Sensit SD 115C Instruction Manual

INSTRUCTION MANUAL
TEMPERATURE SENSOR SD 115C DS18B20
Temperature sensor with a plastic head for temperature measurement in
outdoor or indoor areas ranging from -30 to 100 ° C

Application:

The temperature sensors SD 115C are designed for temperature measurements of gaseous substances in outdoor
on the wall of buildings and in rooms, offices, or even production halls. The temperature range for application of the
sensor is – 30°C to 100
temperature sensor . The sensor meets the ingress protection IP65 according to the EN 60 529 standard. The
sensors are suitable for temperature measurement in chemically non-aggressive environments.
Recommended use and location of sensors:
• The temperature measuring in outdoor
- the recommended location of the sensor is on the coldest side of the building (north or northwest), without
direct sunlight, in 2/3 the height of the building wall
• The temperature measuring in rooms, offices, or even production halls
- the recommended location of the sensor is on the inner wall at a height of 1.5 m, in place
with the movement of the people, out of place with sunshine influence and out of places
with the influence of temperature radiators or lighting

Declaration of conformity:

SENSIT s.r.o. provides the product with the EU Declaration of Conformity issued according to Act No. 22/1997
Coll., as subsequently amended. The product is in accordance with the following
• European Parliament and Council Directive 2011/65/EU of 8 June 2011 on the restriction of the use of certain
hazardous substances in electrical and electronic equipment and Commission delegated Directive 2015/863/EU
of 31 March 2015 amending annex II to Directive 2011/65/EU, as amended
Product safety and technical parameters were evaluated according to the following standards and norms, as
amended:
EN 60730-1, EN 60730-2-9, EN 60751, EN 60 529
SENSIT s.r.o.
Školní 2610, 756 61 Rožnov pod Radhoštěm, ID No. 64087484, VAT No. CZ64087484, Phone: +420 571 625 571, Fax: +420 571 625 572
Company is incorporated in the Companies Register at the Regional Court in Ostrava, Section C, File 13728, sensit@sensit.cz, www.sensit.cz
°C. The sensors may be used for all control systems compatible with the DS 18B20
directives:
3749.1 10-20
Supersede
