Manual No.3156E R4

Operation Manual for

DTF-201

Oxygen Analyzer

(% Range)

RX-62230＊-A＊＊＊＊＊

Table of Contents

Need help?

Do you have a question about the DTF-201 and is the answer not in the manual?

Questions and answers

Summary of Contents for ENERGY SUPPORT CORPORATION DTF-201

Page 1 Manual No.3156E R4 Operation Manual for DTF-201 Oxygen Analyzer (% Range) RX-62230＊-A＊＊＊＊＊...
Page 3 Cautionary items for safety Observe the following cautionary items for safe operation of the device. Warning 1. When connecting wiring at the terminal of the analyzer, be careful to avoid electric shock. Be sure to turn the power off before connecting wiring. 2.
Page 4 Guarantee 1. Term The term of guarantee of a single piece of equipment shall be one year since the product is delivered. However, if the equipment is built in another unit, the term of guarantee shall be that of the unit. The single unit delivery meant that the receiver, sensor unit, cable are delivered as single unit whereas the equipment built in another unit meant the equipment by combining the sampling flow or to combine to another units are delivered as built-in delivery.
Page 5: Table Of Contents
4-5 Operation for when an Error Occurs ---------------------------------------------------------------------- 18 4-6 Applied Operations -------------------------------------------------------------------------------------------- 19 5. Maintenance ------------------------------------------------------------------------------------------------------------- 22 5-1 Daily and Periodic Inspection ------------------------------------------------------------------------------- 22 5-2 Troubleshooting ------------------------------------------------------------------------------------------------ 23 6. Reference Material ----------------------------------------------------------------------------------------------------- 25 6-1 Standard Specifications -------------------------------------------------------------------------------------- 25 6-2 Drawing name: DTF-201 oxygen analyzer receiver -------------------------------------------------- 26...
Page 6: Introduction
1. Introduction 1-1 Introduction The DTF-201 Oxygen Analyzer is a product of the latest ceramics production technology, using a thick film sensor and digital signal processing technology. This Operation Manual explains how to operate the DTF-201 oxygen analyzer. Please read this manual thoroughly to ensure long, successful operation of your SH-201-C Oxygen Analyzer.
Page 7 Operating Principles of Zirconia Type Oxygen Analyzer (1) Configuration and Functions (See diagram at right.) Heater: Heats the sensor to approximately 800℃. Sensing cell: Sets the oxygen concentration of the reference oxygen chamber to 100%, and measures the oxygen concentration of the gas detection chamber. (See below for detailed principles.) Pumping cell: Sets the oxygen concentration of the gas detection...
Page 8 Sensor Element Construction Heater Exhaust gas O concentration (%) Sensor Heater temperature Heater control Pumping cell Pumping current Output signal Gas detection chamber Pumping current Sensing cell controller Gas diffusion holes Microcurrent to Reference voltage generate Reference oxygen chamber (450 mV) reference oxygen...
Page 9: Name Of Each Part
1-4 Name of each part (1)DTF-201 receiver of oxygen analyzer Name (function) ① POWER lamp (Lit after the power is turned on.) ② Display 1 (5 digits, for display of concentration, data and error) ③ Display 2 (3 digits, for display of range, concentration alarm and channel) ④...
Page 10: Opening The Packaging
2. Unpacking 2-1 Checking the Components and Accessories Part name Part No. Q'ty Remarks RX-622300:AC100V Oxygen analyzer RX-62230＊-A＊ RX-622301:AC200V RX-622303:DC24V Installation fitting CA-1 Accessory NOTE) ※refer to your specifications document. The probe, sensor, relay cables, and others are different depending on the specifications; check those parts off against the specifications document.
Page 11: Installation Method
3-2 Installation Method Installation Cautions ・ This oxygen analyzer is a precision instrument. When installing it, avoid large shocks and applying a load upon it. ・ Its terminal block and connector jut out from the panel, so they are easily damaged. Take care not to knock them during installation.
Page 12 ② Wiring to receiver Connect wiring to the receiver at the terminal block (M3 screws). Take care of the polarity when wiring. Layout of terminal block and description COM1 COM2 OUT1 OUT1 OUT2 OUT2 POWER POWER ＋－＋－ :NO-voltage contact input terminal 1 :NO-voltage contact input terminal 2 :NO-voltage contact input terminal 3...
Page 13: Operation
4. Operation 4-1 Operation Preparation Before you turn the power ON, perform the following inspection. Start pre-operation inspection Is the power cord Connect it. connected properly? Is the connecting cable Connect it. connected properly? Is the analyzer Connect it. input/output wiring connected properly? Is the sample gas piping connected...
Page 14: Start-Up
4-2 Start-up Perform the basic start-up operation as follows. O2 ANALYZER Display 1 ％ POWER Start-up operation RANGE Display 2 Turn power ON. ① When you turn ON the power to the analyzer, the POWER LED lights up and Display 1 starts the countdown.
Page 15: Stop Procedure
4-3 Stop Procedure Stop Procedure Turn OFF the power supply to the oxygen analyzer. There is no power switch on the analyzer, so turn off the Turn OFF the power external power supply. If operation is stopped for a short period such as 1 week or less, do not turn off the power. If operation is stopped for a longer period, once the sample gas is replaced by ambient air, then turn off the power.
