824 Assembly Instruction Sheet
Unit 77
Unit 46
Wedge
Armless Chair
Armless Chair
Unit 46
Armless Chair
Unit 46
Armless Chair
Unit 35
Loveseat
(Left Piece
Separated)
Size
Qty (unit) Leg/unit
35
1
46
4
77
1
Total
(Sectional 1)
Unit 35
Unit 46
Loveseat
(Right Piece
Separated)
Total leg
5
5
2
8
7
7
20
Remove bottom coverings and take out pillows, back
cushions, couch backs, legs, U-brackets and hand bolts.
Advertisement
Summary of Contents for AshleyDirect 824
- Page 1 824 Assembly Instruction Sheet (Sectional 1) Unit 35 Unit 77 Unit 46 Unit 46 Loveseat Wedge Armless Chair Armless Chair (Right Piece Separated) Unit 46 Armless Chair Unit 46 Armless Chair Unit 35 Loveseat (Left Piece Separated) Size Qty (unit) Leg/unit...
- Page 2 Step 1 Place backs on the sofa ends using the KD brackets. Be sure to match back to seat. Step 2 Use 2 hand bolts to connect the Armless Chair with RAF Loveseat/Sofa.
- Page 3 Step 3 Use 2 hand bolts to connect the two Armless chairs together. Step 4 Replace the back and bottom coverings and apply 8 legs to the bottom. Flip unit upright.
- Page 4 Step 5 Continue for the assembly unit on the left. Place backs on the sofa ends using the KD brackets. Be sure to match back to seat. Step 6 Use 2 hand bolts to connect the Armless Chair with Wedge.
- Page 5 Step 7 Use 2 hand bolts to connect the two Armless Chairs together. Step 8 Use 2 hand bolts to connect the LAF Loveseat/Sofa with Armless Chair.
- Page 6 Step 9 Replace the back and bottom coverings and apply 12 legs to the bottom. Flip unit upright.
- Page 7 Step 10 Use the U-Brackets to connect the left and right units together. Place seat and back cushions.
