X65 ASSEMBLY MANUAL

5763EN-4

Table of Contents

Need help?

Do you have a question about the X65 and is the answer not in the manual?

Questions and answers

Summary of Contents for FlexLink X65

Page 1 X65 ASSEMBLY MANUAL 5763EN-4...
Page 3 FlexLink AB. The contents of this manual are for informational use only. All information and specifications contained in this document have been care- fully checked to the best efforts of FlexLink AB, and are believed to be true and accurate as of time of publishing. However, due to continued efforts in product development FlexLink AB reserves the right to modify products and its manuals without notice.
Page 4 X65 System...
Page 5: Table Of Contents
Intermediate drive unit, no slip clutch 4.10 Intermediate drive unit, no slip clutch 4.11 Synchronous drive unit 4.12 Beam section for chain installation 4.13 Idler bend unit 4.14 Vertical bend 4.15 Plain bend 4.16 Wheel bend 4.17 X-bend X65 System...
Page 6 Mounting conveyor chain Mounting conveyor chain using a beam section Mounting chain on drive units Mounting chain on Intermediate drive units 149 Assembly Guide Rail 7 .1 Mounting guide rails 7 .2 Mounting guide rails 7 .3 Connecting plug X65 System...
Page 7: Safety
System information The project number and/or general drawing number shall always be speci- fied when communicating with FlexLink with respect to the machine. Important safety conditions At the moment that the machine is going to be operated by a user, the fol- lowing safety conditions must be met: •...
Page 8: Assembly Information
Only use recommended spare parts. • Only authorised personnel may open electrical units. • FlexLink is not responsible for damage if service on the equip- ment is not performed in accordance with this assembly manual. Maintenance and Service technicians Service technicians must have: •...
Page 9: Introduction
Therefor the underlying symbols will be used to refer the reader to the chapters concerning mounting of slide rail and chain, instead of showing the steps repeatedly. n°1 refer to chapter 5, Assembly slide rail, while n°2 refer to chapter 6, Mounting conveyor chain. X65 System...
Page 10: Support Assembly
Support assembly Support assembly X65 System...
Page 11 Support assembly X65 System...
Page 12: Support Systems Assembly
In the formula H represents the height from the floor to the top of a stand- ard plain chain. Most support combinations permit height adjustments, both at the foot, and at the beam support brackets. X65 System...
Page 13 X65 System...
Page 14: Support Feet Assembly
Support feet assembly 13 mm Ruler X65 System...
Page 15 50 mm X65 System...
Page 16: End Plate Assembly
End plate assembly 5 mm Roller threads X65 System...
Page 17 X65 System...
Page 18: Adjustable Foot Assembly
Adjustable foot assembly 19 mm X65 System...
Page 19 X65 System...
Page 20: Three-Point Support Feet Assembly
Three-point support feet assembly 30 mm 6 mm X65 System...
Page 21 X65 System...
Page 22: Height Adjustment Assembly
Height adjustment assembly 30 mm 6 mm X65 System...
Page 23 X65 System...
Page 24 X65 System...
Page 25 X65 System...
Page 26: Support Bracket Assembly
Support bracket assembly 13 mm X65 System...
Page 27 XLAT 17 XCAN 8 BRB 8,4x16 BRB 8,4x16 XLAN 8 M6S 8x16 X65 System...
Page 28 X65 System...
Page 29 X65 System...
Page 30 X65 System...
Page 31 X65 System...
Page 32: Support Bracket Assembly
Support bracket assembly 13 mm 13 mm X65 System...
Page 33 XLAT 17 XCAN 8 BRB 8,4x16 BRB 8,4x16 XLAN 8 M6S 8x16 X65 System...
Page 34 X65 System...
Page 35 X65 System...
Page 36 X65 System...
