  • Page 1 Digi XBee® RR RF Module Hardware Reference Manual...
  • Page 2 Added chip antenna 29000710, re-included EU/UKCA certification section. 2022 Trademarks and copyright Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United States and other countries worldwide. All other trademarks mentioned in this document are the property of their respective owners.
  • Page 3 To provide feedback on this document, email your comments to techcomm@digi.com Include the document title and part number (Digi XBee® RR RF Module Hardware Reference Manual, 90002517 C) in the subject line of your email. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 4: Table Of Contents

    Contents Digi XBee® RR RF Module Hardware Reference Manual Safety instructions Safety instructions XBee modules И нс т рукции з а бе з опа с нос т XBee м одул и Sigurnosne upute XBee moduli Bezpečnostní instrukce moduly XBee Sikkerhedsinstruktioner...
  • Page 5 Networking and security specifications Communication interface specifications Mechanical drawings Micro antennas Micro (U.FL/RF Pad) Pin signals Pin signals for the XBee RR micro module Recommended pin connections Design notes Power supply design Board layout Antenna performance Design notes for RF pad devices...
  • Page 6 Labeling requirements For model XBRR, XBee RR RF MMT For PRO model XBPRR, XBee RR RF MMT RF Exposure Transmitters with detachable antennas Detachable antenna Europe (CE/UKCA) for model: XBRR Maximum power and frequency specifications CE and UKCA OEM labeling requirements...

  • Page 7: Digi Xbee® Rr Rf Module Hardware Reference Manual

    Digi XBee® RR RF Module Hardware Reference Manual This manual provides information for the XBee RR RF Module hardware. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 8: Safety Instructions

    Sicherheitshinweise Ο δηγ ίες ασ φαλείας Biztonsági utasítások Istruzioni di sicurezza Drošības instrukcijas Saugos instrukcijos Sikkerhetsinstruksjoner Instrukcje bezpieczeństwa Instruções de segurança Instructiuni de siguranta Bezpečnostné inštrukcie Varnostna navodila Módulos XBee Säkerhets instruktioner Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 9: Safety Instructions

    пе ч а т на т а пл а т ка и ком поне нт ит е . Н е из л а га йт е ра диом одул ит е XBee на в ода ил и в л а га . Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 10: Sigurnosne Upute

    štít ani nijak neupravujte XBee. Úpravy mohou vyjmout modul z jakékoli záruky a mohou způsobit, že rádio XBee bude fungovat mimo zákonnou shodu pro danou zemi, což povede k možnému nezákonnému provozu rádia. Při manipulaci s modulem XBee používejte standardní ochranu ESD. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 11: Sikkerhedsinstruktioner

    De XBee-radiomodule is niet goedgekeurd voor gebruik in (deze lijst is niet uitputtend): o medische apparaten o nucleaire toepassingen o explosieve of ontvlambare atmosferen Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 12: Ohutusjuhised

    Lõppkasutajale tuleb öelda, kuidas XBee raadiomoodulilt toide eemaldada või antennid inimestest või loomadest 20 cm kaugusele paigutada. Turvallisuusohjeet XBee moduulit XBee-radiomoduulin toimintaa ei voida taata radiolinkin vuoksi, joten sitä ei tule käyttää turvallisuuden kannalta kriittisten laitteiden, kuten koneiden tai autosovellusten, Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 13: Consignes De Sécurité

    Utilisez ce produit avec les antennes spécifiées dans les guides d'utilisation du module XBee. L'utilisateur final doit savoir comment couper l'alimentation du module radio XBee ou placer les antennes à 20 cm des humains ou des animaux. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 14: Sicherheitshinweise

    οδηγ ών τ ας σ ε πιθαν ή παρ άν ομη λειτ ουρ γ ία τ ου ρ αδιοφών ου. Χ ρ ησ ιμοποιήσ τ ε βιομηχ αν ική πρ οσ τ ασ ία ESD κατ ά τ ο χ ειρ ισ μό τ ης μον άδας XBee. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 15: Biztonsági Utasítások

    Non ci sono componenti riparabili dall'utente all'interno del modulo radio XBee. Non rimuovere lo scudo o modificare in alcun modo l'XBee. Le modifiche possono escludere il Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 16: Drošības Instrukcijas

    Negalima garantuoti, kad „XBee“ radijo modulis veiks dėl radijo ryšio, todėl jo neturėtų būti naudojamas blokuoti saugai svarbiuose įrenginiuose, pvz., mašinose ar automobiliuose. XBee radijo modulis nebuvo patvirtintas naudoti (šis sąrašas nėra baigtinis): medicinos prietaisai branduolinės programos sprogioje ar degioje aplinkoje Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 17: Sikkerhetsinstruksjoner

