DIAGAUTO MST-500 Instruction Manual

Motorcycle diagnostic
Hide thumbs

Advertisement

Quick Links

Download this manual
深圳宙斯特科技有限公司
MST-500
Motorcycle Diagnostic
Instruction
- 1 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the MST-500 and is the answer not in the manual?

Questions and answers

Related Manuals for DIAGAUTO MST-500

Summary of Contents for DIAGAUTO MST-500

  • Page 1 深圳宙斯特科技有限公司 MST-500 Motorcycle Diagnostic Instruction - 1 -...
  • Page 2 深圳宙斯特科技有限公司 Part 1 Scanner Introduction & Attentions Scanner appearance and keys:  Top view: - 2 -...
  • Page 3 深圳宙斯特科技有限公司 Bottom view:  Diag. accessories: KYMCO SUZUKI-1 SUZUKI-2 YAMAHA - 3 -...

  • Page 4: Buttons Descriptions

    深圳宙斯特科技有限公司 HARTFORD AEON-1 HONDA PIAGGIO/VESPA POWER CABLE MAIN ※Please connect the power cable to the scanner’s 12V socket when diagnosis with YAMAHA models. Buttons descriptions ▲▼ Up down Arrow Keys：Choose items ◄ ►Left right arrow keys：Shift pages Enter：Perform Esc：Return F1,F2,F3,F4 Function keys：Reserved Shift key：Reserved - 4 -...
  • Page 5 深圳宙斯特科技有限公司 Attentions Use restrictions 1. The displays screen and illustrations (such as key markings) in this manual are for illustrative purpose only, and may differ somewhat from the actual items they represent. 2. The contents of this manual are subject to change without notice. 3.

  • Page 6: Part 2 Connection Specifications

    深圳宙斯特科技有限公司 Part 2 Connection Specifications 1、 Scanner accessories  Testing accessories  Connection methods： 1.Connect the main test cable - 6 -...
  • Page 7 深圳宙斯特科技有限公司 2.Connect the diagnostic cable 3.Connect to the car diagnostic - 7 -...
  • Page 8 深圳宙斯特科技有限公司 Part 3 Operation Descriptions （Take SUZUKI GSR600 as sample） 1. Connection Connect Scanner to motorcycle by following the steps of Part 2. 2. Perform function options Start the scanner, it will come out options as below Perform：1.DIAGNOSIS：Enter maintenance diagnostic procedure. Perform：...
  • Page 9 深圳宙斯特科技有限公司 ●Choose one way to enter at random 01. ECU Data. Enter this option will display the information of ECU, as below: - 9 -...
  • Page 10 深圳宙斯特科技有限公司 02.Current Data Current Data is the numeric figures of the working status for motor engine, through this data we can know whether motor works normally. Select Current Data to enter Current Data interface: In the current page, you can press YES to enter waveform function, it is able to display numerical changes of the selected item.
  • Page 11 深圳宙斯特科技有限公司 Just as below in yellow: Please press [F2] if you want to know the item introduction in detais 03.Freeze frame Data In the function list select Freeze frame Data displays: Freeze frame Data option: ●Press <Enter>： - 11 -...
  • Page 12 深圳宙斯特科技有限公司 04.Read fault Data In the function list select Read fault Data displays: Read Fault Code option: ●Press <Enter>： 05.Erease Fault Code: In the function list select Erase Fault Code will display: - 12 -...
  • Page 13 深圳宙斯特科技有限公司 Note! Before erase fault code please switch on the key and not to start engine. Press YES to erase fault code. 06.Actuators Test: In the function list select Actuators Test will display: ●Press <Enter>： Part 4 System Settings And View Version Select menu SYSTEM SETUP , Press <Enter>...
  • Page 14 深圳宙斯特科技有限公司 1. Basic setup This function can set whether the buzzer sound, and modify the current language. Press UP or DOWN to select item, Press LEFT or RIGHT to modify the option’s values. 2. Date and time setup This feature can be set the date and time of the host. - 14 -...
  • Page 15 深圳宙斯特科技有限公司 Press LEFT or RIGHT to select item, Press UP or DOWN to modify the option’s values. 3. View Version Select menu View Version , Press <Enter> to enter next menu, as below: ●Press <Enter>： - 15 -...

  • Page 16: Part 5 Offline Upgrade

    深圳宙斯特科技有限公司 Note: 1. The clock chip need to use button batteries (3.0 ~ 3.3 V) power supply, prevent clock data is lost when the power is cut off. 2. If battery low, date/time will be set to zero when the power is cut off, but does not affect the use of other functions.
  • Page 17 深圳宙斯特科技有限公司 图(1) 图(2) Press ENT to upgrade or press ESC to cancel. ※Note: The scanner use SD card format for FAT32, please pay attention to when formatting the SD card, otherwise the tool will not be able to work properly. - 17 -...
