Hubbell GAI-Tronics 12538 Series Manual

Speaker Kit and Vacancy Kit
Model 12538-xxx & Model 12539-xxx
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics.
GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,
and such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.

General Information

The Model 12538-xxx Speaker Kit is intended for use with a Model 234SBM Stanchion Broadcast
Module or a Model 234SBA Stanchion Broadcast Assembly. Each speaker kit consists of a weatherproof
speaker mounted to a gasketed plate and wiring harness to connect to the 10458-xxx Electronics Paging
Module.
Qty Description
1 Speaker Assembly
4 #10-32 tamper-resistant screws
4 Washers, felt
The Model 12539-xxx Vacancy Kit is also used with a Model 234SBM Stanchion Broadcast Module or a
Model 234SBA Stanchion Broadcast Assembly. The vacancy kit is used when less than four speakers are
needed in the stanchion.
Qty Description
1 Vacancy Panel Assembly
4 #10-32 tamper-resistant screws
4 Washers, felt

Installation

1. Install the speaker kit or vacancy kit into the stanchion or broadcast module in the desired direction,
carefully feeding wires down to the access panel cutout for connection to the electronics module.
2. Secure each speaker panel with the four #10-32 tamper-resistant screws and felt washers provided.