    Moduł radiowy XBee nie został dopuszczony do użytku w (lista ta nie jest wyczerpująca): Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 18: Instruções De Segurança

    • Use este produto com as antenas especificadas nos guias do usuário do módulo XBee. • O usuário final deve ser informado sobre como remover a energia do módulo de rádio XBee ou localizar as antenas a 20 cm de humanos ou animais. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 19: Instructiuni De Siguranta

    čo vedie k možnej nezákonnej prevádzke rádia. Pri manipulácii s modulom XBee používajte štandardnú ochranu pred ESD. Pri manipulácii buďte opatrní, aby ste predišli elektrickému poškodeniu dosky plošných spojov a komponentov. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 20: Varnostna Navodila

    XBee funcione fuera del cumplimiento normativo de un país determinado, lo que puede provocar una operación ilegal de la radio. Utilice la protección ESD estándar de la industria al manipular el módulo XBee. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 21: Säkerhets Instruktioner

    Använd den här produkten med antennerna som specificeras i XBee-modulens användarguider. Slutanvändaren måste informeras om hur man kopplar bort strömmen från XBee- radiomodulen eller för att placera antennerna 20 cm från människor eller djur. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 22: Specifications

    Specifications The following tables provide general specifications for the hardware. General specifications Electrical characteristics Power requirements Regulatory conformity summary Serial communication specifications GPIO specifications Electro Static Discharge (ESD) Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 23: General Specifications

    -40 to 85 °C (industrial) RF pad or U.FL connector Antenna options Analog-to-digital converter 4 10-bit analog inputs (ADC) Electrical characteristics The following table lists the electrical characteristics for the XBee RR RF Module. Symbol Parameter Condition Typical Units Input pins -0.3...

  • Page 24: Regulatory Conformity Summary

    Transmit Output Power for BLE +8 dBm +8 dBm +8 dBm Transmit Output Power for 802.15.4 +19 dBm Bluetooth® Declaration ID: (pending) Declaration ID: (pending) Europe (CE) UK (UKCA) Brazil ANATEL: 10535-22-03966 pending Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 25: Serial Communication Specifications

    RTS/ DIO6 SPI pin assignments GPIO specifications XBee RR RF Modules have 15 General Purpose Input / Output (GPIO) ports available. The exact list depends on the device configuration as some GPIO pads are used for purposes such as serial communication.

  • Page 26: Ieee 802.15.4-Specific Specifications

    IEEE 802.15.4-specific specifications The following tables provide specifications specific to the XBee RR RF Module when using the IEEE 802.15.4 physical layer, for example: XBee 802.15.4, Zigbee, DigiMesh, and so on. Performance specifications Networking and security specifications Communication interface specifications...

  • Page 27: Performance Specifications

    Networking and security specifications The following table describes the networking and security specifications for the XBee RR RF Module. XBee RR Specification...

  • Page 28: Mechanical Drawings

    Mechanical drawings The following mechanical drawings of the XBee RR RF Modules show all dimensions in inches. Micro antennas Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 29: Micro Antennas

    Mechanical drawings Micro antennas Micro antennas The following mechanical drawings are for the XBee RR RF Module micro antennas. Micro (U.FL/RF Pad) Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 30: Pin Signals

    Pin signals Pin signals for the XBee RR micro module Recommended pin connections Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 31: Pin Signals For The Xbee Rr Micro Module

    Pin signals for the XBee RR micro module Pin signals for the XBee RR micro module The following drawing shows the micro pin locations. The following table shows the pin signals and their descriptions for the XBee RR RF Module. Default Pin#...
  • Page 32 Pin signals Pin signals for the XBee RR micro module Default Pin# Name Direction state Description Line/GPIO. Ground. Serial peripheral SPI_ATTN/ BOOTMODE/DIO19 Output Output interface attention Do not tie low on reset. Ground. SPI_CLK /DIO18 Input Input Serial peripheral interface clock/GPIO.

  • Page 33: Recommended Pin Connections

    VCC, GND, DOUT, DIN, RTS, and DTR. For applications that need to ensure the lowest sleep current, never leave unconnected inputs floating. Use internal or external pull-up or pull-down resistors, or set the unused I/O lines to outputs. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 34: Design Notes

    Design notes XBee RR RF Modules do not require any external circuitry or specific connections for proper operation. However, there are some general design guidelines that we recommend to build and troubleshoot a robust design. Power supply design Board layout...

