Service Manual
Created: 05 May 2015
T5 INFINIUM
5-Watt Cage-Style Tube Amplifier Head with INFINIUM
Tube Life Multiplier and Reverb
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PCB Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Exploded Drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
© 2015 MUSIC Group IP Ltd. All third party trademarks mentioned belong to their respective owners and are not affiliated with MUSIC Group IP Ltd. All information (including
drawings and diagrams) contained in this document is the property of MUSIC Group IP Ltd., its subsidiaries or content providers, and is protected by intellectual property (copyright,
trademark, patents, etc) laws, international treaty provisions and other laws. Any unauthorized disclosure, use, application, reproduction, modification, lease, sale, transmission or
any other dealings in the information may violate applicable laws and result in civil and/or (where applicable) criminal liabilities and penalties.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for MUSIC Group IP Bugera T5 INFINIUM
- Page 1 Exploded Drawing ............. 15 © 2015 MUSIC Group IP Ltd. All third party trademarks mentioned belong to their respective owners and are not affiliated with MUSIC Group IP Ltd. All information (including drawings and diagrams) contained in this document is the property of MUSIC Group IP Ltd., its subsidiaries or content providers, and is protected by intellectual property (copyright,...
-
Page 2: Specifications
T5 INFINIUM Specifications - Hand-built 5-Watt guitar head driven by 1 x 12AX7 and 1 x EL84 tubes - Authentic preamp design—everything from traditional clean/crunch to modern high-gain sounds - Revolutionary INFINIUM Tube Life Multiplier technology: - Extends the life of your amplifier’s expensive power tube up to 20 times - Provides incredible reliability and consistent tone over the complete lifespan of your tubes - Monitors performance of the power tube continuously and displays defective tube to allow for easy replacement... -
Page 3: Pcb Schematic
T5 INFINIUM PCB Schematic Page 3... - Page 4 T5 INFINIUM PCB Schematic Page 4...
- Page 5 T5 INFINIUM PCB Schematic Page 5...
-
Page 6: Parts List
T5 INFINIUM Parts List Hi Pcb Assemblies Quantity Unit S.Sku M.Sku Description Reference Designators Notes 1.0000 PC A05-B6C01-00102 PCB ASSEMBLY;P0B6C;PCB:1;REV:B;HI;MAIN 1.0000 PC A05-B6C02-00102 PCB ASSEMBLY;P0B6C;PCB:2;REV:B;HI;REAR Assembly Quantity Unit S.Sku M.Sku Description Reference Designators Notes 1.0000 PC A05-B6C01-00202 PCB ASSEMBLY;P0B6C;PCB:1;REV:B;SD;MAIN 1.0000 PC A05-B6C01-00302 PCB ASSEMBLY;P0B6C;PCB:1;REV:B;AI;MAIN 1.0000 PC... - Page 7 T5 INFINIUM Parts List Capacitor Quantity Unit S.Sku M.Sku Description Reference Designators Notes 5.0000 PC CAP E;47uF;25V;PITCH:2mm5;5mm x 11mm;VERTICAL 12.7-15-9mm [P0B6C:1: {5.0}(C26,C50-C51,C54,C56)] *NOT available in DP 2.0000 PC CAP E;100uF;25V;PITCH:2mm5;6mm x 12mm;VERTICAL 12.7-15- [P0B6C:1: {2.0}(C14-C15)] *NOT available in DP 1.0000 PC CAP E;4uF7;50V;PITCH:2mm5;5mm x 11mm;VERTICAL 12.7-15-9mm [P0B6C:1: {1.0}(C30)] *NOT available in DP 2.0000 PC...
-
Page 8: Circuit Protector
T5 INFINIUM Parts List Circuit Protector Quantity Unit S.Sku M.Sku Description Reference Designators Notes 8.0000 PC R21-15201-52000 B21-15201-52000 FUSE CLIP;2 A;V;ZINC PLATING;250V;SERIES;520;FUSE;250 V;PLATING [P0B6C:1: {8.0}(F1A-F4A,F1B-F4B)] 1.0000 PC R22-01512-31501 B22-01512-31501 FUSE;315mA;250V;SLOW BLOW;H-TYPE;5mm x 20mm [P0B6C:1: {1.0}(F4)] 1.0000 PC R22-01513-31501 B22-01513-31501 FUSE;3A15;250V;SLOW BLOW;H-TYPE;5mm x 20mm [P0B6C:1: {1.0}(F1)] 1.0000 PC R22-01513-10001... - Page 9 T5 INFINIUM Parts List Hardware Quantity Unit S.Sku M.Sku Description Reference Designators Notes 1.0000 PC CABLE TIE;NYLON;4in;COLOR: *NOT available in DP 0.5000 G SCREWLOCK;SPEC.NO:01090 *NOT available in DP 1.0000 PC NUT;M;4 MM;4.2 MM;HEX WASHER;8.3 MM;ZINC;BLUE;HEXAGON *NOT available in DP REC.;0.5 MM;M4*0.75mm NUT WITH TEETH EXTERNAL WASHER 1.0000 PC HEX.NUT;12 MM;2 MM;NICKEL;SILVER;0.75 MM *NOT available in DP...