Page 16 Key Operation Method Display 1 O2 ANALYZER ％ POWER Display 2 RANGE Key Operation Method Keys During measurement Display 1 is the O Concentration display. Display 2 is the Range or Concentration warning display. ① First, press the key. Press Display 2 will display the CH No.
Page 17 System data Table CH No. Function Setting Data Default Data 0: No display (－－ ― ―) 1: Oxygen concentration 2: Icp 3: Vs *2 – 9 are for 4: Ip1 Display selection 5: Ip2 checking use 6: Vp by we. 7: Vh 8: Ih 9: CPU Ih...
Page 18 CH No. Description Setting data Initial data Output range No. 1 span value 1 - 99999 Output range No. 2 span value Specifications * Check the output range unit Output range No. 3 span value using CH034 - 037. Manual. Output range No.
Page 19 CH No. Description Setting data Initial data 0: No contact output Contact output RY1 function setting 1: Analyzer error 2: Range echo (2 range discrimination) Contact output RY2 function setting 3: Range echo (discrimination of 3 Specifications ranges or more)) Manual.
Page 20 CH No. Description Setting data Initial data Solid and Liquid fuel 0.00 H concentration Solid and Liquid fuel 0.00 S concentration Solid and Liquid fuel 0.00 – 100.00 0.00 N2 concentration Solid and Liquid fuel 0.00 H2O concentration Solid and Liquid fuel 0.00 O2 concentration －...
Page 21 (2) Output Range Switching The output range switching method can be made from 2 methods: range switching by key operation, by Contact input, or by auto range switching. ①Range switching by key operation (Local range switching) By inputting 0 for CH026 and 0 for CH209, you can change output range 1 - 4 for CH020.
Page 22 ② Air, Zero 2 point calibration This analyzer doesn’t need to carry out zero point calibration standardly. How to zero point (0.0%O2point) calibration is shown in the following for the reference. (a) Input 1 to CH276 to set the calibration mode to air and zero 2 point calibration. (b) Send the Air to the Probe transmitter (sensor unit) at 1-3L/min ,and it stabilizes indication.
Page 23: Operation For When An Error Occurs
(e) Input to CH121 for span gas concentration. The concentration of span gas is to use the gas of the 90% in F.S. range. Send the span gas to the Probe transmitter (sensor unit) at 1-3L/min ,and it stabilizes indication. Air point is calibrated in a method to show in (e),(f) of ③. This procedure performs calibration.
Page 24: Applied Operations
4-6 Applied operations (1) Primary delay time setting With the data value input to CH016 (unit: seconds), primary delay can be applied to the concentration output signal. The setting range is 0 - 99 seconds. (2) WET/DRY The output of oxygen concentration when 0 is inputted to CH18 is WET output. When fuel to use is gas fuel, each element concentration (vol %) in the fuel is inputted to CH230 - 239, and 1 is inputted to CH018.
Page 25 (5) Current output adjustment ① Connect an ammeter to check OUT1+ and OUT1- on the analyzer terminal board. ② When CH027 is called up, the display shows "cAL 1". ③ When you press the key, 0 is displayed on display 1. Each time you press the key, display 1 can be switched to 0 and 100.
Page 26 (8) Contact output (RY1 – 4) setting The contact output contents are set using CH200 - 203, and the contact output movement settings are set using CH204 - 207. RY1 contact output functions are set at CH200, and the contact output operation settings are set using CH204.
Page 27: Maintenance
(9) RS232C Communication function setting The measurement status, error codes, range and measurement values can be transmitted. The formats include condition = measurement status (6 bytes), E = error code (2 bytes), RANGE = range No. (1 byte), ppm = measured value (maximum 11 bytes), CR + LF. The communication specifications (bit rate, data length, parity check, stop bit, etc.) are set by ENERGY SUPPORT CORP.
Page 28: Troubleshooting
5-2 Troubleshooting Phenomenon Cause Countermeasure Remarks 0 is input for CH310. Input 201 for CH310. Unable to change Receiver problem Request repair by data. ENERGY SUPPORT CORP. Analyzer error Turn power OFF, then Take occurring ON again after 10 countermeasures in seconds.
Page 29 Phenomenon Cause Countermeasure Remarks Receiver problem Turn power OFF, then E-01 displayed ON again after 10 sec. E-02 displayed If operation is not E-03 displayed restored, request repair (ROM, RAM, by ENERGY EEROM error) SUPPORT CORP. With the error cause E-04 displayed Sensor heater failure Replace sensor.
Page 30: Reference Material
6. Reference Material 6-1 Standard Specifications Model DTF-201 Measurement Principle Zirconia limiting current method Measuring range 0 - 5，10，25% O DC4 - 20 mA (non-insulated output, load resistance 600 Ω or less) Output DC0 - 1 V (non-insulated output, load resistance 100 KΩ or above) ±0.5% FS (0 –...
Page 31: Drawing Name: Dtf-201 Oxygen Analyzer Receiver
Repairs request slip for measuring apparatus ENERGY’s entry column Please Notice for customers following contents through facsimile or telephone. Measuring instrument repair request sheet (product send-back sheet) If the contents of the repair request are insufficient when sending your product back to ENERGY for repair, it takes a long time to perform the acceptance inspection, causing inconvenience in delivery.
Page 32 ENERGY SUPPORT CORPORATION Private description Industrial system Division : 0568-67-1842 ※ To customer Tel. : 0568-67-2743 ※ In terms of contents mentioned Address : 1,Aza Kamikobari,Inuyama, below please get in touch with us by means of FAX or Telephone. Aichi 484-8505...
Page 34 Description in this operation manual is subject to changes without prior notice. For advice or detail of our products and services, contact the Technical Service Team. Industrial System Division...