  • Page 35: Power Supply Design

    To help reduce noise, place a 1.0 µF and 8.2 pF capacitor as near as possible to the VCC connection on the XBee RR RF Module (pad 2 for micro and surface-mount, and pin 1 for through-hole).

  • Page 36: Design Notes For Rf Pad Devices

    Implementing these design suggestions helps ensure that the RF pad device performs to its specifications. The following figures show a layout example of a host PCB that connects an RF pad device to a right angle, through-hole RPSMA jack. Digi XBee® RR RF Module Hardware Reference Manual...
  • Page 37 We do not recommend using a trace wider than the pad width, and using a very narrow trace (under 0.010") can cause unwanted RF loss. The following illustration shows PCB layer 2 of an example RF layout. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 38: Copper Keepout For Test Points

    RF test points on the bottom of the device as shown in the following diagrams. These devices have a ground plane in the middle on the back side for shielding purposes, which can be affected by copper traces directly below the device. Digi XBee® RR RF Module Hardware Reference Manual...
  • Page 39 Design notes Copper keepout for test points Copper keepout for the Micro Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 40: Regulatory Information

    Regulatory information United States (FCC) ISED (Innovation, Science and Economic Development Canada) Europe (CE/UKCA) for model: XBRR Brazil ANATEL Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 41: United States (Fcc)

    (1.) this device may not cause harmful interference and (2.) this device must accept any interference received, including interference that may cause undesired operation. CAUTION! Changes or modifications not expressly approved by Digi International Inc. could void the user's authority to operate the equipment.

  • Page 42: Fcc-Approved Antennas (2.4 Ghz)

    United States (FCC) FCC-approved antennas (2.4 GHz) The XBee RR RF Module can be installed using antennas and cables constructed with non-standard connectors (RPSMA, RPTNC, etc.) An adapter cable may be necessary to attach the XBee connector to the antenna connector.
  • Page 43 Channel 26 (2480 MHz) will be limited to +3 dBm to meet band edge requirements for FCC and ISED. All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.
  • Page 44 Model: XBRR Required antenna cable loss (dB) 802.15.4 Based Bluetooth low energy Type Gain Protocols (Ex: technology (when (description) Part number (dB) Application* Min. separation Zigbee) available) A24-F3NF Omni-directional (Fiberglass base Fixed/Mobile 20 cm station) A24-F5NF Omni-directional (Fiberglass base Fixed 20 cm 0.72 station) A24-F8NF...
  • Page 45 Model: XBRR Required antenna cable loss (dB) 802.15.4 Based Bluetooth low energy Type Gain Protocols (Ex: technology (when (description) Part number (dB) Application* Min. separation Zigbee) available) A24-P14NF Flat Panel 14.0 Fixed 12.82 2.58 A24-P15NF Flat Panel 15.0 Fixed 13.82 3.58 A24-P16NF Flat Panel 16.0 Fixed...
  • Page 46 Channel 26 (2480 MHz) will be limited to +3 dBm to meet band edge requirements for FCC and ISED. All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.
  • Page 47 Model: XBPRR Required antenna cable loss (dB) 802.15.4 Based Bluetooth low Protocols (Ex: energy technology Gain (dB) Part number Type (description) Application* Min separation Zigbee) (when available) articulated RPSMA - 5.25") 31000019-01 Integral Dipole 0.87 Fixed only 20 cm (USB Adapter Only) Omni-directional (Collinear Dipole Array) antennas A24-F2NF Omni-directional...
  • Page 48 Model: XBPRR Required antenna cable loss (dB) 802.15.4 Based Bluetooth low Protocols (Ex: energy technology Gain (dB) Part number Type (description) Application* Min separation Zigbee) (when available) (Fiberglass base station) A24-W7NF Omni-directional Fixed 2.22 (Fiberglass base station) A24-M7NF Omni-directional Fixed 2.22 (Mag-mount base station) A24-F15NF...
  • Page 49 Model: XBPRR Required antenna cable loss (dB) 802.15.4 Based Bluetooth low Protocols (Ex: energy technology Gain (dB) Part number Type (description) Application* Min separation Zigbee) (when available) A24-Y7NF Yagi (7-element) Fixed 4.22 A24-Y9NF Yagi (9-element) 10.0 Fixed 5.22 A24-Y10NF Yagi (10-element) 11.0 Fixed 6.22...