- Page 10 T5 INFINIUM Parts List Quantity Unit S.Sku M.Sku Description Reference Designators Notes 1.0000 PC WASHER;SPRING;INNER DIA:14mm5;OUTER *NOT available in DP DIA:17mm;THICKNESS:1mm5;PLATING:NICKEL 2.0000 PC SILICA GEL;MASS;10g;SPEC.NO:10QB-BB2001-4 *NOT available in DP 1.0000 PC SILICA GEL;MASS;10g;SPEC.NO:10QB-BB2001-4 *NOT available in DP Quantity Unit S.Sku M.Sku Description Reference Designators...
-
Page 11: Plug Socket
T5 INFINIUM Parts List Plastic Part Quantity Unit S.Sku M.Sku Description Reference Designators Notes 4.0000 PC G51-00100-15460 RUBBER FOOT;HARDNESS 75;BLACK;DIA.18X9.8MM;HOLE SIZE 3.5MM;METAL WASHER;DST.NO:001;DPT.NO:1546;(MI- RUBFEET_18X9MM8-REVA.DWG);DIA.18x9.8mm;HOLE SIZE 3.5mm 5.0000 PC G52-00001-15218 PLASTIC;KNOB;P0B47;ABS PA747;BLACK;ROTARY KNOB 1.0000 PC W52-00100-14962 G52-00100-14962 PLASTIC;PUSH KNOB;I00499P;BLACK CHROME;DST.NO:001;DPT.NO:14962;(I00499P-PUSH_KNOB-REVA) 1.0000 PC G53-00000-04668 PLASTIC;JEWEL;P0404;AMBER TRANSLUCENT 2.0000 PC... - Page 12 T5 INFINIUM Parts List Quarz Quantity Unit S.Sku M.Sku Description Reference Designators Notes 1.0000 PC X65-40471-00000 H65-40471-00000 QUARZ;RESONATOR;10MHz;HC49/S;FUNDAMENTAL [P0B6C:1: {1.0}(Q1)] Page 12...
- Page 13 T5 INFINIUM Parts List Resistor Quantity Unit S.Sku M.Sku Description Reference Designators Notes 2.0000 PC RESISTOR;CARBON;2ohm2;5%;0W063;SMD603 [P0B6C:1: {2.0}(R64-R65)] *NOT available in DP 4.0000 PC RESISTOR;CARBON;5ohm1;5%;0W063;SMD603 [P0B6C:1: {4.0}(R41-R42,R44-R45)] *NOT available in DP 1.0000 PC RESISTOR;CARBON;100ohm;5%;0W063;SMD603 [P0B6C:1: {1.0}(R1)] *NOT available in DP 1.0000 PC RESISTOR;CARBON;470ohm;5%;0W063;SMD603 [P0B6C:1: {1.0}(R46)]...
-
Page 14: Vacuum Tube
T5 INFINIUM Parts List Quantity Unit S.Sku M.Sku Description Reference Designators Notes 1.0000 PC RESISTOR;CEMENT;3ohm3;5%;5W;LEAD WIRE;AXIAL [P0B6C:2: {1.0}(R1)] *NOT available in DP 1.0000 PC RESISTOR;CEMENT;220ohm;5%;5W;LEAD [P0B6C:1: {1.0}(R43)] *NOT available in DP WIRE;RADIAL;PITCH:5mm;PRECUT:3mm1+/-0mm5 1.0000 PC RESISTOR;CEMENT;240ohm;5%;5W;LEAD [P0B6C:1: {1.0}(R40)] *NOT available in DP WIRE;RADIAL;PITCH:5mm;PRECUT:3mm1+/-0mm5 1.0000 PC RESISTOR;CEMENT;5Kohm1;5%;5W;LEAD... -
Page 15: Exploded Drawing
T5 INFINIUM Exploded Drawing Page 15... - Page 16 T5 INFINIUM Exploded Drawing Page 16...
- Page 17 T5 INFINIUM Exploded Drawing Page 17...
