Thank you for choosing AEORC ultra-micro receiver, this receiver integrates 5A/1S brushed ESC, with
2CH electromagnetic servo control function, and with 5CH PWM signal output function, please read
this document carefully before use.
Version selection
For RX34x series, now we have below 8 versions for choice, please understand the corresponding basic
functions according to the product you purchased.
RX342
RX344
RX345
RX346
Flysky（AFHDA-2A）
RX347
RX344-T
RX345-T
RX346-T
Flysky（AFHDA-2A）
Basic Data
Size： 16*10*2.5mm
Weight： 0.5g
Working voltage：3.0-4.2V
Built-in 2CH electromagnetic servo driver (512 class resolution)
Interface Definition
(with 2CH electromagnetic servo control function)
Protocol
S-FHSS
DSMX/2
FRSKY-D16
FRSKY-D8
DSMX/2
FRSKY-D16
AEORC RX34x Series Mini Micro Receiver
5A/1S Brushed
electromagnetic
ESC
√
√
√
√
√
√
√
√
Instruction Manual
2CH
servo control
√
√
√
√
√
√
√
√
TELEM
√
√
√
Advertisement
Table of Contents
Related Manuals for AEORC RX34 Series
Summary of Contents for AEORC RX34 Series
- Page 1 (with 2CH electromagnetic servo control function) Instruction Manual Thank you for choosing AEORC ultra-micro receiver, this receiver integrates 5A/1S brushed ESC, with 2CH electromagnetic servo control function, and with 5CH PWM signal output function, please read this document carefully before use.
- Page 2 AEORC RX34x Series Mini Micro Receiver (with 2CH electromagnetic servo control function) Instruction Manual Combine receiver and transmitter 1.Turn on the transmitter and power the receiver. At this time, the receiver is in the state of confirming the transmitter signal, and the LED light flashes slowly.