  • Page 50: Rf Exposure

    IMPORTANT: XBee XBRR and XBee XBPRR Zigbee RF Modules have not been certified by the FCC for use (integrated) with other radio products. The customer integrating the Digi XBee RF module is responsible for the FCC certifications of their product.

  • Page 51: Over-Voltage Detection

    2.7 Antennas A list of approved antennas is provided for the XBee RR product. For the XBee RR, see The following table shows the antennas approved for use with the XBee RR RF Module.. For the XBee-PRO RR, see XBee RR-PRO RF module.

  • Page 52: Ised (Innovation, Science And Economic Development Canada)

    (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. For PRO model XBPRR, XBee RR RF MMT Contains Model XBPRR, IC: 1846A-XBPRR The integrator is responsible for its product to comply with IC ICES-003 & FCC Part 15, Sub. B - Unintentional Radiators.

  • Page 53: Transmitters With Detachable Antennas

    Europe (CE/UKCA) for model: XBRR The XBee RR RF Module has been tested for use in several European countries. For a complete list, refer to www.digi.com/resources/certifications. If XBee RR RF Modules are incorporated into a product, the manufacturer must ensure compliance of the final product with articles 3.1a and 3.1b of the Radio Equipment Directive.

  • Page 54: Maximum Power And Frequency Specifications

    The CE marking must have a height of at least 5 mm except where this is not possible on account of the nature of the apparatus. The CE marking must be affixed visibly, legibly, and indelibly. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 55: Declarations Of Conformity

    For more information, see www.digi.com/resources/certifications. Antennas The following antennas have been tested for use with the XBee RR RF Module. All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.
  • Page 56 Regulatory information Europe (CE/UKCA) for model: XBRR Dipole (2.1 dBi, Omni-directional, Articulated RPSMA, Digi part number A24-HABSM) Chip antenna (micro form factor only) (0.0 dBi) Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 57: Brazil Anatel

    Este produto está homologado pela ANATEL, de acordo com os procedimentos regulamentados pela Resolução 242/2000, e atende aos requisitos técnicos aplicados. Para maiores informações, consulte o site da ANATEL www.anatel.gov.br. Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 58: Xbib-C Development Boards

    XBIB-C development boards This section describes the XBIB-C development boards and how to interact with them. XBIB-C Micro Mount reference Attach the XBee RR RF Module Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 59: Xbib-C Micro Mount Reference

    This board is sold separately. WARNING! Connecting one pin off will destroy the unit under test! Always disconnect USB and power before changing one unit for another. See the following images for examples. Incorrect Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 60: Correct

    XBIB-C development boards XBIB-C Micro Mount reference Correct Digi XBee® RR RF Module Hardware Reference Manual...
  • Page 61 XBIB-C development boards XBIB-C Micro Mount reference Digi XBee® RR RF Module Hardware Reference Manual...
  • Page 62 This part is accessible through I2C. Be sure that the XBee that is inserted into the development board has I2C if access to this sensor is desired. XBee Socket This is the socket for the XBee (Micro form factor). Digi XBee® RR RF Module Hardware Reference Manual...

  • Page 63: Attach The Xbee Rr Rf Module

    WARNING! Make sure the board is NOT powered when you plug in the XBee RR RF Module. Never insert or remove the XBee RR RF Module while the power is on! Make sure the XBee RR RF Module is oriented correctly and not upside down when you attach it to the board.

  • Page 64: Manufacturing Information

    Manufacturing information Manufacturing information The micro XBee RR RF Module is designed for surface-mounting on the OEM PCB. It has castellated pads to allow for easy solder attaching and inspection. The pads are all located on the edge of the device so there are no hidden solder joints on these devices.

  • Page 65: Recommended Solder Reflow Cycle

    Hand soldering is possible and should be done in accordance with approved standards. Handling and storage The XBee RR RF Modules are level 3 Moisture Sensitive Devices. When using this kind of device, consider the relative requirements in accordance with standard IPC/JEDEC J-STD-020.

  • Page 66: Flux And Cleaning

    Place the component last and set the placement speed to the slowest setting. Flux and cleaning Digi recommends that a “no clean” solder paste be used in assembling these devices. This eliminates the clean step and ensures unwanted residual flux is not left under the device where it is difficult to remove.

  • Page 67: Reworking

    During rework, the device temperature may rise above its internal solder melting point and care should be taken not to dislodge internal components from their intended positions. Digi XBee® RR RF Module Hardware Reference Manual...
