- Page 1 GAS RANGETOP INSTALLATION GUIDE SPECIFICATIONS, INSTALLATION, AND MORE MODEL NUMBERS: FCTGS5751-30 FCTGS5751-36 FCTGS5751-48...
-
Page 2: Table Of Contents
Important Safety Information Features of You Rangetop Cooktop Burner Grills Installation Electrical Gas Supply Pressure Regulator Gas Shut-off Valve Product Dimensions and Cabinets Exhaust Hood Installation Gas Conversion Operation Gas Supply Connection Ignition Simmer and Boil Burner Grates Griddle Operation Cooktop Cleaning Tips Wire Diagram... - Page 3 Customer service: 1 866-231-8893 opt.2 ext.214 Or email : mysupport@forno.ca If there is a problem, please contact FORNO customer service. All warranty work needs to be authorized by FORNO customer service. All of our authorized service providers are carefully...
- Page 4 Rangetop Safety Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is a safety alert symbol. It will alert you to potential personal or property safety hazards. Obey all safety messages to avoid any property damage, personal injury or death.
- Page 5 WARNING This product can expose you to chemicals including carbon monoxide, which is known to the State of California to cause developmental harm. For more information go to www.P65Warnings.ca.gov The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54 or, in Canada, the Natural Gas and Propane Installation Code, CSA B149.1.
-
Page 6: Important Safety Information
1. Use this rangetop for its intended purpose as described in this instruction manual. 2. Have your rangetop installed and properly grounded by a qualified installer in accordance with the provided installation instructions. 3. Any adjustment and service should be performed only by a qualified rangetop installer or service technician. - Page 7 Cook food thoroughly to help protect against foodborne illness. Minimum safe food temperature recommendations can be found at www.IsItDoneYet.gov and www.fsis.usda.gov. Use a food thermometer to take food temperatures and check several locations. Keep the ventilator hood and grease filter clean to maintain good venting and to avoid grease fires.
-
Page 8: Features Of You Rangetop
Features of Your Rangetop 8 burners Cooktop Burner Grates LED Light Switch Control Panel Not all features are on all models. Appearance may vary. 6 burners 5 burners... - Page 9 Installation Instructions Before using your rangetop 1. Remove all packaging material. 2. Check to make sure you have all of the accessories listed below FCTGS5751-30 15 pieces LPG injector FCTGS5751-36 18 pieces FCTGS5751-48 24 pieces Burner Grills FCTGS5751-30 2 pieces FCTGS5751-36 3 pieces Burner Grills...
-
Page 10: Cooktop Burner Grills Installation
YOU NEED TOOLS FOR INSTALLATION. (not supplied with the rangetop) Tape measure Screwdriver Wrench Socket wrench Allen key &Pencil Protective Adjustable Hammer Adjustable Drill gloves wrench pliers Cooktop Burner Grills Installation Remove the packing materials from the cooktop burner grills. Place the burner grills to the correct position. Check the direction of middle grill on the right as illustrated, the thicker side should be towards the left. -
Page 11: Gas Supply
this rangetop is equipped with a three-prong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-pronged receptacle. cut or removes the grounding prong from the plug. Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. -
Page 12: Pressure Regulator
Pressure Regulator Since service pressure may fluctuate with local demand, every rangetop must be equipped with a pressure regulator on the incoming service line for safe and efficient operation. The pressure regulator shipped with the range has two female threads 1/2" NPT for the 30" 36" and the 48". -
Page 13: Product Dimensions And Cabinets
Product Dimensions and Cabinets FCTGS5751-30 FCTGS5751-36 7"1/2 (190) 7"1/2 (190) FCTGS5751-48 7"1/2 (190) - Page 14 Dimensions and Clearances Cabinet tolerances ± 1/16" (± 1.6 mm) unless otherwise noted. 1 1/2” " (3.8 cm) 10” " (25.4 cm) to typical countertop combustible side thickness wall min. both sides 7 1/2" (19cm) Recommended Mounting platform gas and electrical 36"...
- Page 15 Cabinet/Countertop Dimensions (cont.) Cabinet tolerances ±1/16" (±1.6 mm) unless otherwise noted. 23.7" (60.2 cm) Gas and electrical connections at right rear section of chassis Installed control Countertop panel overhang 1/7/10" (4.35 cm) Cabinet face Mounting platform Installed Rangetop - Side View Gas connection and power cord may be routed through bottom or back of chassis Increase countertop and overhang...
-
Page 16: Exhaust Hood Installation
Exhaust Hood Installation The bottom of the hood should be 30" min. to 36" above the countertop. This would typically result in the bottom of the hood being 66" to 72" above the floor. These dimensions provide safe and efficient operation of the hood. After Installation: 1. - Page 17 The conversion is not completed if all 5 steps have not been concluded properly. Before performing the gas conversion, locate the package containing the replacement nozzles shipped with every rangetop. STEP 1: Pressure Regulator To access the gas regulator, pull the rangetop away from the cabinet wall. The gas regulator is located at the back of the rangetop.
- Page 18 Model:FCTGS5751-30 Model:FCTGS5751-36 Model:FCTGS5751-48 Save the nozzles removed from the rangetop for future use.
- Page 19 STEP 3: Gas Valve a. Remove control knobs. b. Using a flat screwdriver, adjust main burner bypass jets toward to 1/4 circle for LP until the flame is normal. For 9,000btu and 15,000btu burners, please refer to fig.1, which is in the center of valve axis.
-
Page 20: Gas Supply Connection
Gas Supply Connection All connections to the gas piping must be wrench-tightened. Do not overtighten or allow pipes to turn when tightening. When all connections have been made, check that all rangetop controls are in the “OFF” position and turn on the main gas supply valve. If a flexible metal connector is being used, verify it is not kinked, then attach the gas supply line to the regulator on the rangetop. -
Page 21: Ignition
Ignition To light the cooktop burners, push and turn the appropriate control knob counter clockwise to a “Hi” position. You will hear a clicking noise –the sound of the electric spark igniting the burner. Once burner ignition has been achieved, turn the burner control knob to adjust the flame size. If the knob stays at “Hi”, it will continue to click. -
Page 22: Burner Grates
Burner Grates 1. The grates must be properly positioned before cooking. Improper installation of the grates may result in scratching of the cooktop and / or poor combustion. 2. Do not operate the burners without a pan or utensil on the grates. Griddle Operation Before Using the Griddle 1. - Page 23 Troubleshooting Tips Before you call for service Check that power is on. Rangetop does not operate Check that electrical power to rangetop and home circuit breaker is on. Burners Do Not Light Or Spark Electrical plug is not plugged into a live power outlet. Randomly Gas supply not turned on.
-
Page 24: Wire Diagram
Wire Diagram... - Page 27 2022.06...
