Acer LCD Monitor Quick Start Guide (QSG)
Important safety instructions
Please read the following instructions carefully.
1. To clean the LCD monitor screen: Be sure that your monitor is electrically
rated to operate with the AC power available in your location.
• Turn off the LCD monitor and unplug the power cord.
• Spray a non-solvent cleaning solution onto a rag and clean the screen
gently.
• NEVER SPRAY OR POUR ANY LIQUID DIRECTLY ONTO THE
SCREEN OR CASE.
• PLEASE DO NOT USE ANY AMMONIA OR ALCOHOL-BASED
CLEANERS ON THE LCD DISPLAY SCREEN OR CASE.
• Acer will not be liable for damage resulting from use of any ammonia or
alcohol-based cleaners.
2. Do not place the LCD monitor near a window. Exposing the monitor to
rain, moisture or sunlight can severely damage it.
3. Do not apply pressure to the LCD screen. Excessive pressure may cause
permanent damage to the display.
4. Do not remove the cover or attempt to service this unit yourself. An
authorized technician should perform servicing of any nature.
5. Store the LCD monitor in a room with a temperature of -20° to 60°C (-4° to
140°F). Storing the LCD monitor outside this range may result in
permanent damage.
6. Immediately unplug your monitor and call an authorized technician if any
of the following circumstances occur:
• Monitor-to-PC signal cable is frayed or damaged.
• Liquid spills onto the LCD monitor or the monitor is exposed to rain.
• The LCD monitor or case is damaged.
LCD Monitor Quick Start Guide - 1

Advertisement

Table of Contents
loading

Summary of Contents for Acer XZ396QU

  • Page 1 • PLEASE DO NOT USE ANY AMMONIA OR ALCOHOL-BASED CLEANERS ON THE LCD DISPLAY SCREEN OR CASE. • Acer will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. 2. Do not place the LCD monitor near a window. Exposing the monitor to rain, moisture or sunlight can severely damage it.
  • Page 2: Package Contents

    LCD Monitor AC Power Cord DP Cable (Optional) HDMI Cable (Optional) Remote Control Quick Start Guide HDMI LCD Monitor NITRO XZ6 Series/XZ396QU USER GUIDE VESA Mount Screws LCD Monitor Quick Start Guide - 2...
  • Page 3: Attaching The Monitor To The Base

    Attaching the monitor to the base 1. Unpack the box. 2. Take the Styrofoam with display out of the box. 3. Remove the top Styrofoam. 4. Tighten the base and stand arm with three screws. 5. Attach the base of step 4 to the 6.
  • Page 4: Connecting Your Monitor To A Computer

    Connecting Your Monitor to a Computer 1. Make sure both the monitor and computer are powered-OFF. 2. Connect DP Cable (Only DP-input model) a. Make sure both the monitor and computer are powered-OFF. b. Connect the DP cable to the computer. 3.
  • Page 5: External Controls

    External Controls Icon Function description Main menu OSD Hot key 1 (default: Mode) Hot key 2 (default: Brightness) Input source Middle key: Power on, Press more than 5 seconds to turn off the power. Four directions key: Press to any directions key to display first menu. Move the cursor, with four direction.
  • Page 6: Regulations And Safety Notices

    • Consult the dealer or an experienced radio/television technician for help. CE declaration of Conformity Hereby, Acer Inc., declares that this LCD monitor is in compliance with the essential requirements and other relevant provisions of EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU, and RoHS Directive 2011/65/EU and Directive 2009/125/EC with regard to establishing a framework for the setting of ecodesign requirements for energy-related product.
  • Page 7 Disposal of Waste Equipment by Users in Private Household in the European Union This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
  • Page 8: Specification

    SPECIFICATION Model name XZ396QU Driving System TFT Color LCD Size 38.5" W (98 cm) Pixel pitch 0.333 mm Brightness Native: 350 nits; HDR400 mode: peak 400 nits Contrast 100,000,000:1 Max. (ACM) LCD Panel Viewable angle 178° (H) 178° (V) (CR≥10)
  • Page 9 Quick Start Mode * Specifications vary depending on model and/or region. Regulatory Compliance Find manuals and other documents for your Acer product on the official Acer support website. Product Information for EU Energy Label LCD Monitor Quick Start Guide - 9...
