detectable. If ozone is inhaled, remove person to fresh air. Get medical attention for

any breathing difficulties.

WARNINGS

Catalog #

AMS.E400110

AMS.E400220

AMS.E40010B

AMS.E330110

AMS.E330220

AMS.E100100

AMS.E100200

Table of Contents

Need help?

Do you have a question about the Ozilla AMS.E4002GD and is the answer not in the manual?

Questions and answers

Summary of Contents for amsbio Ozilla AMS.E4002GD

Page 1 Ozone Gas Detector Pro Related Products Catalog # Catalog # Description/Content Amount Ozilla® Ozone Sterilizer*, 110V AMS.E400110 AMS.E4002GD Ozilla® Ozone Gas Detector Pro, 1 Unit Ozilla® Ozone Sterilizer*, 220V AMS.E400220 rechargeable, 0.00-50.00 PPM Ozilla® Ozone Sterilizer Nest AMS.E40010B Wall charger and USB cord 1 each CoolCLAVE™...
Page 2 Ozilla® Ozone Gas Detector Pro INTRODUCTION ® The Ozilla Ozone Gas Detector Pro is the next generation gas detector and a substantial improvement over the original Ozilla Ozone Gas Detector, both in terms of sensitivity, performance, and options. Just like the original device, the Ozilla Ozone Gas Detector Pro is portable, rugged, but it also has a vastly improved backlit color display that is easy to read and more user analog-to-digital ( functions.
Page 3 Ozilla® Ozone Gas Detector Pro section ??? below on how to access saved detector values. The detector has a power saving function where it will go into a low power usage mode after 30 seconds of idle time. When this •...
Page 4 Ozilla® Ozone Gas Detector Pro III. Turning the Instrument On Press power button for three seconds: red alarm light/audible beep will come on briefly followed by a warm up cycle as follows: Figure 4: Detector warms up by Figure 3: Figure 5: initial screen ”ready screen”...
Page 5 Ozilla® Ozone Gas Detector Pro language options are English and Chinese. C. ALARM PARAMETERS SETUP: To enter this mode from the MAIN MENU screen, press the down button to highlight the “Alarm param” option, then press the [OK] button. The following screens are displayed: Alarm Param Sensor Alarm Param...
Page 6 Ozilla® Ozone Gas Detector Pro E. STORED DATA REVIEW: To enter this mode, press the down button to highlight the “History data” option, then press the [OK] button. The following screens are displayed as follows: Segment Number History data Check 1703160939 •...