Page 37 X65 System...
Page 38 X65 System...
Page 39 X65 System...
Page 40: Support Bracket Assembly
Support bracket assembly 10 mm X65 System...
Page 41 X65 System...
Page 42: Foot Plate Assembly
3.10 Foot plate assembly Roller threads 6 mm X65 System...
Page 43 MF6S-TT 8x30 M8 x30 X65 System...
Page 44 MF6S-TT 8x30 M8 x30 X65 System...
Page 45 X65 System...
Page 46: Guide Rollers Assembly
3.11 Guide rollers assembly 6 mm X65 System...
Page 47 X65 System...
Page 48 X65 System...
Page 49 X65 System...
Page 50: Support Bracket For Hnlp/Hnrp Drive Units
3.12 Support bracket for HNLP/HNRP drive units 13 mm X65 System...
Page 51 X65 System...
Page 52 X65 System...
Page 53 X65 System...
Page 54: Support Adapters For Horizontal Bend Drive Units
3.13 Support adapters for horizontal bend drive units. 5 mm 10 mm X65 System...
Page 55 X65 System...
Page 56 X65 System...
Page 57 X65 System...
Page 58: Conveyor Assembly
Conveyor assembly Conveyor assembly X65 System...
Page 59 Conveyor assembly X65 System...
Page 60: Idler End Unit
Idler end unit 4 mm X65 System...
Page 61 ≈ 6-8 Nm X65 System...
Page 62: Horizontal Bend Drive Unit, With Slip Clutch
Horizontal bend drive unit, with slip clutch 10 mm 3 mm 10 mm NOCO-Fluid 13 mm 4 mm or similar Snap ring pliers Hook spanner X65 System...
Page 63 ≈ 6-8 Nm X65 System...
Page 64 X65 System...
Page 65 X65 System...
Page 66 Traction force, F Article number for the slip clutch are found in Spare parts catalogue for X65. X65 System...
Page 67 X65 System...
Page 68: Horizontal Bend Drive Unit, No Slip Clutch
Horizontal bend drive unit, no slip clutch 4 mm 10 mm NOCO-Fluid Snap ring pliers 6 mm or similar X65 System...
Page 69 ≈ 6-8 Nm X65 System...
Page 70 X65 System...
Page 71 X65 System...
Page 72 X65 System...
Page 73 X65 System...
Page 74: End Drive Unit, Direct Drive With Slip Clutch
End drive unit, direct drive with slip clutch 10 mm 3 mm 10 mm NOCO-Fluid 13 mm 4 mm or similar Snap ring pliers Hook spanner X65 System...
Page 75 20 mm 25 mm ≈ 6-8 Nm X65 System...
Page 76 20 mm >4,5 mm X65 System...
Page 77 X65 System...
Page 78 X65 System...
Page 79 Traction force, F Article number for the slip clutch are found in Spare parts catalogue for X65. X65 System...
Page 80 25 mm X65 System...
Page 81 X65 System...
Page 82: End Drive Unit, Direct Drive, No Slip Clutch
End drive unit, direct drive, no slip clutch 10 mm 4 mm 10 mm NOCO-Fluid 13 mm or similar Snap ring pliers X65 System...
Page 83 ≈ 6-8 Nm X65 System...
Page 84 X65 System...
Page 85 X65 System...
Page 86 X65 System...
Page 87 X65 System...
Page 88: End Drive Unit, Suspended With Slip Clutch
End drive unit, suspended with slip clutch 4 mm X65 System...
Page 89 ≈ 6-8 Nm X65 System...
Page 90: End Drive Unit, Guided Chain With Slip Clutch
End drive unit, guided chain with slip clutch 10 mm 3 mm 10 mm NOCO-Fluid 13 mm 4 mm or similar Snap ring pliers Hook spanner X65 System...
Page 91 20 mm 25 mm ≈ 6-8 Nm X65 System...
Page 92 20 mm >4,5 mm X65 System...
Page 93 X65 System...
Page 94 Traction force, F Article number for the slip clutch are found in Spare parts catalogue for X65. X65 System...
Page 95 25 mm X65 System...
Page 96: End Drive Unit, Guided Chain, No Slip Clutch
End drive unit, guided chain, no slip clutch 10 mm 3 mm 10 mm NOCO-Fluid 13 mm 4 mm or similar Snap ring pliers X65 System...
Page 97 ≈ 6-8 Nm X65 System...
Page 98 X65 System...
Page 99 X65 System...
Page 100: Intermediate Drive Unit, No Slip Clutch
Intermediate drive unit, no slip clutch 10 mm 10 mm 4 mm NOCO-Fluid 13 mm or similar Snap ring pliers X65 System...
