Generation Lighting Jane 200 Manual

LED TAPE
Step by Step Component Guide
LED tape is an incredibly versatile and long-lasting product that can be used in a wide range
of applications where space may be limited such as under cabinets, cove ceilings, toe kicks,
in cabinets, or even in drawers. Its low profile design and flexibility allow for discrete installation.

CHOOSE YOUR TAPE

At 200 lumens per foot, Jane 200 features high quality LED diodes that meet a stringent
three step binning threshold for maintaining a consistent color of light across an entire run.
2700k
Jane 200 2700k
900006-15
10' tape
900004-15 40' tape

SELECT CONNECTORS

Cord with fold-over clasps on either end for quick and secure connections between two pieces of Jane 200 tape.
Jane Tape-to-Tape
Connector
905001-15

SELECT A TRANSFORMER

Transformers allow you to connect power to your LED tape system. Choose based on your run length of tape.
98745S-12
60W 120V Primary
24VDC Secondary
Electronic Transformer
Black Powder Coated
Enclosure Damp Location
3000k
Jane 200 3000k
900007-15
10' tape
900005-15 40' tape
Jane Connector Cords
905002-15
905006-15 24
3"
905003-15 905007-15 36
6"
905004-15
12" 905040-15 72
905005-15 18"
98746S-12 98747S-12
105W High Output 150W High Output
Electronic Transformer Electronic Transformer
ORDER THIS
POWER CORD:
905000-15
Jane Power Cord
"
"
"
98743S-12
200W High Output
Magnetic Transformer
generationlighting.com
For connecting Jane LED Tape to
a 24v DC transformer. Cord has
bare leads on one end for easy
wiring to the transformer and a
fold-over clasp on the other for
a quick, secure connection to the
LED tape. Length is 96".
