- Page 1 User Manual PaceBlade MDT-8XX Series MDT with RJ45 connector Transport (fleet / public) Tablet...
-
Page 2: Table Of Contents
Content 1. Safety Precautions ........................3 1.1 Device ..............................3 1.2 Environment ............................3 2. Product Overview ........................4-5 2.1 Package components ..........................4 2.2 Front / Left / Right / Top / Bottom / Rear ..................... 5 3. Getting started ........................6-11 3.1 Inserting SIM card &... -
Page 3: Safety Precautions
1. Safety Precautions 1.1 Device The tablet and the battery should not be thrown into fire and not used in areas where the temperature exceeds the specified values. This can lead to the outbreak of a fire or cause the battery to explode. In addition, this will result in a battery leak and the functionality will be significantly reduced, or, in a worst-case scenario, the tablet can no longer be used. -
Page 4: Product Overview
2. Product Overview 2.1 Package components NFC card RAM mount Cable SIM Card Tape Locking Keys TF Card Tape Screws: 4 nos. 4 nos. 1 no. USB Cable... -
Page 5: Front / Left / Right / Top / Bottom / Rear
2.2 Front / Left / Right / Top / Bottom / Rear Top View Left View Front View Right View Bottom View Rear View... -
Page 6: Getting Started
3. Getting started 3.1 Inserting SIM card & TF card TF/SIM card • Insert the SIM card with the gold contacts facing up. • Insert the TF card with gold contacts facing up. • Push the card in the direction of the arrow as shown in the picture. •... -
Page 7: Mounting The Ram And Cradle
3.2 Mounting the RAM and Cradle Step 2 Main Unit Step 1 Cradle Screws X 4nos. RAM Mount... -
Page 8: Locking Device And Unlocking Device
3.3 Locking Device & Unlocking device Step 1 Insert the key Step 2... -
Page 9: Remove Device From Cradle
3.4 Remove device from cradle 1. Insert the key, rotate the key clockwise to unlock cradle. 2. Press and hold the release button on the cradle. 3. Separate the main unit and cradle. Press & Hold... -
Page 10: Cradle Cable Pin Assignment
3.5 Cradle cable pin assignment Interface There are RJ45 and video input interfaces. 3.6 Turning On Device Press Power button to turn on the device. Power Button... -
Page 11: Charging The Device
3.7 Charging Device Plug into vehicle power supply Notice & Warning PLEASE CHARGE AND DISCHARGE THE DEVICE IN ONE CYCLE AT ROOM TEMPERATATURE WHEN DEVICES ARE STORED FOR HALF A YEAR OR LONGER. -
Page 12: Android Tutorials
4. Android Tutorial 4.1 Start Screen 4.2 Home Screen... -
Page 13: Status Bar
4.3 Status Bar The status bar shows your tablet’s status and notifications The notification panel is your center for new events: like new e-mail, voicemail, updates, and more. Drag down to display notifications. Touch a notification to respond. 4.4 APP Screen... -
Page 14: Switching Between Apps
4.5 Switching between apps Switching between home screen and app screen. Slide your fingers up from the bottom of the home screen. Split screen: • Press the recent key to the right of the touch screen to display the recent applications history. -
Page 15: Viewing Two Apps At Once
4.6 Viewing two apps at once • Select second app displayed at the same time. • When the second app appears, drag it to the left or right side of the screen. • Release the app. You can press and drag the dividing line in the center to resize the apps. -
Page 16: Closing Active Apps
4.7 Closing active Apps: 1. Press the recent key to the right of the touch screen 2. Slide your fingers up from the bottom of the application you want to close 4.8 Turning of the device: Press and hold the power button for about three seconds to choose power off. -
Page 17: Connecting To Networks
5. Connecting to Networks 5.1 Connecting to Wi-Fi network: 1. Tap Settings icon to open settings menu. 2. In the Settings menu, tap Network & internet. 3. Tap the Wi-Fi toggle to enable Wi-Fi connections. 4. When the list of Wi-Fi networks appears, tap an available network. 5. -
Page 18: Using Card Slots
6. Using Card Slots 6.1 Inserting SIM card Insert: SIM Card Puller helps to insert SIM Card easily. -
Page 19: Removing Sim Card
6.2 Removing SIM card Remove: SIM Card Puller helps to pull-out SIM Card easily. -
Page 20: Inserting Tf Card
6.3 Inserting TF card Insert: TF Card Puller helps to insert TF Card easily. -
Page 21: Removing Tf Card
6.4 Removing TF card Step 1: Move the cover Step 2: Pull to remove TF card Remove: TF Card Puller helps to pull-out TF Card easily. -
Page 22: Specification
7. Specification Model 8” MDT860 Hardware MTK platform 2GHz oct core CPU high sensitivity receiver, 64 channels 2 version (EUR and NAR) with voice call: EUR - (European market) • GSM: 900/1800Mhz • WCDMA – 850/900/2100Mhz • FDD (4G, EUR) – B1, B3, B5, B7, B8, B20 4G / 3G module / GSM module NAR- (North American market) -
Page 23: Customization Services
Capacity 6300mAh (default) Battery Standby Operating Time Software Operating System Android version 9.0 Android applications Navigation software Packaging Details 1pc main unit and 1pc cradle 8. Customization Services Topicon’s device management server is developed to allow customers to update various firmware and to make kiosk mode function: •... -
Page 24: Safety & Regulatory Compliance
9. Safety and Regulatory Compliance FCC RF Exposure Information and Statement This device meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health.