Page 101 ≈ 6-8 Nm X65 System...
Page 102 X65 System...
Page 103 X65 System...
Page 104 X65 System...
Page 105 X65 System...
Page 106: Intermediate Drive Unit, No Slip Clutch
4.10 Intermediate drive unit, no slip clutch 10 mm 4 mm 10 mm NOCO-Fluid 13 mm or similar Snap ring pliers X65 System...
Page 107 ≈ 6-8 Nm X65 System...
Page 108 X65 System...
Page 109 X65 System...
Page 110: Synchronous Drive Unit
4.11 Synchronous drive unit 10 mm 3 mm 4 mm Loctite 13 mm 4 mm Stripes Cutting pliers X65 System...
Page 111 X65 System...
Page 112 ≈ 6-8 Nm X65 System...
Page 113 2-3 mm X65 System...
Page 114 X65 System...
Page 115 X65 System...
Page 116: Beam Section For Chain Installation
4.12 Beam section for chain installation 4 mm X65 System...
Page 117 ≈ 6-8 Nm X65 System...
Page 118: Idler Bend Unit
4.13 Idler bend unit 4 mm X65 System...
Page 119 ≈ 6-8 Nm X65 System...
Page 120: Vertical Bend
4.14 Vertical bend 4 mm X65 System...
Page 121 ≈ 6-8 Nm X65 System...
Page 122: Plain Bend
4.15 Plain bend 4 mm X65 System...
Page 123 ≈ 6-8 Nm X65 System...
Page 124: Wheel Bend
4.16 Wheel bend 4 mm X65 System...
Page 125 ≈ 6-8 Nm X65 System...
Page 126: X-Bend
4.17 X-bend 13 mm 4 mm X65 System...
Page 127 ≈ 6-8 Nm X65 System...
Page 128 ≈ 6-8 Nm X65 System...
Page 129 ≈ 6-8 Nm X65 System...
Page 130 X65 System...
Page 131 X65 System...
Page 132: Assembly Slide Rail
Assembly slide rail Assembly slide rail X65 System...
Page 133 Assembly slide rail X65 System...
Page 134: Slide Rail Mounting
Slide rails are available in three profile designs: 1. Narrow 2. Wide Not suitable in bends 3.Support rail for plain bends The guides are used as shown below: Note: It is recommended to avoid splicing as much as possible X65 System...
Page 135 X65 System...
Page 136: Mounting Slide Rail On Idler End Unit
Mounting slide rail on idler end unit Mounting tool X65 System...
Page 137 X65 System...
Page 138: Joining Slide Rail Ends
Joining slide rail ends Cutting Pliers X65 System...
Page 139 45° X65 System...
Page 140: Fixing Slide Rail To The Conveyor Using Aluminium Rivets
Fixing slide rail to the conveyor using aluminium rivets X65 System...
Page 141 ≈30 X65 System...
Page 142: Mounting Conveyor Chain
Mounting conveyor chain Mounting conveyor chain X65 System...
Page 143 Mounting conveyor chain X65 System...
Page 144: Mounting Conveyor Chain Using A Beam Section
Mounting conveyor chain using a beam section 4 mm Pin insertion tool X65 System...
Page 145 X65 System...
Page 146 X65 System...
Page 147 ”snap” X65 System...
Page 148 X65 System...
Page 149 ”snap” X65 System...
Page 150: Mounting Chain On Drive Units
Mounting chain on drive units Pin insert tool X65 System...
Page 151 ”snap” X65 System...
Page 152 X65 System...
Page 153 X65 System...
Page 154: Mounting Chain On Intermediate Drive Units
Mounting chain on Intermediate drive units 10 mm Pin insertion tool X65 System...
Page 155 X65 System...
Page 156 ”snap” X65 System...
Page 157 X65 System...
Page 158: Assembly Guide Rail
Assembly Guide Rail Assembly Guide Rail X65 System...
Page 159 Assembly Guide Rail X65 System...
Page 160: Mounting Guide Rails
1000 mm, there is a possi- bility that guide rails will become deformed due to excessive force. 7.1.2 Effective track width The effective track width is calculated as in figure below. W = WB + W1 + W2 - 2C X65 System...
Page 161 X65 System...
Page 162: Mounting Guide Rails
7 .2 Mounting guide rails 13 mm Pliers X65 System...
Page 163 X65 System...
Page 164: Connecting Plug
7 .3 Connecting plug No tools required X65 System...
Page 165 X65 System...
