SCILOGEX SCI500H-Pro LCD Digital 10x10 Magnetic Hotplate
User Manual
SCI500H-Pro
LCD Digital 10 Square LCD Digital Hotplate
Please read the User Manual carefully before use, and follow all operating
and safety instructions!
Technical specifications and outline are subject to change without prior
notice.
www.scilogex.com
12301409
Ver.20211126
Advertisement
Table of Contents
Related Manuals for Scilogex SCI500H-Pro
Summary of Contents for Scilogex SCI500H-Pro
- Page 1 SCILOGEX SCI500H-Pro LCD Digital 10x10 Magnetic Hotplate User Manual SCI500H-Pro LCD Digital 10 Square LCD Digital Hotplate Please read the User Manual carefully before use, and follow all operating and safety instructions! Technical specifications and outline are subject to change without prior notice.
-
Page 2: Table Of Contents
11. Associated standards and regulations ......10 Contents 12. Specifications ............11 Preface ................1 Service ................1 Warranty ..................1 1. Safety Instructions ............2 2. Proper use ............... 3 3. Inspection ............... 4 3.1 Receiving Inspection ..........4 3.2 Listing of Items ............ -
Page 3: Preface
Please provide the customer care representative with the Preface following information • Serial number on the rear panel Welcome to the “ 10” Square LCD Digital Hotplate”. • Certification Users should read this Manual carefully, follow the • Description of problem (i.e., hardware or software) instructions and procedures, aware... -
Page 4: Safety Instructions
instrument in explosive atmosphere, with hazardous 1. Safety Instructions substances or under water. • Gradually increase the speed, reduce the speed if: Warning! - The instrument is not running smoothly, or container • Read operating instructions moves on the base plate carefully before use. -
Page 5: Proper Use
• The instrument can only be disconnected from the main power supply by pulling out the main or the connector plug. • The voltage stated on the label must correspond to the >100mm main power supply. • Ensure that the main power supply cable does not touch the hotplate. -
Page 6: Inspection
3. Inspection 3.2 Listing of Items The package includes the following items: 3.1 Receiving Inspection Items Unpack the equipment carefully and check for any damages Main unit which may have arisen during transport. Please contact User Manual supplier for technical support. Note: Table 1 If there is any apparent damage to the system,... -
Page 7: Control
4. Control 4.1 Control elements Items Descriptions Temperature The heating function is switched control knob Timer Press the knob,and then press “-“ or “+” can setting heating time value If rotate the heating knob, LCD displays the temperature setting LCD Display value(right side) and real value(left side) SD card... -
Page 8: Display
4.2 Display Display when using SD card Display values in when heating or Rated timer function is switched ON. value/Real value Figure 5 LCD digital model Display temperature when the Temp and heating function is switched ON Display Timer parameter when the Timer timer function is switched ON Display in case of error happening... -
Page 9: Trial Run
5. Trial run • Make sure the required operating voltage and power supply voltage match. • Ensure the socket properly grounded. • Plug in the power cable ensure the power is on and begin initializing. Fuse Connection PT1000 • Place vessel on the work plate. Figure 7 •... -
Page 10: Residual Heat Warning Hot
8. Logging function 7. Residual heat warning HOT In order to prevent the risk of burns from the hotplate, the unit has a residual heat warning function. When the heating function is switched off and the heating plate temperature is still above 50°C, “Hot”... -
Page 11: Faults
The logged data can be checked in Excel format by 10. Maintenance and Cleaning connecting the SD card to a personal computer. Note: • Proper maintenance can keep instruments working The logging function starts automatically when you properly and lengthen its lifetime. press the temperature control knob, and stops when •... -
Page 12: Associated Standards And Regulations
packing. Changes or modifications not expressly approved by the • party responsible for compliance could void the user's The enamel makes the hotplate easier to care for and more resistant to acids and bases. Because of it, however, authority to operate the equipment. the hotplate is also more susceptible to extreme NOTE: This equipment has been tested and found to comply fluctuations in temperature and the force of impact. -
Page 13: Specifications
12. Specifications Work plate Dimension [W x D] 254x254mm 10 inch Work plate material Glass ceramic Heating position Heating temperature range Room Temp.-500 , increment 1 Temperature control accuracy ±1 (<100 )±1%(>100 ) Safety temperature Temperature,time display Timer function 1min-99h59min Temperature display accuracy ±0.1 External temperature sensor... - Page 14 Tel: E-mail: info@ .com www. .com...
