COUGAR LUXLIM Quick Start Manual

LUXLIM
LOW PROFI LE O P TI CAL-M EC HAN I C A L GAM I N G KE Y B OAR D

14 LIGHT EFFECTS

Raninbow
Reset
Default

Key-light option

+

Background option

+
Press and hold
down the FN key
and ESC key for

Key-light direction

3 seconds and
+
the white light
will flash 4 times.
Key-light option Rainbow, Red, Yellow, Green, Cyan, Blue, Purple, White
Background option Red, Yellow, Green, Cyan, Blue, Purple, White, OFF

Manual Mode

( Need to press the key to show the light effcets. )
Laser Cross
+ x 9 + x 10
Key-light option Key-light option
+ +
Background option Background option
+ +
Key-light direction
+
Key-light option Rainbow, Red, Yellow, Green, Cyan, Blue, Purple, White
Background option Red, Yellow, Green, Cyan, Blue, Purple, White, OFF
The light effect would be not obvious if you set similar or rainbow colors as key-light and background option.
Breathing Color Cycle
+ x 1 + x 2
Key-light option Key-light option
+ +
Background option Background option
+ +
Pulse Firework
+ x 11 + x 12
Key-light option Key-light option
+ +
Background option Background option
+ +
Key-light direction
+

Media and function shortcuts

FN+F1、F2、F3、F4、F5、F6、F7、F8、F9、F10、F11、F12
Some shortcuts keys do not works with Mac OS.
1. Only the shortcuts keys, FN+(F1, F5, F9, F10, F11, F12),
can not work in Mac OS.
2. Luxlim's FN key different from Mac OS's FN key.
Mac OS
WIN-LOCK
FN+
Twinkle Radar
+ x 3 + x 4
Key-light option Key-light option
+ +
Background option Background option
+ +
Key-light direction
+
The light effect would be not obvious if you set similar or rainbow colors as key-light and
background option.
How to customize and save your own Background effect
to 2 on-board memory profiles?
Ripple 2
1.Press and hold the FN key and END key simultaneously to make the PGUP(C1) and PGDN(C2)
key flash with white light.
2.Press PGUP(C1) or PGDN(C2) to choose mode you want to set.
3.Press any key you want to set to change the backlight color.
4. Press and hold down the FN key and END key simultaneously to save it.(Or wait for 10 seconds
auto save.)
+ x 13
Key-light option
+
Background option
+

RGB underglow mode

FN+ INS
Direction、brightness & speed
do not be adjusted.
FN key Key-light brightness
=Option
=Command
Key-light speed
Static Ripple 1
+ x 5 + x 6
Key-light option Key-light option
+ +
Background option Background option
+ +
+
Key-light brightness
Light effects
FN+ PRT
Key-light direction Background option
FN+ DEL FN+ SCR
Key-light option
FN+ PAU

Background custom mode

FN+ FN+
FN+
Auto Mode
Wave Reactive
+ x 7 + x 8
Key-light option Key-light option
+ +
Background option Background option
+ +
Background custom mode
Step1
+
Step2 + or
Step3 set up
+
+
Key-light speed
